OPERATOR'S MANUAL

OMRPVRENG.319

ROTATING PULVERIZER

RAMMER RPV14R, RPV22R, RPV29R, RPV39R,

RPV53R, RPV75R

Table of Contents

Need help?

Do you have a question about the RPV22R and is the answer not in the manual?

Questions and answers

Summary of Contents for RAMMER RPV22R

Page 1 Original instructions 3/19 OPERATOR'S MANUAL OMRPVRENG.319 ROTATING PULVERIZER RAMMER RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R...
Page 2: Table Of Contents
Safety instructions ....13 Main dimensions RPV22R ..67 5. Operation ..... . . 23 Technical specifications RPV29R .
Page 4: Foreword
Foreword RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1. FOREWORD 1.1 THIS MANUAL This manual is arranged to give you a good understanding of the product and its safe operation. It also contains maintenance information and technical specifications. Read this manual from front to back before installing, operating or maintaining the product for the first time.
Page 5: Important Safety Information
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Foreword This symbol identifies correct and recommended action. See illustration 3. This symbol identifies environmental and recycling matter. See illustration 4. R010265 1.2 IMPORTANT SAFETY INFORMATION Basic safety precautions are outlined in the "Safety" section of this manual and in the instructions where hazards exist.
Page 6: Warranty
Foreword RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1.3 WARRANTY The customer is provided with a separate warranty sheet, where the export warranty terms are explained. Check always that this warranty sheet is provided with the product. If not, contact your local dealer immediately.
Page 7: Machine Numbers
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Machine numbers 2. MACHINE NUMBERS 2.1 MODEL AND SERIAL NUMBER The product serial number is stamped on the product body. The model and serial number are also located on the product identification plate. It is important to make correct reference to the serial number of the product when making repairs or ordering spare parts.
Page 8: Product Introduction
Product introduction RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 3. PRODUCT INTRODUCTION 3.1 OVERVIEW The product is a hydraulically operated pulverizer. It can be used on any carrier which meets the necessary hydraulic and mechanical installation requirements. 3.2 REMOVAL FROM PACKAGE Remove all the steel belts from the package.
Page 9 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Product introduction The other threaded holes on the product are intended for handling single parts only. You must not lift the entire assembly by using these threaded holes. For handling the parts, see product workshop documentation for suitable lifting methods and lifting adapters.
Page 10 Product introduction RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Place a chain or sling as shown in the illustration to lift the product. MB010011 Note: The lifting eye screws must always be removed from the product and replaced with a screw before operation.
Page 11: Main Parts
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Product introduction 3.4 MAIN PARTS The main parts of the rotating pulverizer are shown below. MB010018 A. Mounting bracket B. Jaw C. Frame D. Crushing plate E. Crushing tooth F. Cutting blades G. Cylinder H.
Page 12: Environmental Protection And Recycling
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 3.5 ENVIRONMENTAL PROTECTION AND RECYCLING POLICY Rammer products support the recycling of materials to help customers achieve their environmental objectives. During manufacturing all necessary precautions are taken to make sure that no harm is done to the environment.
Page 13: Safety
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Safety 4. SAFETY 4.1 GENERAL SAFETY All mechanical product can be hazardous if operated without due care or correct maintenance. Most accidents involving machine operation and maintenance are caused by failure to observe basic safety rules or precautions. An accident can often be avoided by recognizing potentially hazardous situations before an accident occurs.
Page 14 Safety RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R WARNING IGNORING INSTRUCTIONS HAZARD Faulty handling practice could cause death or severe injury. Read and follow the instructions in the operator’s manual. 169410_ENG-3 R010348 CARE AND ALERTNESS All the time you are working with the product, take care and stay alert. Always be alert for hazards.
Page 15 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Safety COMMUNICATIONS Bad communications can cause accidents. Keep people around you informed of what you will be doing. If you will be working with other people, make sure they understand any hand signals you will be using.
Page 16 Safety RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R DANGER DUST HAZARD Breathing dust will cause death or severe injury. Always wear approved respirator. 169410_ENG-1 R010349 Airborne pollutants are microscopic particles, which will damage your health when inhaled. Aiborne pollutants on construction sites can be for example silica dust, oil fumes or diesel exhaust particles, visible or invisible.
Page 17 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Safety FLYING DEMOLITION DEBRIS The safety label on the product is shown below: "FLYING OBJECTS HAZARD Fragments fly up to 40 m (130 ft) and could cause death or serious injury. Stop operation when a person enters hazard zone.
Page 18 Safety RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R G010031 COLLAPSING CONCRETE FRAMES Protect yourself and your surroundings from collapsing concrete frames. Do not operate the product or carrier with people around it. PRODUCT LIMITS Operating the product beyond its design limits can cause damage. It can also be dangerous.
Page 19 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Safety FIRE HAZARD Most hydraulic fluids are flammable and might ignite when contacting hot surface. Avoid spilling hydraulic fluid to hot surfaces. Working with the product on certain materials can cause sparks and hot splinters to get loose.
Page 20 Safety RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R MODIFICATIONS AND WELDING Non-approved modifications can cause injury and damage. Contact your local dealer for advice before modifying the product. Before welding on the product while it is installed on the carrier, consult your carrier dealer for precautions in welding.
Page 21 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Safety RPV14R Demolition tool Sandvik Mining and Construction Oy, Taivalkatu 8, 15170 LAHTI, FINLAND Serial number Model Max cylinder pressure (bar) Weight (kg) Max rotation pressure (bar) Min working Max cylinder oil flow (l/min)
Page 22 Safety RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R RPV29R Demolition tool Sandvik Mining and Construction Oy, Taivalkatu 8, 15170 LAHTI, FINLAND Serial number Model Max cylinder pressure (bar) Weight (kg) Max rotation pressure (bar) Min working Max cylinder oil flow (l/min)
Page 23: Operation
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Operation 5. OPERATION 5.1 OPERATING INSTRUCTIONS RECOMMENDED USE The pulverizer is designed for use in demolishing work to pulverize demolition material. It can be used in recycling plants for separating the concrete from the reinforcement bars or for removing and regrinding road surfaces.
Page 24 Operation RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R PRINCIPLES OF OPERATION The operation of the product is based on a static force produced by the hydraulic cylinder of the product. To increase the product's working life, pay particular attention to correct working methods.
Page 25: Daily Operation
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Operation 5.2 DAILY OPERATION Warning! Protect yourself and your surroundings from flying debris and collapsing concrete frames. Do not operate the product or carrier with people around it. The product, as a standard assembly, must not be used under water. It must be adapted for underwater applications.
Page 26 Operation RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R In models equipped with a rotation prevention system, remember to unlock the system before starting operation. Remove the cotter pin and take out the locking pin. MB010038 ■ Prepare the carrier for normal excavation work. Move the carrier to the required position.
Page 27 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Operation ■ Open the jaws, position the object on the fixed jaw side by operating excavator cylinders and close the jaws to crush. The best crushing result is obtained by using the whole tooth area of the jaws. NOTICE! Avoid using cutting blades for crushing.
Page 28 Operation RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R ■ To cut rebars or similar objects with the product, open the jaws. Operate the excavator cylinder to position the object on the cutting blade of the fixed jaw side and close the jaws to cut. For the best possible cutting performance and to avoid damaging the product, only use cutting blades for cutting.
Page 29 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Operation ■ Do not use the product to move the excavator. MB010060 ■ When operating the product, make sure that it does not make contact with the carrier boom or hydraulic lines. MB010061 ■ Do not operate the jaws with the carrier's boom stick or bucket cylinders at the end of their stroke (either fully extended or retracted).
Page 30 Operation RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R ■ When the jaws are closed, the cylinder rod is exposed. NOTICE! Avoid hitting the rod or shield plate with concrete or iron bars. Damage to the cylinder rod or shield plate may cause rod seal breakage and oil leaks.
Page 31 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Operation ■ To prevent the spread of dust during operation, constantly keep the working area damp with water jets. MB010067 ■ Stay more than 10 meters (33 feet) away from live, overhead electric cables with any part of the machine.
Page 32: Mounting And Dismounting The Product
Operation RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 5.3 MOUNTING AND DISMOUNTING THE PRODUCT REMOVAL FROM CARRIER Warning! The product must be secured from falling over when disconnecting it from the carrier. Only use a skilled operator to position the carrier for the...
Page 33 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Operation 4. Disconnect the hoses. Protect the environment from oil spills. Plug the hoses. MB010082 5. Remove the mounting bracket pins and other parts. MB010088 6. Install the locking pins and cotter pins. 7. Move the carrier aside, if needed.
Page 34 Operation RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 3. Connect the hoses. An installation inspection must be carried out after the product has been mounted on the carrier. During installation inspection, certain specifications (operating pressure, oil flow, etc.) are checked so that they are within given limits.
Page 35: Movement
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Operation 5.4 MOVEMENT The transportation and parking positions are shown below. When moving the carrier, ensure that the product is not too close to the carrier. MB010095 5.5 SPECIAL CONDITIONS OF USE The product may require modifications, special operating techniques, increased maintenance or special wear items if it is used in conditions that differ from normal breaking or demolition work.
Page 36: Storage
Operation RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R In case of special conditions of use, contact your local dealer for instructions. The product as a standard assembly, must not be used under water. Contact your local dealer for more information on underwater use.
Page 38: Greasing
Greasing RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1. GREASING 1.1 RECOMMENDED GREASES Item Recommended greases Greasing interval Pins and bushings every 8 hours Thrust bearing every 40...80 hours Additives: molybdenum disulfide Minimum working temperature below lowest ambient temperature Penetration 0 ... 2 (NLGI)
Page 39 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Greasing The greasing points of the product are shown below. MB020002 COPYRIGHT © 2019 SANDVIK MINING AND CONSTRUCTION OY Lubrication - Page 39...
Page 40: Carrier Hydraulic Oil
Carrier hydraulic oil RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 2. CARRIER HYDRAULIC OIL 2.1 REQUIREMENTS FOR HYDRAULIC OIL GENERAL REQUIREMENTS In general, the hydraulic oil originally intended for the carrier can be used with this product. However, since working with the product heats the oil more than with the usual excavation work, the temperature of the oil must be monitored.
Page 41 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Carrier hydraulic oil OIL SPECIFICATIONS The table below shows hydraulic oils recommended for product use. The most suitable oil is selected in such a way that the temperature of the hydraulic oil in continuous use is in the ideal area on the chart and the hydraulic system is used to best advantage.
Page 42: Oil Cooler
Carrier hydraulic oil RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Note: We strongly recommend the use of different hydraulic oils in the summer and in the winter if there is an average temperature difference of more than 35 °C (95 °F). The correct hydraulic oil viscosity is thus ensured.
Page 43: Oil Filter
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Carrier hydraulic oil 2.3 OIL FILTER The purpose of the oil filter is to remove impurities from the hydraulic oil. Air and water are also impurities in oil. Not all impurities can be seen with the naked eye.
Page 44 Carrier hydraulic oil RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Malfunction of valves ■ Binding spools. ■ Rapid wear of parts. ■ Blocking of small holes. Note: Component damage is only a symptom. The trouble itself will not be cured by removing the symptom. After any component damage due to impurities in the oil, the entire hydraulic system must be cleaned.
Page 46: Routine Maintenance
Routine maintenance RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1. ROUTINE MAINTENANCE 1.1 OVERVIEW This product is a precision-made hydraulic machine. Therefore, great care and cleanliness should be taken when handling any of the hydraulic components. Dirt is the worst enemy in hydraulic systems.
Page 47: Dealer
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Routine maintenance 3. Check the jaws and teeth for wear. Replace if necessary. Any type of hardfacing welding on the teeth of the jaws is not recommended as they are made of die- cast, wear-resistant material. Hardfacing welding on the teeth would alter their special shape, reducing the ability to penetrate concrete as well as productivity.
Page 48: Maintenance Intervals In Special
Routine maintenance RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R EVERY 600 HOURS OR ONCE A YEAR The 600-hour/yearly service is performed by your local dealer. It is recommended every 600 operating hours or once a year, whichever comes first. Neglecting the 600-hour/yearly service can cause severe damage to the product.
Page 49: Turning And Changing Cutting Blades
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Turning and changing cutting blades 2. TURNING AND CHANGING CUTTING BLADES WEAR LIMITS, ADJUSTMENTS AND TORQUES FOR CUTTING BLADES Item Adjustment Cutting blade clearance (C) 0.2...1.2 mm (0.01...0.05 in) Tightening torque, grade Tightening torque, grade...
Page 50: Turning And Changing Cutting Blades
Turning and changing cutting blades RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R TURNING AND CHANGING CUTTING BLADES Warning! Prior to maintenance or inspection, operate all the control levers to their fully extended stroke. This will release pressure within the hydraulic piping and prevent unexpected movement of the jaw and loss of oil through the hydraulic lines.
Page 51 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Turning and changing cutting blades 6. Remove the screws, cutting blades and shim plates. Turn the blades to use one of the 4 sharp sides (the blades may be rotated up to 4 times). Replace the blades if necessary.
Page 52: Replacing Teeth
Replacing teeth RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 3. REPLACING TEETH WELDING TOOLS AND TORQUES FOR CUTTING BLADE SCREWS Item Welding tool Repair of parent, installation of MIG-wire, DIN 8559: SG 2 tooth Welding rod, DIN 1913: E 51 53 B 10...
Page 53 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Replacing teeth For the product to perform and operate well and to reduce maintenance costs, it is necessary to replace the interchangeable parts before wear and tear can undermine their housings. If, due to lack of maintenance, teeth are lost during product operation, stop operation immediately or you will damage the housings on the product body.
Page 54 Replacing teeth RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R NOTICE! Any type of hardfacing welding on the interchangeable parts is not recommended, since they are made of wear proof material and hard to weld. Furthermore, the hardfacing welding would alter the flatness of the manufactured parts, making the coupling in their housings difficult.
Page 55 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Replacing teeth 5. By gently hammering, make sure that the key is in full contact with the tooth. Make sure that contact between the tooth and the adapter is maintained. 6. Prepare the STIMIX kit. The kit includes a pistol (3), one cartridge containing resin, and two mixing tubes.
Page 56: Replacing Crushing Plate
Replacing crushing plate RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 4. REPLACING CRUSHING PLATE TIGHTENING TORQUE FOR CRUSHING PLATE Tightening torque, grade Tightening torque, grade Tightening torque, grade Screw 10.9 12.9 25 Nm (18 lbf ft) 35 Nm (26 lbf ft)
Page 57 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Replacing crushing plate 4. Remove the old crushing plate. MB030016 5. Fix the new crushing plate properly into place. 6. Install the screws and washers. Tighten parts to the specified torques. COPYRIGHT © 2019 SANDVIK MINING AND CONSTRUCTION OY...
Page 58: Changing Oil In The Rotation Unit
Changing oil in the rotation unit RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 5. CHANGING OIL IN THE ROTATION UNIT DIAGRAM MB030034 Item Drain plug (A) Filler cap (B) Level plug (C) CHANGING OIL IN THE ROTATION UNIT Warning! Support the jaw to prevent it from closing unexpectedly during maintenance.
Page 59 RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Changing oil in the rotation unit Avoid mixing oils of different viscosity or of different brands. Do not mix mineral oils with synthetic oils. After start-up, check the lubricant level periodically and top it up whenever necessary.
Page 60: Troubleshooting
DROP IN HYDRAULIC PRESSURE ON BASE MACHINE Adjust pressure. See “Product specifications” on page 64. OIL LEAKAGE WITHIN CYLINDER The product must be serviced in an authorized Rammer service shop. 6.2 PRODUCT DOES NOT CUT WORN CUTTING BLADES Turn over the cutting blades and adjust. If necessary, change the cutting blades. See “Turning and changing cutting blades”...
Page 61: Excessive Moving
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Troubleshooting OIL LEAKAGE WITHIN CYLINDER The product must be serviced in an authorized Rammer service shop. CYLINDER ROD IS BENT The product must be serviced in an authorized Rammer service shop. 6.4 EXCESSIVE MOVING WORN PINS AND BUSHINGS The product must be serviced in an authorized Rammer service shop.
Page 64: Product Specifications
Product specifications RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1. PRODUCT SPECIFICATIONS 1.1 TECHNICAL SPECIFICATIONS RPV14R Item Specification 1150 kg (2535 lb) Minimum working weight Pulverizer weight 1050 kg (2315 lb) Max. jaw opening 580 mm (22.83 in) Max. cutting force 1590 kN (357446 lbf) Max.
Page 65: Main Dimensions Rpv14R
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Product specifications 1.2 MAIN DIMENSIONS RPV14R 130 130 125 MB040020 COPYRIGHT © 2019 SANDVIK MINING AND CONSTRUCTION OY Specifications - Page 65...
Page 66: Technical Specifications Rpv22R
Product specifications RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1.3 TECHNICAL SPECIFICATIONS RPV22R Item Specification 2080 kg (4586 lb) Minimum working weight Pulverizer weight 1900 kg (4189 lb) Max. jaw opening 750 mm (29.53 in) Max. cutting force 2680 kN (602488 lbf) Max.
Page 67: Main Dimensions Rpv22R
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Product specifications 1.4 MAIN DIMENSIONS RPV22R 142.5 142.5 142.5 142.5 MB040021 COPYRIGHT © 2019 SANDVIK MINING AND CONSTRUCTION OY Specifications - Page 67...
Page 68: Technical Specifications Rpv29R
Product specifications RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1.5 TECHNICAL SPECIFICATIONS RPV29R Item Specification 2990 kg (6592 lb) Minimum working weight Pulverizer weight 2770 kg (6107 lb) Max. jaw opening 900 mm (35.43 in) Max. cutting force 2620 kN (588999 lbf) Max.
Page 69: Main Dimensions Rpv29R
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Product specifications 1.6 MAIN DIMENSIONS RPV29R 160 160 160 MB040022 COPYRIGHT © 2019 SANDVIK MINING AND CONSTRUCTION OY Specifications - Page 69...
Page 70: Technical Specifications Rpv39R
Product specifications RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1.7 TECHNICAL SPECIFICATIONS RPV39R Item Specification 4245 kg (9359 lb) Minimum working weight Pulverizer weight 3925 kg (8653 lb) Max. jaw opening 1000 mm (39.37 in) Max. cutting force 3720 kN (836289 lbf) Max.
Page 71: Main Dimensions Rpv39R
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Product specifications 1.8 MAIN DIMENSIONS RPV39R 170 170 170 1000 MB040023 COPYRIGHT © 2019 SANDVIK MINING AND CONSTRUCTION OY Specifications - Page 71...
Page 72: Technical Specifications Rpv53R
Product specifications RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1.9 TECHNICAL SPECIFICATIONS RPV53R Item Specification xxx0 kg ( lb) Minimum working weight Pulverizer weight 5200 kg (11464 lb) Max. jaw opening 1100 mm (43.31 in) Max. cutting force 5430 kN (1220713 lbf) Max.
Page 73: Main Dimensions Rpv53R
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Product specifications 1.10 MAIN DIMENSIONS RPV53R 170 170 170 1100 MB040043 COPYRIGHT © 2019 SANDVIK MINING AND CONSTRUCTION OY Specifications - Page 73...
Page 74: Technical Specifications Rpv75R
Product specifications RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 1.11 TECHNICAL SPECIFICATIONS RPV75R Item Specification xxx0 kg ( lb) Minimum working weight Pulverizer weight 8200 kg (18078 lb) Max. jaw opening 1250 mm (49.21 in) Max. cutting force 7870 kN (1769246 lbf) Max.
Page 75: Main Dimensions Rpv75R
RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R Product specifications 1.12 MAIN DIMENSIONS RPV75R 1020 225 225 225 1250 MB040044 COPYRIGHT © 2019 SANDVIK MINING AND CONSTRUCTION OY Specifications - Page 75...
Page 76: Ec Declaration Of Conformity
EC Declaration of Conformity RPV14R, RPV22R, RPV29R, RPV39R, RPV53R, RPV75R 2. EC DECLARATION OF CONFORMITY EC DECLARATION OF CONFORMITY Manufacturer: MANTOVANIBENNE S.R.L. Address: VIA RIGHI, 6 41037 MIRANDOLA (MO), ITALY Declares under our sole responsibility that the interchangeable product: Rammer rotating pulverizer...
Page 80 Sandvik Mining and Construction Oy, Breakers Lahti Taivalkatu 8, P.O. Box 165, FI-15101 Lahti, Finland Phone Int. +358 205 44 151, Telefax Int. +358 205 44 150 www.rammer.com 75-12-14133-42-20-343 75-12-14133-45-28-161...
