Assembly Instructions & Replacement Parts List
Assembly Instructions ................................................................................................. 1
Important Safety Information .................................................................................... 7
Parts Diagram ............................................................................................................... 9
WARNING:
All safety precaution statements on the air/hydraulic pump operation instruction supplied must be carefully observed to
help prevent personal injury.
Wedge Clamp Systems Inc. 170-21320 Gordon Way, Richmond, BC V6W 1J8
Tel: (604) 207-9595 | Fax: (604) 207-9593 | Toll Free: 1-800-615-9949
EZE ROLLER
10 TON PULLING MACHINE
Advertisement
Summary of Contents for Wedge Clamp Systems Inc. EZE ROLLER
- Page 1 EZE ROLLER 10 TON PULLING MACHINE Assembly Instructions & Replacement Parts List Assembly Instructions ………………………………….………..………………………………………. 1 Important Safety Information ………………………………………………………………………... 7 Parts Diagram ………………………………………………………………………………………………… 9 WARNING: All safety precaution statements on the air/hydraulic pump operation instruction supplied must be carefully observed to help prevent personal injury.
- Page 2 EZE ROLLER ASSEMBLY INSTRUCTIONS • Place left the right channel on the floor as shown • Place Eze Roller base and ram carriage onto the channels in the positions as shown.
- Page 3 • Loosely insert the two channel wedges under the channel between the base of the channels and the Eze Roller base as shown, • Take the loose end of the black nylon strap which is attached to the ram carriage and thread the strap through the roller cap rollers.
- Page 4 EZE ROLLER ASSEMBLY INSTRUCTIONS • Side the ram carriage towards the Eze Roller base a shown • Stand the Eze Roller into the vertical position as shown. • Hammer in the two channel wedges at the base of the channel •...
- Page 5 EZE ROLLER ASSEMBLY INSTRUCTIONS BEARING CRANK HANDLE WASHERS • Fit the ringed bearing and the bearing STRAP into the hole in the crank mount bracket from the inside of the bracket. As seen in the picture RINGED the bearing faces should be flush to the outside BEARING face of the bracket.
- Page 6 EZE ROLLER ASSEMBLY INSTRUCTIONS Set the ram carriage pulling height as shown by inserting the Pulley Pin under the ram carriage and through the holes in the channels Pulley Pin Always hold the crank handle firmly before removing the Pulley Pin otherwise handle will spin violently which could cause personal injury.
- Page 7 EZE ROLLER ASSEMBLY INSTRUCTIONS...
-
Page 8: Important Safety Information
IMPORTANT SAFETY INFORMATION The hydraulic reservoir in the pump must be vented prior to use. Please refer to re-priming the pump instructions located in Pump User Manual. - Page 9 IMPORTANT SAFETY INFORMATION...
- Page 11 21009 21009 20055 Pulley Pin 13063 Bearing 13007 1, 2, 3,14 Pump Assembly with Hose includes: (1) 20111; (1)20113; (1) 20053; (1)20054...
