Summary of Contents for RF Technologies 9450
- Page 1 Baby Check Transmitter User Guide 0510-1124-A...
- Page 2 Users must read this Guide before using the Product Copyright 2015 by RF Technologies, Inc. All Rights Reserved. No Part of this work may be reproduced or copied in any form or by any means without written permission from RF Technologies, Inc.
- Page 3 RF Technologies, Inc. Parts and accessories not manufactured or recommended by RF Technologies, Inc. may not meet the requirements of the applicable safety and performance standards. Failure to use the components and supplies specified by RF Technologies, Inc.
- Page 4 Technologies, Inc. recommends quarterly inspections of your system for safety and performance by a qualified RF Technologies, Inc. representative. To arrange for a quarterly inspection by RF Technologies, Inc., call our Technical Support Department at (800)-669-9946 or (262) 790-1771. Failure to provide regular inspection of these products may result in...
- Page 5 This includes regular inspection, testing, and cleaning. RF Technologies, Inc. recommends monthly maintenance and testing of your system. It is also recommended that your facility keep records of maintenance and test completions.
- Page 6 This device must accept any interference, including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by RF Technologies Inc. can void the user’s authority to operate the equipment. The term “IC” before the certification/registration number only signifies that the Industry Canada technical specifications were met.
-
Page 7: Table Of Contents
Contents Contents CONTENTS PREFACE ..................3 VERVIEW 9450 S ..................3 YSTEM ................4 NTENDED UDIENCE ........... 4 DDITIONAL ETAILED OCUMENTATION ............... 4 ONTACT NFORMATION ................4 RODUCT ARRANTY CHAPTER 1 .............. 5 HECK RANSMITTER Introduction ................5 Mounting of Baby Check Transmitter Wall Bracket ..... 6 Link a Baby Check Transmitter ........... - Page 8 Contents CHAPTER 3 ................. 17 HECK LARMS Mismatch Alarm..............17 Link Alarm ................18 LED T ..............18 ROUBLESHOOTING ............20 ISCHARGE ROUBLESHOOTING CHAPTER 4 ..............21 HECK RANSMITTER ............22 RANSMITTER LEARING EVICE Page 2 of 22 Baby Check Transmitter User Guide 0510-1124-A...
-
Page 9: Preface
Preface Overview This guide provides important information about the Baby Check transmitter, a component of the 9450 System. It provides detailed instructions about using the transmitter as well as specific requirements. 9450 System The 9450 System monitors doors, elevators, hallways, and stairwells, to assist staff in monitoring patients and assets in a facility. -
Page 10: Intended Audience
Preface WARNING: The 9450 system is designed and intended to work in conjunction with a facility’s overall patient security program, including reasonable operating policies and procedures. The 9450 system, by itself, cannot prevent the mismatch, abduction, or elopement of patients. -
Page 11: The Baby Check Transmitter
Exit Receiver or the Baby Check transmitter. WARNING: The 9450 System Baby Check Match feature option is designed and intended to work in conjunction with a facility’s overall infant identification program, including identification bands and reasonable operating policies and procedures. -
Page 12: Mounting Of Baby Check Transmitter Wall Bracket
Chapter 1 Transmitters Mounting of Baby Check Transmitter Wall Bracket The Baby Check transmitter resides outside the Mother’s room near the doorway. To mount the Baby Check transmitter Determine a desired location near the doorway. The mounting height should be between 36 and 42 inches from the floor. Once the location is determined place the mounting bracket on the wall and mark the four mounting holes found in the four corners of the mounting bracket. -
Page 13: Link A Baby Check Transmitter
Chapter 1 Transmitters Link a Baby Check Transmitter This section provides detailed information on how to Link a Baby Check transmitter to an Infant transmitter. To Link a Baby Check transmitter When ready to Link the Baby Check transmitter with the Infant transmitter bring the Baby Check transmitter 10-12 inches from the Infant transmitter and press the button on the front of the Baby Check transmitter. -
Page 14: Verify A Baby Check/Infant Match
Chapter 1 Transmitters Verify a Baby Check/Infant Match This section provides detailed information on how to determine if a Match exists between a Baby Check transmitter and an Infant transmitter. To Verify a Match When ready to verify a Match between the Baby Check transmitter and the Infant transmitter bring the Baby Check transmitter 10-12 inches from the Infant transmitter and press the button on the front of the Baby Check transmitter. -
Page 15: The Baby Check Transmitter
The Baby Check transmitter is lightweight and compact. Each transmitter is stamped with a warranty expiration date. This date indicates the date that RF Technologies’ warranty on that transmitter expires (the last day of the month stamped). If the warranty period has expired, discard the Baby Check transmitter immediately. -
Page 16: Clear A Baby Check Transmitter
Chapter 1 Transmitters Required weekly testing for transmitters in use NOTE: Transmitters in use must be tested at least weekly. Test the operation of transmitters in use weekly as described above. Visually inspect transmitters in use weekly for damage or loose parts. Verify on a weekly basis that the warranty expiration date stamped on transmitters in use has not expired. -
Page 17: Cleaning And Caring For A Transmitter
Chapter 1 Transmitters Cleaning and Caring for a Transmitter This section provides detailed information about cleaning and caring for a transmitter. To clean a transmitter after use CAUTION: Use of non-approved cleaners on transmitters can cause permanent damage to the transmitter and will void any and all warranties. -
Page 18: Approved Cleaners
Chapter 1 Transmitters Approved Cleaners Following is a list of an approved cleaners recommended for use when cleaning the transmitter. Approved Cleaners Airex 109A Isopropyl Alcohol Quest 256 Cavicide™ Neutral Quat 128™ Virex II-256 Quik Fill 920™ Health-Tec™ Sani-cloth HB (wipes) Hi-Tor Plus™... -
Page 19: The Transmitter Clearing Device
The Transmitter Clearing Device is available with a two year life expectancy. Each Transmitter Clearing Device is stamped with a warranty expiration date. This date indicates the date that RF Technologies’ warranty on that Transmitter Clearing Device expires (the last day of the month stamped). If the warranty period has expired, discard the Transmitter Clearing Device immediately. -
Page 20: Required Transmitter Clearing Device Testing
Chapter 2 Transmitter Clearing Device Required Transmitter Clearing Device Testing You must test each Transmitter Clearing Device prior to use to verify proper operation. WARNING: Do not use the transmitter tester on a Transmitter Clearing Devices whose expiration date has expired. Results may not be accurate. - Page 21 The transmitter tester requires a 9V battery. Retest the Transmitter Clearing Devices If it fails a second time, DO NOT USE THE TRANSMITTER CLEARING DEVICE and contact RF Technologies Technical Support Team at (800)669- 9946 or (262) 790-1771. Baby Check Transmitter User Guide...
- Page 22 Chapter 2 Transmitter Clearing Device This page intentionally left blank. Page 16 of 22 Baby Check Transmitter User Guide 0510-1124-A...
-
Page 23: Baby Check Alarms
Chapter 3 Alarms and Troubleshooting Chapter 3 Alarms and Troubleshooting Baby Check Alarms Baby Check alarms are High Priority alarms. They are displayed on the Safe Place Computer on the Map Screen in the right column. Mismatch Alarm How to Respond Ensure patient safety. -
Page 24: Link Alarm
Chapter 3 Alarms and Troubleshooting Link Alarm How to Respond Ensure patient safety. Move the Infant and Baby Check transmitters out of close proximity. Clear the alarm at the computer by selecting the Event Cause. Use the Clearing Device to Erase the Baby Check transmitter’s incorrect Link. - Page 25 Chapter 3 Alarms and Troubleshooting Baby Check Transmitter is in Link Mode 1 Amber The button on the Baby Check transmitter is pressed once to verify it is ready to be linked. The amber light signals Link Mode. Baby Check Transmitter Decodes 4 Signals and Links 3 Green Transmitter is successfully linked.
-
Page 26: Discharge Troubleshooting
Chapter 3 Alarms and Troubleshooting Discharge Troubleshooting If “Confirm Discharge” and “Require Mom/Infant match before discharge” are both enabled during configuration (refer to the Software Administrator Guide for your system), the following discharge procedure is standard from linked Baby Check/Infant transmitters. To discharge a linked Baby Check and Infant transmitter Perform a Baby Check/Infant match. -
Page 27: Baby Check Transmitter
32-122° Fahrenheit (0–50° Celsius) Composition Battery Life 2 year, Lithium Ion (non-replaceable) Depends on Model: Frequency 66 kHz 262 kHz FCC Compliant Regulations 9450-7066— 66 kHz TX Part Number 9450-7262—262 kHz TX Baby Check Transmitter User Guide Page 21 of 22 0510-1124-A... - Page 28 2 years Depends on Model: Frequency 66 kHz 262 kHz Banding Material FCC Compliant Regulations 9450-3066—Transmitter Clearing Device 66 kHz Part Number 9450-3262—Transmitter Clearing Device 262 kHz Transmitter Tester 9450-0050 Page 22 of 22 Baby Check Transmitter User Guide 0510-1124-A...
