- Page 1 LaserLight LT RD-1550 1.5” Remote Display TECHNICAL MANUAL (Version 1.0) P.O. Box 775 - Farmington, NH 03835 Tel: 603-755-3885 email: rmk@candscontrols.com www.candscontrols.com Authorized RLWS Distributor...
-
Page 3: Table Of Contents
Contents Introduction............................. 1 1.1 Overview ............... 1 1.2 Safety . - Page 4 6.3 Updating the Laser LT............31 6.4 Front Panel Display Characters .
-
Page 5: Introduction
Introduction ® This manual is intended for use by service technicians responsible for installing and servicing the Laser LT remote display. Installation procedures are presented in the order likely to be followed by the installer: pre-installation setup, configuration, and on-site installation. This manual can be viewed and downloaded from the Rice Lake Weighing Systems web site at www.ricelake.com . -
Page 6: Safety
Safety Safety Symbol Definitions Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death, and WARNING includes hazards that are exposed when guards are removed. CAUTION Indicates a potentially hazardous situation that, if not avoided may result in minor or moderate injury. Indicates information about procedures that, if not observed, could result in damage to equipment or Important corruption to and loss of data. -
Page 7: Annunciators
Annunciators The Laser LT remote display uses a set of six designated LED annunciators (shown in Figure 1-3) and a red and green (stop/go feature lights). The annunicators are dependent on the status character. They can also be associated with ASCII characters (tokens) and are shown in Table 4-1 on page 25 and the default status characters are shown in Table 3-2 on page 14. -
Page 8: Tokens
1.3.1 Tokens The Laser LT has tokens that can be used in the general formatting of a serial string. The Laser LT will light the status annunicators (tokens) based on the ASCII characters sent in the serial string. Those tokens are: •... -
Page 9: Installation And Setup
Installation and Setup The Laser LT remote display can be easily set up and configured. This section describes basic installation, AC wiring, RS-232 and 20mA current loop connections. Once installation setup is complete, go to Section 3.0 for information on configuring the Laser LT. Use a wrist strap to ground yourself and protect components from electrostatic discharge (ESD) when CAUTION working inside the enclosure. -
Page 10: Wiring
Wiring The Laser LT remote display provides two cord grips located on the underside of the enclosure for cabling; one for inputs, and one for outputs. An AC power cord is supplied with the unit. Only the serial communications cable must be connected. -
Page 11: Ac Wiring
2.3.2 AC Wiring The Laser LT AC power cord comes in through a cord grip to the AC to DC power supply. The DC then goes to J5 on the main CPU board (see Table 2-3 on page 9). Power Supply Figure 2-4. -
Page 12: Dc Wiring
2.3.3 DC Wiring Alternatively a 9-36V DC power converter may be supplied. To connect DC power to the DC to DC converter, wire the positive voltage to pin 1 (red wire - right hand side of connector), ground to pin 3 (black wire-left side) on CN1 DC power supply . -
Page 13: Serial Wiring
2.3.4 Serial Wiring Serial communications are connected to the CPU board using clamp spring connectors on J2, J3 and J4 (see Table 2-3 for wiring positions ). To connect the communications cable to the remote display, do the following: 1. If the enclosure is not open, make sure power is disconnected from the unit and open the latches on the enclosure. -
Page 14: Reset Switch
Communications Cable Distance Limitations The maximum cable lengths that can be used for various communications types depend on a number of factors. These include: output impedance of the transmitter, electrical noise in the environment; cable capacitance, gauge, termination, and shielding. Given that these and other factors will affect the maximum usable cable length, the following distances can be used as a general guide for the Laser LT communications cabling. -
Page 15: Commport Jumper
2.3.6 Commport Jumper The com port jumper (shown in Figure 2-7, upper right hand corner) is used when an option card is plugged into J7 on the CPU board (see Figure 2-9 for the J7 location). Available option boards include: •... -
Page 16: Configuration
Configuration Once the Laser LT remote display is installed, it may need to be configured. This can be done manually through the front panel and is explained in Sections 3.2 through 3.6. Using Auto-Learn (Section 3.1) simplifies installation by automatically detecting the communications format and data rate used by the indicator and may eliminate the need for configuration. -
Page 17: Manual Configuration
Manual Configuration To begin configuration, open the enclosure to access the CPU board (Figure 3-2). Setup Button Figure 3-2. Laser LT CPU Board The setup button is located on the CPU board (Figure 3-2).This allows access into Configuration Mode. Press the button to access main menu configuration parameters. - Page 18 CONFIG SERIAL TEST KEYPAD DIGIO VERS Figure 3-4. Laser LT Main Menu Flow Figure 3-5 shows the Configuration menu. CONFIG SERIAL TEST KEYPAD DIGIO VERS HOLD WT STDSTL NODATA LOCK SCHAR E CHAR LW POS SUPP 0 No Com 000000 Blank PRI CHR PRI LOC...
- Page 19 CONFIG Menu NO DATA No Com Laser LT Selects what to display when the is not receiving recognizable data - “NO COM” or Blank blank screen. LOCK Select On to make sure the current settings don’t get changed and to disable Auto-Learn. When off, the system enables Auto-Learn.
-
Page 20: Serial Communications
CONFIG Menu SP IND Select, decode status, and settings for special indicator types. None None Toledo Toledo or Fairbanks format SPECIAL NOTES: • If using a Metler Toledo indicator named something other than a numeric model, you may need to set to None •... - Page 21 Serial Menu Parameter Choices Description Port 1, 2, 3, and 4 BAUD Configure Ports 1, 2, 3, and 4. See Level 3 submenu parameter descriptions. DATA BITS STOP BITS ECHO HOST PORT 2 Allows the user to select which port is connected to the weight indicator or host PORT 1 device.
-
Page 22: Testing The Remote Display
Testing the Remote Display The Laser LT remote display provides a test menu to check the hardware of the remote display. These tests can be accessed through the main menu (Figure 3-7). KEYPAD DIGIO SERIAL TEST CONFIG VERS DISPLA STRTUP INTENS RESET Figure 3-7. -
Page 23: Digital I/O
Label Default Description KEYPAD 1 Zero ENABLE = ON Keypad strings are captured using the STRING = KZERO<13> following format for all 5 keys: KEYPAD 2 ENABLE = ON KEYPAD1.STRING = <KZERO<13> STRING = KGROSSNET<13> KEYPAD 3 Tare ENABLE = ON KZERO is a string which can be up to 32 STRING = KTARE<13>... -
Page 24: Demand Print Displaying
Demand Print Displaying The indicator and the Laser LT remote display can be set up to do a demand print display for such applications as cattle weighing. This is useful if you want to show and keep the last weight of an animal. Using Auto-Learn, ensure is on and continuously push the print button on the indicator to learn a demand HOLD WT... -
Page 25: Laser Lt Query Display Command
|<AA>GR<data>! Response: <State><CR> Where: | = Pipe character (0x7C) AA = Two byte address, ASCII digits (00-31) GR = Literal GR Data = 1 or 2 CR = Carriage return, (0x 0D) State = The state of the requested relay, possible responses: 1 = On 1 = Off 2 = On... -
Page 26: Configuration With Revolutionâ
3.10 Configuration with Revolution Revolution is a user-friendly tool for configuring the Laser LT using your PC. Revolution can be used to program and configure the Laser LT. Revolution can be downloaded from the Rice Lake Weighing Systems web site at:www.ricelake.com/support/ software/firmware/Revolution Scale Software. -
Page 27: Comm Ports
3.10.3 Formatting Configuration menu found in Figure 3-14 Keypad menu found in Figure 3-15 Information must be uploaded prior to using Digital I/O menu found in Figure 3-14 the Formatting screen in Revolution. With Revolution running and the new file screen shown (from Figure 3-14), select from Communications... - Page 28 Continue with all known characters and download this new data and the LaserLT should now display a proper weight with the available tokens. The below is a sample of Section Print. The parameters tell the LaserLT how to decode the stream. •...
-
Page 29: Edp Commands
EDP Commands The Laser LT remote display can be controlled by a personal computer or a remote keyboard connected to the remote display. Control is provided by a set of EDP (Electronic Data Processing) commands that can simulate front panel key press functions, display and change setup parameters and perform reporting functions. EDP commands are able to view or change the parameters either in Run or Configuration mode. - Page 30 Command Default Value Description NET.LOC This is the character location in the string format. A 0 (zero) indicates that the Laser LT will look for the character anywhere in the incoming data. The range is 0-63 PRI.CHAR 76 (L) Allows the user the select primary unit character PRI.LOC This is the character location in the string format.
-
Page 31: Parameter Setting Commands
Parameter Setting Commands The following table describes EDP parameter setting commands with descriptions and ranges. Command Choices Description DAISY This is the port that will echo the weight data to another remote display PORT 1 PORT 2 PORT 3 PORT 4 DIO1 Select which LED or front panel key function is controlled by this digital I/O REDLED... -
Page 32: Reporting Commands
Command Choices Description PORTS 1 THRU 4 BAUD = 9600 BITS = 8 NONE ECHO = ON SBITS = 1 STOP BIT KEYPAD 1 ENABLE = ON Keypad strings are captured using the following format for all 5 keys: STRING = KZERO<13> KEYPAD1.STRING = <KZERO<13>... -
Page 33: Options
Options Visor Installation An optional visor can be installed on the Laser LT display. Figure 5-1 shows the remote display with the optional visor installed. Figure 5-1. Laser LT Remote Display w/ Optional Visor Installed Mount the visor (PN 115138) on top of the remote display by opening the front cover, sliding the visor over the latch assembly and re-close the latches on the enclosure. -
Page 34: Appendix
Appendix Error Messages The Laser LT remote display provides error messages. When an error occurs, the message is shown on the display. Message Cause/Remedy NO COM No communication with the ports and the device that it’s communicating with ABORT Laser LT failed to Auto Learn. -
Page 35: Updating The Laser Lt
Updating the Laser LT If software needs to be updated for the Laser LT, the updater utility is available through Revolution. A flash update cable (PN 115968) must be used to connect the CPU board of the Laser LT to a port on your PC. Plug the flash update cable connector into the header TJ3 on the Laser LT CPU board and the other end into the Figure 6-1. -
Page 36: Front Panel Display Characters
Front Panel Display Characters Figure 6-3 shows the 7-segment LED character set used to display alphanumeric characters on the Laser LT front panel. Figure 6-3. Laser LT Display Characters LaserLight LT 1550 Technical Manual... -
Page 37: Replacement Parts
Replacement Parts 6.5.1 UL Approved Replacement Parts Figure 6-4. UL Approved Power Supply Parts Illustration Item No. Part No. Description 153811 Cable Assembly Power Supply to CPU 153600 Power Supply 12V 45Watt PLC-45-12 153808 AC Input Power Cord Assembly, GFCI Table 6-3. - Page 38 See Ground Detail Ground Detail LaserLight LT 1550 Technical Manual...
-
Page 39: Replacement Parts
Replacement Parts Table 6-1 lists selected replacement parts for the Laser LT remote display. Item No. Part No. Description 110384 Board Assembly, LED remote CPU 111848 Overlay, Laser LT 113535 Enclosure, Laser LT RD1550 113542 Power Suppy Cover, Laser LT 1550 113769 Lens 114019... -
Page 40: Laser Lt Enclosure Dimensions
Laser LT Enclosure Dimensions 14.00 12.75 11.85 4.88 7.70 7.50 4.18 LaserLight LT 1550 Technical Manual... -
Page 41: Specifications
Specifications Display Six digit LED, 7-segment character, 1.5 in height Six annunicators for GR, NT, LB, KG, Motion and COZ One Red, one Green light (serial or I/O controlled) Overlay with contrast filtered lens Optional visor for direct sunlight Input Interface Port 1 20mA bidirectional Port 2... -
Page 42: Laser Lt Remote Display Limited Warranty
Laser LT Remote Display Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for two years. - Page 44 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319 www.ricelake.com www.ricelake.mx www.ricelake.eu www.ricelake.co.in m.ricelake.com PN 114035 Rev C © Rice Lake Weighing Systems 02/2015...
