Encore Hartco RAC-1003 Operating Manual

Pneumatic c-ring closure tools

Advertisement

Quick Links

C-Ring Tools
1/2" RAC-1003 and 3/4" RAC-1001, RAC-1002, RAC-1004
3/4" C-Ring
Closure Tool
RAC-1001
3/4" C-Ring Tool
with Tight Closure
RAC-1002
3/4" C-Ring
Closure Tool
with Extended Nose
RAC-1004
2019-03-19
1/2" C-Ring Closure
Tool RAC-1003
Use with Encore Hartco C-Rings
3/4" 15 ga: RC1001, RC1003, RC1004
3/4" 16 ga: RC1005, RC1006,
RC1009
1/2" 16 ga: RC1007,
RC1008
www.encorehartco.com
info@encorehartco.com
Northbrook, IL 60062 U.S.A.
Phone: (224) 723-5524
Fax: (224) 723-5526
OPERATING
MANUAL
ENCORE HARTCO
PNEUMATIC
C-RING CLOSURE
TOOLS
BLACK components
RAC-1003
(Standard)
For 1/2" C-Rings
RAC-1001
(Standard)
For 3/4" C-Rings, in 16 or 15 gauge
RAC-1002
(Tight Closure)
For 3/4" C-Rings, in 16 or 15 gauge
RAC-1004
(with
Extended Nose)
For 3/4" C-Rings, in 16 or 15 gauge

SAFETY INFORMATION

READ THE ENTIRE
MANUAL BEFORE
OPERATING THE TOOL.
SAFETY GLASSES
should always be
worn while operating,
maintaining, or
repairing a tool, or in the vicinity of
a tool in operation.
KEEP HANDS AND
FINGERS AWAY from the
front of jaws area and
all moving parts when operating
or connecting air supply to tool.
Never actuate tool when loading.
Serious injury may result.
DISCONNECT THE AIR SUPPLY
when mechanically clearing a jam,
performing maintenance or repairs,
and whenever the tool is not in use.
mAINTAIN AIR PRESSURE at
85–120 PSI (6–8 BARS) using 1/4"
(6.35mm) ID air hose. Higher
pressure may damage tool.
INJURY PREVENTION—Operate
tool in an unobstructed work area.
Keep others at a safe distance.
Never point the tool toward
yourself or anyone else.
Never use oxygen,
carbon dioxide or any
other bottled gas as a
power source for this
tool—the tool will explode and
cause serious injury.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RAC-1003 and is the answer not in the manual?

Questions and answers

Summary of Contents for Encore Hartco RAC-1003

  • Page 1: Safety Information

    OPERATING C-Ring Tools MANUAL 1/2” RAC-1003 and 3/4” RAC-1001, RAC-1002, RAC-1004 ENCORE HARTCO PNEUMATIC C-RING CLOSURE TOOLS BLACK components 3/4” C-Ring Closure Tool RAC-1003 (Standard) RAC-1001 For 1/2” C-Rings RAC-1001 (Standard) For 3/4” C-Rings, in 16 or 15 gauge RAC-1002 (Tight Closure) For 3/4”...
  • Page 2 C-Ring Tool Models RAC-1001, RAC-1002, RAC-1003, RAC-1004 Parts and assemblies called out in have “mODEL SPECIFIC” components. No. 206 Magazine Assembly 73, 75, 76, 77, 82, 83 No. 200 Housing 23, 27, 28 No. 202 Blade Assembly 47, 48, 49 No.
  • Page 3 C-Ring Tool Models: RAC-1003 and RAC-1001 (1/2”), (3/4”) RAC-1002 and RAC-1004 (3/4”) (3/4”) UNIVERSAL PARTS MODEL-SPECIFIC PARTS Part # Description EHC01001 Set Screw 1/2” 3/4” 3/4” Tight 3/4” Extend EHC01003 Lock Washer Standard Standard Closure Nose Description EHC01004 Air Deflector...
  • Page 4: Trouble Shooting

    C-RING TOOL OPERATING INSTRUCTIONS TO GET STARTED When working with the tool, lways take care to put it down lightly to avoid damaging the body or the magazine. Do not drop the tool! Install a ¼” NPT fitting (not included) into air inlet opening in the bottom of Tools not operating properly should be removed from service at once and the housing assembly (#27 on page 2), using suitable thread sealant.
