- Page 1 THORNTON Part No. 84428 Leading Pure Water Analytics Total Organic Carbon Analyzer Instruction Manual...
- Page 2 IMPORTANT SAFETY INFORMATION Please read and observe the following: INSTALLATION: This instrument must be installed by trained instrumentation personnel in accordance with relevant local codes and instructions in this manual. Observe all instrument specifications and ratings. SHOCK HAZARD: Make sure power to all wires is turned off before proceeding with installation or service of this instrument.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER 1: GETTING STARTED ................5 INTRODUCTION......................5 PRINCIPLE OF OPERATION ..................6 CHAPTER 2: INSTALLATION / SET-UP................ 8 LOCATION ......................... 8 ELECTRICAL CONNECTIONS.................. 8 SAMPLE TUBING CONNECTIONS................8 ANALOG OUTPUT..................... 9 ALARMS........................9 USER INTERFACE/PRINTER ................... 9 START-UP ....................... - Page 4 VIEWING SENSORS ....................37 TOC CURVE ......................38 APPENDIX A ........................ 40 KEY/DISPLAY FUNCTIONS ..................40 SYSTEM CHECK SEQUENCE ................41 550 OPERATION CHART - Measurement Mode............. 42 550 OPERATION CHART - Setup Mode ..............43 550 OPERATION CHART - Setup Mode (Maintenance menus)......44 550 OPERATION CHART - Maintenance Mode (Other Setup menus)....
-
Page 5: Chapter 1: Getting Started
It is evident that a fast response, easy to operate and maintain, device has recognizable benefits for the user. The Thornton 550 Total Organic Carbon Analyzer provides a faster and easier method of on line measurement. As its predecessor, the 502P, the 550 TOC analyzer units offers the widest dynamic water quality range that can be measured without cumbersome reagents or accessories. -
Page 6: Principle Of Operation
PRINCIPLE OF OPERATION The Thornton 550 TOC Analyzer measures Total Organic Carbon in pure and ultrapure water based on differential conductivity. This difference in conductivity is used to determine the amount of organic carbon present. Flow Pressure Flow UV Oxidation... - Page 7 residence time in the oxidation chamber of less then one minute. The conductivity measurements are continuous; therefore, response time is directly related to the residence time of the sample in the oxidation chamber. Values of TOC, resistivity (or alternatively conductivity or uncompensated conductivity), and temperature are displayed on the LCD screen of the instrument.
-
Page 8: Chapter 2: Installation / Set-Up
CHAPTER 2: INSTALLATION / SET-UP LOCATION The Thornton 550 TOC Analyzer is to be installed in a dry environment with a relative humidity <80% (non-condensing) and with ambient temperature between 5 and 40°C (41 to 104°F), on a flat, horizontal surface. The sample inlet line should be fitted with an isolation valve. -
Page 9: Analog Output
Communication specifications for this port: 9600 baud; 1 stop bit; no parity; 8-bit data. Mettler-Toledo Thornton, Inc. supplies a small format thermal printer as an optional accessory. A straight-through 9 pin, male or female, sub-D cable is provided with this printer. -
Page 10: Start-Up
Observe the flow rate from the flow meter on the front panel of the Thornton 550 TOC Analyzer. Adjust the flow rate to the maximum setting by means of the flow adjustment knob, located at the top of the flow meter. If not... - Page 11 After rinsing, use the flow adjustment knob to set the flow to 20 ml/min. CAUTION: Even if no pressure adjustment is required (which is the usual case); the cover should be removed so that the analyzer can be checked for water leaks, as any leak could be a source of error in the readings and also could lead to damage or failure of the unit.
-
Page 12: Chapter 3: Configuration
CHAPTER 3: CONFIGURATION The unit can be configured before or after installation as described in Chapter 2. When the unit is first powered, the following “TITLE” display will be seen. THORNTON 550 TOC Analyzer Ver 1. XX Menus Save Next... -
Page 13: User Setup And Configuration Menus
‘0000’, (all zeros). The password can be configured for a personalized four-digit password from the Maintenance Menus. Otherwise pushing the Menus key from the Title screen will display the main menus. THORNTON 550 TOC ANALYZER Ver 1.XX Push MENUS key to enter the password screen as shown below:... -
Page 14: Calendar
Push the NEXT key to view the 2 page of the main menus as shown here: 5. *PRINT SETUP 6. ANALOG SETUP 7. ANALOG CALIB 8. UV TIME Push the NEXT key again to see the 3 main menus as shown here: 9. -
Page 15: System Name
Otherwise, configure outputs as described in the sections below. ALARM SETUP, CODES, and SETPOINTS The Thornton 550 has two independent relay alarms. Each can be configured for one of the three measurement parameters on the display. Choose the parameter and set point. -
Page 16: Alarm-X(1 Or 2) Mode Configuration
ALARM-X (1 OR 2) MODE CONFIGURATION ITEM Select output parameter ppb = TOC Mohm = Resistivity °C = Temperature of sample water ERset = Error None = no output RELAY Definition of relay activation Low Off = Relay off at lower than set point Low On = Relay on at lower than set point High Off = Relay off at higher than set point High On = Relay on at higher than set point... -
Page 17: Analog (4-20 Ma) Output
up key. Press enter. Note: Changing Print-T unit will reset the print time to 01. Press the esc key twice to return to the title screen. ANALOG (4-20 mA) OUTPUT In the MAIN menus, 2 screen, Select: 6. 4-20 mA SETUP ANALOG SETUP Output = *ppb... -
Page 18: Measurement Display
MEASUREMENT DISPLAY The user has the option of displaying the measurement value of the incoming water sample as resistivity, conductivity, or (temperature) uncompensated conductivity. To change from the default value of resistivity: Go to MEASURE PARA 2, choose 12: MAINTENANCE, Then move the asterisk to 11. Other Setup. -
Page 19: Printout Of Configuration Database
ADVANCED CONFIGURATION. For any application outside the normal operating parameters, please consult Mettler- Toledo Thornton, Inc. technical support department. PRINTOUT OF CONFIGURATION DATABASE A printer attached to the printer port can be used to print out the configuration database. -
Page 20: Chapter 4: Demonstration Mode
CHAPTER 4: DEMONSTRATION MODE The Thornton 550 can be run in the Demonstration Mode to illustrate and allow practice in changing some of the parameters prior to actual use of the instrument. While the measurement value cannot be changed, other parameters, such as alarm set points, can be altered. -
Page 21: Chapter 5: Operation
CHAPTER 5: OPERATION POWER ON Turn on the power at the switch on the rear panel of the Analyzer. THORNTON TITLE Screen will appear as shown. High 550 TOC Analyzer temperature units display 550-HT and SX units Ver x.xx display 550-SX. -
Page 22: Trend Data Clear
From the above screen, the Measurement Trend Check Mode can be accessed with ENTER. The past record of measurement values can be accessed with UP/DOWN. Pressing ENTER again will show the three most current readings on the display. 255 Lines of data are stored. The values are TIME TOC RES 10:30* 75.2... -
Page 23: Alarm Setpoint Screen
Select Nr. Of Data using the DOWN key and press ENTER. Move the cursor using the NEXT key and change to the desired number of most recent data lines you wish to print with the UP/DOWN keys. Press ENTER. Next, select History Write using the UP key, press ENTER and toggle ON using the UP/DOWN keys. -
Page 24: Error Codes
ERROR CODES Message Fault Cause SYSTEM CHECK Unable to measure TOC Differential between sensors FAILED before UV oxidation is too great ERROR 02 Unable to measure TOC Conductivity of sample water is greater than 20 µS/cm ERROR 03 Sensor 1 error Sensor 1 cable not connected, or sensor fault ERROR 08... -
Page 25: End Measurement
Using the NEXT key, select MEASURE PARA 2 screen (fourth screen in ‘Other Setup’ menu) and select Sensor Status using the DOWN key. 4. MEASURE PARA2 Change Sensor Status from 0XXX to 1XXX RESERVE 0000 by pressing ENTER and UP keys. RESERVE 0000 Refer to ADVANCED CONFIGURATION for... -
Page 26: Chapter 6: Maintenance
CHAPTER 6: MAINTENANCE LAMP REPLACEMENT The only maintenance that is required on a regular basis is replacement of the UV lamp. When the lamp usage time has reached 4,000 hours, a UV lamp alarm appears on the display. At some point after 4,000 hours, the UV radiation will gradually degrade and eventually will affect the validity of the measurement. - Page 27 UV TIME UV ON TIME = 0020 UV CHG TIME = 4000 UV TIME CLR = *OFF • Press ENTER and toggle UV TIME CLR to ON using the UP/DOWN key and press ENTER. UV ON TIME will reset to 0000. •...
-
Page 28: Chapter 7: Calibration
CHAPTER 7: CALIBRATION Four aspects of Calibration are covered in this section. • Analog Output Calibration. This procedure is used to calibrate the analog output loop. • Auto Zero Calibration. This is a procedure, performed by the monitor itself, to obtain zero readings of the two TOC sensors and correct for any zero drift. -
Page 29: Auto Zero Calibration
BOARD CALIBRATION This section describes a procedure to verify the functionality and accuracy of the electronics within the instrument. The Thornton 550 TOC Analyzer has two sensors for TOC measurement and one sensor for measurement of the incoming water sample. - Page 30 Stop the measurement and remove the top cover. CAUTION: POWER IS LIVE DURING THIS PROCEDURE. Press Menus and select 12. MAINTENANCE using the NEXT and UP/DOWN keys. Press ENTER and change pass word (Factory default is 0000) using the UP key. Press ENTER and select 4. Board Calib in MAINTENANCE 2/4.
- Page 31 Figure 2 (Printed Circuit Board) MΩ (S3) 4 kΩ (S1) 100 kΩ Assembly A and B (S2) After inserting the resistor assemblies as shown above, press ENTER to result in these displays: BOARD CALIBRATION BOARD CALIBRATION S1S2 ∅Rc S1S2 ∅Rc TH ! ∅R ∅R...
- Page 32 Remove Assembly C from the S3 connection and replace with Assembly D (see Figure 4): Figure 4 (Printed Circuit Board) MΩ (S3) 2 MΩ (S1) 100 kΩ Assembly D (S2) Press ENTER resulting in the following display: BOARD CALIBRATION BOARD CALIBRATION S1S2 ∅Rc S1S2 ∅Rc ∅Rc...
-
Page 33: Measurement Verification/Calibration
Thornton 770MAX system. The measuring point of the 770MAX should be close to the connection point for the Thornton 550. TOC verification/calibration can be performed a number of ways. - Page 34 A second, more extensive TOC calibration, subjects the test unit to a known TOC level. A sample is prepared by adding some suitable reagent into low TOC water, to prepare a sample with known TOC level. Run the calibration sample through the unit until stable readings are achieved. The instrument value can be adjusted in the following manner.
-
Page 35: Chapter 8: Advanced Configuration
CHAPTER 8: ADVANCED CONFIGURATION ADVANCED START UP METHODS The CONFIGURATION and OPERATION methods described previously should be adequate for pure and ultrapure waters (resistivity generally in the 10-18 MΩ-cm range) with relatively low levels of TOC. However, at higher levels of TOC, such as encountered in some Reverse Osmosis product water, recycle, and reclaim rinse water, an advanced configuration technique may be necessary for proper operation. - Page 36 OTHER SETUP WRITE NOTE: Changing the WRITE OFF to ON will allow changes to be the factory settings within the ‘OTHER SETUP’ menu screens. This should only be turned to ON if changes are being made. Using the NEXT key select INITIALIZE CHANGE screen. 2.INITIALIZE CHANGE Calib.
-
Page 37: Viewing Sensors
If the resistivity of the incoming water is 10 MΩ-cm or above, the System Check not passing indicates there is a problem, and the screen will display “SYSTEM CHECK FAILED.” If this occurs, turn the unit off, then on again, and push the START button to once again initiate the System Check sequence. -
Page 38: Toc Curve
CAUTION: PRESSING THE MENUS KEY WHILE IN SENSOR VIEW, WILL TURN ON THE UV LAMP. THIS FUNCION EXISTS AS A MAINTENANCE TOOL AND IS INTENDED FOR USE BY AUTHORIZED THORNTON SERVICE PERSONNEL ONLY. TOC CURVE In Sensor View screen 3 / 4, the display shows the TOC Curve designation used to determine the TOC value measured by the analyzer. - Page 39 In certain circumstances, this Factory default may be changed. These are special cases where a sample water may contain known levels of specific organics, in which case a different curve designation may be entered. This alteration will require factory support and should only be performed by factory trained and certified personnel. ADVANCED CONFIGURATION...
-
Page 40: Key/Display Functions
APPENDIX A KEY/DISPLAY FUNCTIONS MAJOR FUNCTION FUNCTION FUNCTION MODE WHEN UNIT IS WHEN UNIT IS IN FUNCTION WITHIN ITEM 12. MEASURING TOC STANDBY MAINTENANCE MENUS START/ Start or Stop Stop Measuring Start Measuring Measuring TOC STOP Push to enter setup Push to enter setup Push to enter setup - Turns UV lamp... -
Page 41: System Check Sequence
SYSTEM CHECK SEQUENCE Push START key Push Start/stop Key and Enter Key Simultaneously Wait 3 minutes to stabilize S2-S1 value Sets |S1-S2| = 0 |S1-S2| < CalibNo.1 (See Table in Chap 8) SYSTEM CHECK PASS Wait for 1 minute UV ON Wait for 2 minutes Check 3 Times TOC measurement displayed... -
Page 42: 550 Operation Chart - Measurement Mode
550 OPERATION CHART - Measurement Mode MEASUREMENT MODE Flowchart shows Start-up (System Check) sequence and menu screens available during Measurement Mode PRESS MENUS Key THORNTON 550 TOC Analyzer To Main Menus page Ver x.xx START/STOP Setup Parameter Select UP Key (Parameter Select) -
Page 43: 550 Operation Chart - Setup Mode
550 OPERATION CHART - Setup Mode Up Key....Numerical Change Back to Measurement Mode or Title Screen (press ESC key once) DOWN Key....Numerical Change NEXT Key.....Move the Cursor ENTER Key...Confirm the Set SETUP MODE Numerical Value Alarm 1 Setup From Measurement Mode or Title Screen Item = Chooses parameter to alarm on. -
Page 44: 550 Operation Chart - Setup Mode (Maintenance Menus)
550 OPERATION CHART - Setup Mode (Maintenance menus) Back to Measurement Mode or Title Screen (Press ESC key twice) MAINTENANCE MODE To MAIN MENUS SCREEN From MAIN MENU SCREEN 3/3 Playing Demo DEMO Mark Password Input Password Input Password 0000 (0000 is Factory Default) Sensor View 3/4 Sensor View 1/4... -
Page 45: 550 Operation Chart - Maintenance Mode (Other Setup Menus)
550 OPERATION CHART - Maintenance Mode (Other Setup menus) Back to Measurement Mode Other Setup Menus (Press ESC key three times) TOC Curve configuration From previous page 1. TOC Curve TOC Curve FLOW Rate Full Oxidation NEXT Initialize Limit Setup (For Factory or Service use only 2. -
Page 46: Optional Printer Dip Switch Settings
OPTIONAL PRINTER DIP SWITCH SETTINGS Dip Switch Settings for optional Printer model: Seiko DPU414 Software DIP SW1: Switch Function Setting Meaning Input Method Serial Printing Speed High Auto loading CR function Carriage return DIP SW setting command Enable Print Density 100% Print Density 100%... -
Page 47: Specifications
SPECIFICATIONS 5-40 °C / 5-80% RH Non-condensing Ambient Temp/Humidity Location Industrial Environment (Indoor) Display LCD with back-light, displays TOC, resistivity, temperature, and operation/error indications Analog outputs One 4-20mA DC, Output is selectable for TOC or resistivity or temperature Outputs Alarm outputs Two SPDT contacts for Hi-Alarm, Lo-Alarm and Error Rated 0.4A @ 120VAC, 2.0A @ 30VDC Alarms displayed... -
Page 48: Accessories And Replacement Parts
ACCESSORIES AND REPLACEMENT PARTS Part No. Description 139-003 Thermal Printer, Serial Interface, 6VDC (Supplied with power cord, interface cable with connectors and manufacturers user’s manual.) 139-005 Resistor Kit, Board Calibration (550 and 552-HT models) 139-007 Resistor Kit, Board Calibration (550-SX model only) 129-010 Replacement UV Lamp, 185 nanometer 129-002... -
Page 49: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY We, Mettler-Toledo Thornton, Inc., 36 Middlesex Turnpike, Bedford, MA 01730 hereby declare, in conjunction with the original equipment manufacturer that all 550 TOC Analyzers to which this declaration relates, is in conformity with the following European, harmonized and published... -
Page 50: Declaration Of Csa Compliance
DECLARATION OF CSA COMPLIANCE Declaration of CSA Compliance Mettler-Toledo Thornton, Inc., 36 Middlesex Turnpike, Bedford, MA 01730 hereby declares that all 550 TOC Analyzers are eligible to bear the official CSA Mark, as shown below, with the adjacent indicators ‘C’ and ‘US’ and a Certificate of Compliance from the Canadian Standards Association has been issued and is on file. -
Page 51: Warranty
Catalog descriptions, although accurate, should not be taken as a guarantee or warranty. Mettler- Toledo Thornton’s obligation under the warranty shall be to repair at its facility or replace any products which Mettler-Toledo Thornton finds to be defective. Items returned for warranty must be properly packaged, shipped prepaid and insured, and must be accompanied by a Return Materials number assigned by Mettler-Toledo Thornton Customer Service. - Page 52 Mettler-Toledo Thornton, Inc. Toll-Free: 800-510-PURE 36 Middlesex Turnpike Fax: 781-271-0214 Bedford, MA 01730 info@thorntoninc.com (781) 301-8600 Part 84428 www.thorntoninc.com Rev. A 11/03...
