Paging Microphone Base for Announcements
Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and
Audio Applications. Zone Announcements, Night Ringer, Multicast general call,
Background music, Standard SIP call or Emergency call, SD memory with pre-recorded
messages, Relays for LAN drives.
Revision
Date
0
20/03/2018
TEMA TELECOMUNICAZIONI
"IP COMMUNICATION AND SECURITY COMPANY"
WWW.TEMATLC.IT
AD696/B
Serie Audio Over IP Network
PRODUCT MANUAL
Version HW 1.0
Revision reason
First release
Prepared
DP
Checked/Approved
DP, FL
Advertisement
Table of Contents
Related Manuals for Tema Telecomunicazioni AD696/B
Summary of Contents for Tema Telecomunicazioni AD696/B
- Page 1 TEMA TELECOMUNICAZIONI “IP COMMUNICATION AND SECURITY COMPANY” WWW.TEMATLC.IT AD696/B Paging Microphone Base for Announcements Serie Audio Over IP Network Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and Audio Applications. Zone Announcements, Night Ringer, Multicast general call, Background music, Standard SIP call or Emergency call, SD memory with pre-recorded messages, Relays for LAN drives.
- Page 2 AD696/B Paging Microphone Base for Announcements TEMA TELECOMUNICAZIONI DICHIARAZIONE DI CONFORMITÀ CE DECLARATION OF CONFORMITY CE TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: Base microfonica per annunci Product name...
- Page 3 This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.
- Page 4 AD696/B Paging Microphone Base for Announcements TEMA TELECOMUNICAZIONI INDEX PAGE PRESENTATION ............................5 TECHNICAL SPECIFICATIONS ....................... 7 PACKING LIST ............................7 OPERATION ..............................8 CONNECTION ............................. 8 MAS-AD696-B-REV00EN Page 4 of 8...
- Page 5 TEMA TELECOMUNICAZIONI 1. PRESENTATION The AD696/B paging microphone base can be connected to an AD615 Tema Encoder to launch announcements on the LAN network in Multicast channels to the network amplifiers or to the IP-SIP AD600 series loudspeakers of the SipComStage line.
- Page 6 AD696/B Paging Microphone Base for Announcements TEMA TELECOMUNICAZIONI VoIP SIP Amplifiers-Speakers Products and Accessories of the AD600 series “SipComStage” AA-39DL AD630 IP-SIP PoE 25W Horn Speaker Plug Power Supply 220Vac/12Vdc-1,0A. with 40W internal amplifier (2x20W) IP65 protection. AA-39D1A AD635 IP-SIP PoE 12W speaker for wall DIN Power Supply 220Vac/15Vdc-1,0A.
-
Page 7: Technical Specifications
AD696/B Paging Microphone Base for Announcements TEMA TELECOMUNICAZIONI 2. TECHNICAL SPECIFICATIONS Microphone capsule Electret condenser Polar diagram Cardioid Frequency response 50 ÷ 16.000 Hz Output impedance 1000 Ohm Sensitivity -40dB (0dB 1V/Pa @1Khz) Controls Direct “Talk” button, “Chime” feature not present Signalings “Talk”... - Page 8 AD696/B Paging Microphone Base for Announcements TEMA TELECOMUNICAZIONI 4. OPERATION The AD696/B base is designed to be used in conjunction with the AD615/S audio encoder system. AD696/B allows an operator to transmit a message to a loudspeakers network for alerts or announcements. LED for active...
