Summary of Contents for UNICOM CB-320
- Page 1 CB-320 TWO-WAY CB RADIO 3WATT INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
TO REMOVE THE BATTERY PACK ... 9 TO SCAN ..........15 TO REFIT THE BATTERY PACK ....9 SCANNING FEATURES ......15 CHARGING THE CB-320 SINGLE UNIT ........10 CTCSS AND DCS ......15 CHARGING THE BATTERY PACK ..10 MENU ........... -
Page 3: Safety Information
SAFETY INFORMATION SQUELCH LEVEL SETTING ....17 TRANSMITTER POWER ....... 17 The CB-320 is a radio transmitting device. DCS TONE CHART ......21 VOX SETTINGS ........18 y When transmitting, keep the antenna more than 25 mm from any part of the head POWER ON MESSAGE ...... -
Page 4: Emergency Channels
The above situations are not a fault of the radio but a symptom of operating wide- y ONLY use Unicom approved rechargeable battery packs with the supplied char- band and narrowband radios in the same bandwidth. This possible interference will ger. -
Page 5: Features
F2: Short press to turn FM radio ON/OFF. Long Press (1s) to activate Emergency Alarm. Alarm sound will stay ON and transmit through CH5. Turn the power OFF to stop this. PAGE 6 CB-320 INSTRUCTION MANUAL CB-320 INSTRUCTION MANUAL PAGE 7... -
Page 6: Lcd Icons
LCD ICONS CHARGING THE BATTERY The CB-320 is powered by a 3.7V Li-ion battery pack. The battery pack should be fully charged before being used for the first time or if you have not used the radio for some time. This will ensure maximum capacity is available. -
Page 7: Charging The Cb-320 Single Unit
CHARGING THE CB-320 SINGLE UNIT BATTERY USAGE The CB-320 is supplied with a 240V Ac adaptor. The Ac adaptor will charge a fully dis- The time taken to discharge the battery pack will depend on how you use the radio. The charged 1300mAh battery pack to full capacity in around 4 hours. -
Page 8: Low Transmit Power Settings
If no further signals are received, the unit will return to standby mode after a few sec- higher than it receives. onds. e.g. If Duplex is selected on channel 1, your radio will receive on channel 1 but will trans- mit on channel 31. PAGE 12 CB-320 INSTRUCTION MANUAL CB-320 INSTRUCTION MANUAL PAGE 13... -
Page 9: Scanning
If neither system is currently in use, you can make your own choice. There is no difference in performance between the two systems. Once a CTCSS or DCS code has been enabled, the display will show (for CTCSS) or (for DCS). PAGE 14 CB-320 INSTRUCTION MANUAL CB-320 INSTRUCTION MANUAL PAGE 15... -
Page 10: Menu
To listen the FM broadcast radio range from 87Mhz – 108Mhz. While in the FM radio plays LOW). The power setting applies to the selected channel. mode, press UP/DOWN to change the radio frequency. PAGE 16 CB-320 INSTRUCTION MANUAL CB-320 INSTRUCTION MANUAL PAGE 17... -
Page 11: Vox Settings
2. Press UP/DOWN repeatedly until ‘LOC.KEY’ is displayed (Option #08). 3. Press MENU to enter the selected option and UP/DOWN to adjust the settings. a. MANU: lock the keypad manually. PAGE 18 CB-320 INSTRUCTION MANUAL CB-320 INSTRUCTION MANUAL PAGE 19... -
Page 12: To Add Or Remove Scan Channels And To Start Scanning
D043N D115N D156N D244N D274N D364N D047N D116N D162N D245N D306N D365N D051N D122N D165N D246N D311N D371N D053N D125N D172N D251N D315N D411N D054N D131N D174N D252N D325N D412N PAGE 20 CB-320 INSTRUCTION MANUAL CB-320 INSTRUCTION MANUAL PAGE 21... -
Page 13: Uhf Cb Operating Frequencies
AS/NZS 4365.2011 Guard band channel. Transmission is inhibited as Road channel required by AS/NZS 4365.2011 *1 Repeater input channels (Duplex) Caravan and motorhome *2 Repeater output channels (Duplex) PAGE 22 CB-320 INSTRUCTION MANUAL CB-320 INSTRUCTION MANUAL PAGE 23... -
Page 14: Specification
This warranty against defects is given by Unicom Communications (NZ) Ltd NZBN Frequency Range 476.4250 – 477.4125 MHz 9429046455161 (We, us, our or Unicom). Our contact details are set out in clause 2.7. Channel Spacing 12.5 kHz 1. Consumer guarantees... - Page 15 4.1 We provide the following warranty on Unicom products. No repair or replacement repair. We agree to re-repair or replace (at our option) any materials or workman- during the warranty period will renew or extend the warranty period past the period ship which we are satisfied are defective.
- Page 16 PAGE 28 CB-320 INSTRUCTION MANUAL...
- Page 17 Unicom Communications (NZ) Ltd 11B Airborne Road, Rosedale, Auckland 0632, New Zealand All other international enquiries email: export@unicoms.co.nz...
