Classeq WS-08 Technical Data

Technical data
Table 1
Water degrees French
hardness
degrees German
Parts per million
Model WS - 08
WS - 12
WS - 16
WS - 20
Flow rate
(litres per hour)
1000 ltrs
This leaflet is an integral part of the product. Please read the warnings provided carefully as these
provide important information concerning the safe installation, use and servicing of this product. This
water softener is intended to be used to soften cold drinking water only, any other use is considered
improper and as such unreasonable.
WARNING: use only sodium chloride Na Cl in large grains (kitchen salt) for regeneration. The
use of any other chemical substances or products is strictly forbidden.
Figure 1 LEGEND
A. Water Inlet
B. Water Outlet
C. Water Inlet Tap
D. Water Outlet
E. Pressure Relief Hose
F. Regeneration Hose
G. Cover Knob
I. Check Valve Tap

INSTALLATION.

After removing the packaging, make sure that the water softener isn't damaged. Keep the packaging
materials (plastic bags, cardboard box etc.) out of the reach of children as they can be dangerous.
The water softener should be installed in full observance of the current laws, following the
manufacturer's instructions and by experts. If installed incorrectly, the equipment may cause injuries
to people and animals and damage to property, in which case the manufacturer cannot be held
liable.
• Install the water softener in rooms where the temperature is minimum 5°c and maximum 30°c
MANUAL WATER
SOFTENER RANGE
30 °f 40 °f
16.5 °d 22 °d
300 ppm 400 ppm
1000 ltrs 900 ltrs
1500 ltrs 1350 ltrs
2100 ltrs 1800 ltrs
3000 ltrs 2600 ltrs
Volume of water softened, against hardness
Water pressure
Minimum Maximum
1 bar
60 °f 80 °f
33 °d 44 °d
600 ppm 800 ppm
700 ltrs 500 ltrs
1050 ltrs 750 ltrs
1400 ltrs 1000 ltrs
2100 ltrs 1500 ltrs
Water temperature
Minimum
5.5 bar 4 °c
Fig 1: Installation Drawing
Height Salt
400 mm 1.0 kg
500 mm 1.5 kg
600 mm 2.0 kg
900 mm 2.5 kg
Maximum
15 °c
