Ermax LSE22 User Manual

USER'S MANUAL
REMOTE CONTROL "LSE22"

CONVENTIONS:

All functions will be referred between "-", keys between (-) and visual indicators
[- ].

INDICATORS

[LED] – visual indicator of function execution;

KEYS

(TV.ON/OFF) – Key to turn on and turn off the TV.
(TV.CHANNEL.+) – Key to increase the TV channel.
(TV.CHANNEL.-) – Key to reduce the TV channel.
(TV.VOLUME.+) – Key to increase the TV volume.
(TV.VOLUME.-) – Key to reduce the TV channel.
(SOUND.ON/OFF) – Key for INPUT selection.
(SOUND.CHANNEL.+) – Key to increase the FM station;
(SOUND.CHANNEL.-) – Key to reduce the FM station;
(SOUND.VOLUME.+) – Key to increase the SOUND volume.
(SOUND. VOLUME.-) – Key to reduce the SOUND volume.
(LIGHT.ON/OFF) – Key to turn on or turn off the LIGHTS;
(LIGHT.CHANNEL1.+) – Key to increase the lightning intensity of zone 1.
(LIGHT.CHANNEL1.-) – Key to reduce the lightning intensity of zone 1.
(LIGHT.CHANNEL2.+) – Key to increase the lightning intensity of zone 2.
(LIGHT.CHANNEL2.-) – Key to reduce the lightning intensity of zone 2.
( * ) – Key to turn on or turn off the air conditioning;
( ) – Key to open the blinds;
( ) – Key to close the blinds;
( ) – Key to open the curtain;
( ) – Key to close the curtain;

1.0 - SPECIFICATIONS

• 5 keys to command the TV with function learning;
• 5 keys to command the sound;
• 5 keys to command 2 illuminations zo nes;
• 4 keys to command blinds and curtains;
• 1 key for additional function;
2.0 - TECHNICAL CARACTHERISTICS
- Power supply: 2 batteries of 1,5V Lr03 AAA;
- Dimensions: 170x43x18 mm;
- Keys in silicone;
- Plastic box ABS;
- Range up to 6 metres.
