Summary of Contents for ASTEL MXU01
- Page 1 MXU01 DMX512 INTERFACE Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Preface ..............................3 Features ..............................3 Precautions ............................3 Controls and Connectors ........................4 DMX512 Interface MXU01 ......................4 Installation ............................. 5 Set-up ..............................6 Appearance ............................8 Technical Specifications ........................8 Warranty ............................... 9 Declaration of Conformity ........................10... -
Page 3: Preface
PREFACE PRECAUTIONS The DMX512 Interface MXU01 has to be The MXU01 is DMX512 to ASTEL protocol converter with 1 output to control a groups of installed and used in accordance with the RGB multi-color lights of EQUATOR series instructions of this manual only. -
Page 4: Controls And Connectors
Control output to connect the +Control (P) and GND Control (-) wires of multi-color RGB lights EQUATOR series or PWM dimmer MDU13. (3) CONTROL The 3-pole terminal block connector to connect DMX512 line. (4) DMX SETTINGS DIP-switch to set the DMX512 and ASTEL protocol commmunication parameters. -
Page 5: Installation
INSTALLATION The DMX512 Interface MXU01 kit consists of the following components: DMX512 Interface MXU01 3 x terminal-block connectors Operating Instructions with Declaration of Conformity and Warranty conditions The MXU01 has to be installed on a suitable location. -
Page 6: Set-Up
SET-UP The DMX512 Interface MXU01 set-up is enabled by adjusting the DIP-switch. 1 2 3 4 5 6 7 8 9 10 11 12 DIP-switch VALUE 1-2-3-4-5-6-7-8-9 DIP-switch VALUE OFF-OFF-OFF-OFF-OFF-OFF-OFF-OFF-OFF 1-2-3-4 ON -OFF-OFF-OFF-OFF-OFF-OFF-OFF-OFF OFF-OFF-OFF-OFF ON –OFF-OFF-OFF ON –ON -OFF-OFF-ON -OFF-ON –ON -OFF OFF-ON –ON –ON... - Page 7 Speed mode Defines the ASTEL protocol communication baud rate. Value FUNCTION LOW speed – 1200 bps MID speed – 2400 bps HIGH speed – 4800 bps Number of addressable lights This defines how the OUT is acting. There are two basic modes: -non addressable –...
-
Page 8: Appearance
Programming the light address The set up procedure: 1. Connect the light to the DMX512 interface MXU01 2. Connect the light to the power supply 3. Switch-on the light – the light must light! 4. Switch-off the light – the light must NOT light! 5. -
Page 9: Warranty
WARRANTY 1. The equipment manufactured by ASTEL d.o.o. is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. -
Page 10: Declaration Of Conformity
DECLARATION OF CONFORMITY according to IEC Guide 22 and EN 45014 Manufacturer's Name: ASTEL, Podjetje za projektiranje, proizvodnjo in trgovino, d.o.o. Manufacturer's Address: Dutovlje 138 6221 Dutovlje Slovenija declares that the products Item, Product Name and Model Number: 1. DMX512 Interface MXU01... - Page 12 ASTEL d.o.o., Dutovlje 138, 6221 Dutovlje, Slovenia Tel: +386 5 7310771, +386 5 7310772 Fax:+386 5 7310789 info@astel-marine.com E-mail: www.astel-marine.com Web:...
