OZ Charge OC-SR10 User Manual

User's Manual and Important Safety Information
Congratulations on purchasing an OzCharge Solar Controller Regulator.
OzCharge Controllers are comprised of the latest technology and suited to Aussie conditions:
Please carefully read these instructions before installing and using this device.

FEATURES

Suitable for Conventional Lead Acid Type Batteries (AGM GEL & WET).
•
Built in regulator to prevent your battery from being overcharged. Overcharging occurs when the charge voltage is
•
unregulated. This can result in premature battery failure.
Can be connected to the battery permanently to keep the battery fully charged by using a process called "floating".
•
This means the controller will stop charging when the battery is full and will automatically start charging the battery
as required. This process will also reduce water loss and help prevent the battery from 'drying out'.
Protects your battery from discharge at night. Under low light or no light conditions the solar panel voltage could be
•
less than the battery voltage. The unit contains a special circuit which prevents current flowing back from the
battery and into the solar panel.
Coloured LED's to indicate the operational status.
•
Digital LCD to indicate battery voltage.
•
Surface Mount or Flush Panel Mount options.
•
For use with 12 Volt Solar Panels Only.
Suitable for Solar Panels up to 170 Watts.
Solar Controller / Battery Charger
Input: DC12V Solar Panel (Max. 23V)
Output: DC12V 10A
Model Number: OC-SR10
OC-SR10 Manual - Rev 1.1
