Summary of Contents for Kyla Smart Temperature/ Humidity Sensor
- Page 1 User Guide...
- Page 2 Smart Temperature/ Humidity Sensor Thanks for using Aztech Kyla product If you need support or help, please visit www.kyla.aztech.com...
-
Page 3: Product Description
Product Description The Smart Temperature/Humidity Sensor monitors home temperature and humidity values anywhere even when out of home. It adopts ultra-low power consumption Zigbee wireless network technology. With dust-proof and insect-proof function, the product is designed to secured. With high-precision temperature and humidity built-in sensor, it can perceive and report temperature and humidity conditions in real-time through App. - Page 4 Operation Guide Step 1: Download Aztech Kyla App from Google Play/App Store Aztech Kyla App Step 2: Login to Aztech Kyla App, then add “Smart Temperature/ Humidity Sensor” to device list to enable the device.
- Page 5 Step 3: Remove battery insulation film to power on.
- Page 6 Step 4: Following the App instructions, long press the device’s networking key until the green LED flashes. The App will be prompted once connected succesfully to the network. Network Network Status Lamp...
- Page 7 Step 5: Tear off the gummed film then stick the equipment to the required area.
- Page 8 Step 6: Note that the mounting base shall be upright as shown on the diagram below. Finally, hang the Smart Temperature/ Humidity Sensor onto the mounting base.
-
Page 9: Speci Cations
Technical Speci cations Working Voltage DC3V (1* CR2450 Button Battery) Standby Current ≤ 10uA Networking Mode Zigbee Ad-Hoc Network Wireless Networking Distance ≤ 100m (Open Area) Working Environment -15 ~ 60°C Working Humidity Max 95% RH Product Dimensions 79 x 68 x 31mm... - Page 10 ©2018 Aztech Technologies Pte Ltd. All rights reserved.
