INSTRUCTION MANUAL

TABLE OF CONTENTS:

 TECHNICAL SPECIFICATIONS
 TECHNICAL SPECIFICATIONS:
Drill chuck:
SPEED (NO LOAD):
SCFM Requirement:
Working pressure:
Air inlet:
SCFM: Standard Cubic Feet per Minute (the volumetric flow rate of a far corrected to standardized conditions of
temperature and pressure).
NPT: National Pipe Thread
Environmental Responsibilities
Please recycle unwanted materials instead of disposing of them as waste. All tools, hoses and packaging should be sorted,
taken to the local recycling centre and disposed of in an environmentally safe way.
AIR-POWERED DRILL
RP27101
IMPORTANT:
Upon receipt of the product, read and follow all safety rules,
operating instructions before first use it.
future reference.
3/8"
Air hose required:
1800RPM
Weight:
3.8@90PSI
90PSI(6.3Bar)
1/4"(6.4mm)
And retain this manual for
2018
3/8"(9.52mm)
2.58Lb(1.17kg)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP27101 and is the answer not in the manual?

Questions and answers

Related Manuals for Rongpeng RP27101

Summary of Contents for Rongpeng RP27101

  • Page 1: Table Of Contents

    INSTRUCTION MANUAL AIR-POWERED DRILL RP27101 IMPORTANT: Upon receipt of the product, read and follow all safety rules, operating instructions before first use it. And retain this manual for future reference. TABLE OF CONTENTS: 2018  TECHNICAL SPECIFICATIONS  SAFETY GUIDELINES ...

  • Page 2: Safety Guidelines

     SAFETY GUIDELINES: DANGER! Potential hazard that will result in serious injury or loss of life. WARNING Potential hazard that could result in serious injury or loss of life. CAUTION! Potential hazard that may result in moderate injury or damage to equipment. NOTE: The world “Note”...
  • Page 3 failure.  Do not overload the tool. Allow the tool to operate at its optimum speed for maximum efficiency. Excessive overload can cause the tool casing to split, and may also lead to excessive wear on moving parts and possible failure. ...

  • Page 4: Key Parts Diagram

    General usage description The RONGPENG Air-powered Drill is a heavy-duty reversible air drill featuring a quiet design, speeds from 1200 to 1700 RPM, and a 3/8" chuck. No matter what the job entails, this drill will help you conquer whatever the day brings. Applications for this air drill include: home improvement projects, body work installation and repair, farm implement assembly and repair, general equipment, auto repair and maintenance, boat repair, truck repair and more.

  • Page 5: Operating Instructions

    CAUTION! Potential hazard that may result in moderate injury or damage to equipment.  Verify that all connections in the air supply system are sealed in order to prevent air from leaking. Failure to comply will result in moderate injury or damage to equipment. Read this instruction manual thoroughly or have tool operators read thoroughly before using the tool.

  • Page 6: Maintenance

     MAINTENANCE WARNING! Potential hazard that will result in serious injury or loss of life.  Disconnect the tool from the air supply before changing accessories, servicing, or performing maintenance.  Only use the tool after replacing or repairing the damaged parts or accessories. ...

  • Page 7: Troubleshooting

     TROUBLESHOOTING The following chart lists common issues and solutions. Please read it carefully and follow all instructions closely. WARNING! Potential hazard that will result in serious injury or loss of life.  If any of the following symptoms appear while the tool is in use, turn it off and disconnect it from the air supply immediately.

  • Page 8: Exploded View

     EXPLODED VIEW  PARTS LIST Description Qty. Description Qty. Description Qty. Bolt M5 x 20 Rotor blade O-ring 11.5 x 1.8 3/8" Chuck Cylinder Reverse valve Gasket Steel wire Copper pipe Connector Rear end plate O-ring 12 x 3 Ball bearing 6201ZZ Sealing ring O-ring 4 x 1.1...
