Summary of Contents for Qtx HAZYR-PRO
- Page 1 HAZYR-PRO Item ref: 160.482UK User Manual Professional Haze Generator Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 Allow the HAZYR-PRO to acclimatize to room temperature before operating. Placement The HAZYR-PRO has a built-in fluid container – please ensure that the cap is securely sealed and the bottle is not inverted, which may cause it to leak into the machine.
- Page 3 Recommended fluid For the HAZYR-PRO haze machine, we strongly recommend the following fluid which has been specifically formulated to perform best with any heater-based haze machines. QTX ref code Description Size 160.591UK High quality professional haze fluid 5 Litre 160.596UK...
-
Page 4: Front Panel
Connect the IEC lead supplied to a suitable outlet (1), ensuring correct voltage. Heat up time is only 30-40 seconds before the HAZYR-PRO is ready to use. Pull forward the output aperture (7) to direct the flow of haze to the required angle. - Page 5 Operation To operate the HAZYR-PRO in standalone mode, use the 6-button control beneath the LED display on the rear panel as described below. Display (FUNCTION) Setting (UP/DOWN) Description Pause time between haze Interval Set 0s -200s (seconds) output Duration Set...
-
Page 6: Specifications
Specifications Power supply 220-240Vac, 50Hz (IEC) Power consumption 1000W Fuse F8AL Warm up time 30-40 seconds Haze output (approx.) 5000 cu ft (142m³) /min Controller Onboard/remote control panel or DMX512 operation DMX channels Fluid capacity 2 litres Dimensions 435 x 390 x 220mm Weight 10.45kg Troubleshooting... - Page 7 160.482UK User Manual...
