Summary of Contents for Bachmann LI1000
- Page 1 LI1000 Manual Bachmann GmbH Ernsthaldenstraße 33 70565 Stuttgart Germany Phone: +49 711 86602-0 Fax: +49 711 86602-34 E-Mail: info@bachmann.com Internet: www.bachmann.com 700.0000_User_Manual_REV02_EN created by BWS PM...
-
Page 2: Table Of Contents
Content General Safety Instructions ......................3 Intended Use ........................... 3 User requirements ........................3 Working area and enviroment ....................3 Safety-conscious state ......................4 Transporting..........................4 Storage ............................ 4 Cleaning, maintenance and repair ..................5 Other applicable documents ......................5 Technical overview ........................... -
Page 3: General Safety Instructions
1.1 Intended Use If the battery is passed on to third parties, these instructions must also be The battery LI1000 is only to be used with provided. BACHMANN approved devices. Any other use If anything is unclear: Contact is considered as improper use. -
Page 4: Safety-Conscious State
Safety-conscious state Transporting The LI1000 battery is in a safe condition if the following conditions are met: WARNING! The battery is undamaged. The battery is clean and dry. The battery is not protected against all The battery works and is unchanged. -
Page 5: Cleaning, Maintenance And Repair
Dangerous Goods Transport injured. Regulations Clean the battery as described in this Manuals and safety information on manual. BACHMANN's independent systems can be found on the Internet at: https://www.bachmann.com/en/downloads/tech WARNING! nical-documents/ If the battery is not serviced or repaired... -
Page 6: Technical Overview
Technical overview Technical data LI1000 Electrical parameters Charging voltage 29,4 VDC Battery capacity 950 Wh Battery cell type Li-Ion Power output Output 1: Unregulated output voltage 20-29 VDC Output current 12 A 1) Push button Output 2: Switches the battery on and off and... -
Page 7: Dimensions
permanently indicates the remaining charging Dimensions capacity during operation. The outputs of the battery are enabled, voltage is applied to the outputs. Switching the battery off To turn off the battery, follow these steps: Switching the battery on and off Switching the battery on The battery can only be switched on if it is completely inserted in the docking station and... -
Page 8: Charge The Battery
Display state of charge Charge the battery While the battery is not in the docking station Charge the battery or during charging, the current charging status can be displayed. To charge the battery, follow these steps: Connect the charger to the socket ... -
Page 9: Performing A Battery Firmware Update
Approx. 15 seconds after pressing the reset 11. Storage button, the push button flashes white three times. The firmware update was completed For optimal storage BACHMANN recommends successfully. storing the battery at a state of charge of approx. 50% (5 blue LEDs). -
Page 10: Transportation
• Contact BACHMANN Customer The battery is separate from Service and request a return. other devices or chargers. BACHMANN GmbH will send you • The battery is in an electrically non-conductive transport packaging non-conductive package. • for return, as an alternative you can... -
Page 11: Customer Service
The operating although the temperature limits may have Contact: display shows been exceeded. Restore the Customer service BACHMANN > 0 % charge permissible operating state (SOC) conditions and allow the BACHMANN GmbH battery to rest for a certain period for reconditioning.
