Summary of Contents for Speck pumps Badu Eco Touch II
- Page 1 Installation, Operating, and Service Manual ® Badu Eco Touch Controller Rev.0113...
-
Page 2: Table Of Contents
Date of Installation: Installed by: Serial Number: For Service Call: Manufactured by Speck Pumps, Jacksonville Florida USA, © 2012-2013 All Rights Reserved. This document is subject to change without notice. Table of Contents Important Safety Instructions General Description Dimensions . -
Page 3: Important Safety Instructions
General Description The Badu Eco Touch II is designed to be intuitive and simple to use. The controller is designed to be used with the Badu EcoM3 swimming pool pump. Once the motor is powered on, the installer or pool owner can enter start times for High, Medium, and Low speeds or enter a stop time. -
Page 4: Dimensions
Dimensions 1.625" 6.75" 3.25" 3.5" 2.0" 1.0" Installation Preparation Guide 1. Upon receipt of the controller, check the carton for damage. Open the carton and check the controller for concealed damage, such as cracks, or dents. If damage is found, contact the shipper or distributor where the controller was purchased. -
Page 5: Installation
8. The controller can now be mounted using the mounting holes located on each side. 9. The front of the controller has a clear sheet of Mylar for protection. This can now be removed. 10. Plug the Badu Eco Touch II transformer into an outlet (100-240 V, 50-60 Hz). Proceed with operation instructions. -
Page 6: Operation
It also displays current program running, programmed speed, and the start time. The Badu Eco Touch II is a 24 hour time clock. Times are set from 00:00 (midnight) to 23:50 with the minutes set in ten (10) minute increments. Anytime a program is added, the Badu Eco Touch II will re-number and put the programs in order automatically. - Page 7 00:00 to select the event/program to be deleted. • Press SET to delete the event/program (Note: Once the event/program has been deleted the Badu Eco Touch II will renumber the events/ programs and return to the Home Screen) Figure 2C...
- Page 8 Press the Up (arrow key) or the DOWN (arrow key) to chose the speed. (See Figure 3A) Just leave the Badu Eco Touch II in one of speeds and the pump will remain in the chosen position until the “Time Limit”...
- Page 9 Setting Date & Time DATE/TIME SCREEN This is the “Date/Time Screen” (See Figure 5). • Press MODE to continue on to the “Information Date/Time Screen” 28-OCT-11 12:00 • Press SET to edit the date & time. (See Figure 5A) • Press the UP (arrow key) or DOWN (arrow Key) to adjust the day.
- Page 10 System Error Screens SYSTEM ERROR SCREEN This is the “System Errors Screen” (See Figure 7). System errors • Press MODE to continue on to the “Home Screen” • Press the UP (arrow key) or DOWN (arrow Key) to view the system errors. (See Table 2.0 for description) North American Version Only.
-
Page 11: Limited Warranty
2. To the fullest extent permitted by law, the Limited Warranty will be void and of no force or effect and Speck Pumps - Pool Products, Inc. will have no liability, responsibilities or obligations to Buyer or with respect to the pump and motor in the event... - Page 12 7. A return merchandise authorization (“RMA”) must be obtained from Speck Pumps - Pool Products, Inc. before returning any product. Products returned without an RMA will be refused and returned, unopened, to the Buyer. All returned products are to be sent freight prepaid and insured for Buyer’s protection to the manufacturer at 8125 Bayberry Road, Jacksonville,...
- Page 13 Notes...
- Page 14 Rev. 032013...
