For Express HIGH SPEED Contact Grills
Models: RE100-PING, RE100FR-PING,
PLEASE READ CAREFULLY BEFORE INSTALLING OR USING THE GRILL
UNPACKING
Caution: When Lifting
Take care when removing grill from the carton. If in doubt about the weight - get assistance.
Carefully remove the grill from the carton, place on a secure flat surface and remove any plastic
protective film from the appliance.
Before disposing of the carton check that no parts or accessories have been left inside.
CONTENTS
♦ 1 Express Contact Grill (single or double model)
♦ 1 Mid-frame Spacer
♦ 1 Mini Wire Spacer
♦ 1 Flat Metal Scraper
♦ 1 Serrated Metal Scraper (if grill has one or more ribbed plates)
♦ 1 Set of Instructions including Cooking Times Guide
ELECTRICAL SPECIFICATIONS
Caution: Electrical Equipment
Models with two cables and plugs (RE200-PING) must be connected to electrical sockets running
directly off the ring main. DO NOT connect to two sockets off the same spur.
IF IN DOUBT use the services of a qualified electrician.
Consumption
RE100-PING
1 x 2.9kw
or
1 x 1.5kw (economy mode)
RE200-PING
2 x 2.9kw (both sides full power)
or
2 x 1.5kw (both sides economy mode)
or
1 x 2.9kw and 1 x 1.5kw
(one side on full power and
one side economy mode.)
INSTRUCTIONS
RE200-PING, RE200FR-PING,RE200FR1-PING
Connection
13amp 3 pin plug
13amp 3 pin plug
HIGH SPEED CONTACT GRILLS
Power
1 x 230/240 volt
2 x 230/240 volt
Express Grills
INSTRUCTIONS For all models
RE100, RE100DT, RE200, RE200DT
Page 2
1
Advertisement
Table of Contents
Summary of Contents for Rowlett RE100-PING
- Page 1 INSTRUCTIONS For Express HIGH SPEED Contact Grills Models: RE100-PING, RE100FR-PING, RE200-PING, RE200FR-PING,RE200FR1-PING PLEASE READ CAREFULLY BEFORE INSTALLING OR USING THE GRILL UNPACKING Caution: When Lifting Take care when removing grill from the carton. If in doubt about the weight - get assistance.
- Page 2 (1) ON/OFF switch +Full/Half power control (6) Removable splash guard (2) Temperature control (7) Fat collection tray (3) Temperature control indicator lamp (8) Adjustable feet (4) Ping Timer Ping Timer indicator lamp Cooking surfaces can be ribbed, smooth or a combination CONTROLS OPERATION Power and on/off Switches grill on to full (...
- Page 3 INSTALLATION Caution: Hot Surfaces Top and bottom plates operate at very high temperatures. Use only the handle when opening and closing the top plate. The lid covering the top plate will get hot. Place grill on the work surface and adjust the feet so that grill is level. Close the top plate/s and plug into a 3kw socket (or two sockets, see electrical specifications).
- Page 4 strong blunt implement (a blunt chisel for example). Some carbon removing cleaners may be effective, but extreme care must be exercised when using such chemicals and the manufacturer’s instructions followed in detail. Do not use caustic cleaners. In severe cases of carbon build up cooking surfaces appear to be cracked, black particles may flake off and can appear on the food.
