Page 1
User and Installation Guide 5.8 GHz DIGITAL Wireless Audio Transmitter / Receiver Model 15 0...
Page 2
User and Installation Guide Unpacking: Check that this package contains: One 5.8 GHz Digital Audio transmitter, one 5.8 GHz Digital Audio receiver, two AC adapters, two dual RCA audio cables. Step 1 Connecting the transmitter The transmitter connects to a line-out interface via the supplied RCA cable. Most audio devices provide a line-out interface.
Page 3
RangeBooster transmitters is suggested. These RangeBooster transmitters are available as an accessory for your 5.8 GHz Digital Wireless Audio Transmitter / Receiver from Amphony and can be located in areas where signal reception is difficult. RangeBooster transmitters connect to the DATA OUT output of the transmitter via a cable and receive the signal in a digital format without any degradation.
Page 4
User and Installation Guide Step 3 Connecting the receiver The receiver connects to a line-in interface via the supplied RCA cable. Most audio devices, such as amplifiers, provide a line-in interface. If no line-in interface is available, the receiver can also be connected to other audio inputs by using an appropriate adapter.
Page 5
User and Installation Guide Step 4 Operating the transmitter and receiver After powering up the transmitter, the transmit light will light for approximately 5 seconds while the transmitter initializes. After initialization, the transmit light will go out. Once audio is detected at the audio input, the transmit light will light and the transmitter will transmit the audio signal.
Page 6
Receiver audio level Lower the receiver output level too high by using an attenuator, or use another audio input. For more information, including a detailed troubleshooting guide, visit the Amphony web site at: www.amphony.com Page 5...
Max. receiver output voltage level: 1 Vrms Receiver noise shaping filter for maximum signal-to-noise ratio Copyright (C) 2005 Amphony. All rights reserved. The information contained herein is subject to change without notice. Revisions may be issued to advise of such changes and/or additions.
This warranty extends only to the original user of the equipment (“you”, ”your”) and is limited to the purchase price of each part. Amphony and it’s affiliated companies (”we”, ”our”, ”us”) warrant this Wireless Transmitter / Receiver Set against defects in materials or workmanship as follows.
