E-Core HP5139 User Manual

Rf2.4g wireless controller for psii
Hide thumbs
1
2
3

Advertisement

Table of Contents

RF2.4G PSII WIRELESS CONTROLLER（HP5139）
USER MANUAL
IMPORTANT INFORMATION REQUIRED BY THE FCC
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO
THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S
AUTHORITY TO OPERATE THE EQUIPMENT.
E-CORE TECHNOLOGY (CHINA) CO., LTD
Thanks for select our RF 2.4G PSII controller! For play more
conviently and correctly, please read the manual carefully before
playing.

Product brief Introduction

HP5139 wireless controller adopt 2.4GHz RF technology, with
steady connection capacity, far distance, low function wastage; beautiful
outlook, good handle , make you feel be personlly on the scene!

Technology Specification

1.
Compatible with PSX、PS1and PSII game console
2.
Two selection model（ANALOG、DIGITAL）
3.
Support TURBO function
4.
Signal connect indicate
5.
Auto/un-unto connection
6.
Fixup ID code defending fault fucntion
7.
Power deplete low, low voltage indicate
8.
Auto sleep saving electricity function
9.
12 buttons and 256 level simulate funciton
10. Grip with soft plastic to prevent slipping
11. Availability distance≥10M
12. Work voltage：6V 4×1.5V AAA battery
13. Work current：work current 6.5mA sleep status:15μA
14. Size：controller 155*110*75mm；receiver 80×50×20mm
15. Weight：156g

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP5139 and is the answer not in the manual?

Questions and answers

Summary of Contents for E-Core HP5139

  • Page 1 THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. HP5139 wireless controller adopt 2.4GHz RF technology, with steady connection capacity, far distance, low function wastage; beautiful outlook, good handle , make you feel be personlly on the scene! Technology Specification Compatible with PSX、PS1and PSII game console...
  • Page 2 2）. Connect PSII console to TV, put in the game dish, insert receiver. 3）. Draw the switch in controller (HP5139) front to “ON” switch on，POWER LED bright，then switch on the game console,”CONNECT” in receiver bright ；...
  • Page 3 switching on. Attention a) When put in battery, please set as battery box polarity indication, don’t put in different class battery b) After play, switch to the power switch to “ON”, avoiding waste power supply. c) When warn of low voltage, please change battery immediately. d) No work for long time, please take out battery , avoid leaking from battery to damage inner current.
