S.D.P. EZ Hauler 4100 Training & Procedure Manual

Hide thumbs Also See for EZ Hauler 4100:

Advertisement

Quick Links

Download this manual See also: Manual
EZ Hauler 4100
Training & Procedure
Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the EZ Hauler 4100 and is the answer not in the manual?

Questions and answers

Related Manuals for S.D.P. EZ Hauler 4100

Summary of Contents for S.D.P. EZ Hauler 4100

  • Page 1 EZ Hauler 4100 Training & Procedure Manual...

  • Page 2: Load Capacity

    Load Capacity of the EZ Hauler’s boom. The maximum weight capacity of the EZ Hauler 4100 is 4100 lbs. • The load capacity of the boom depends upon the distance from center line of boom turret! •...
  • Page 3 EZ Hauler 4100 Safety While the EZ Hauler 4100 is smaller than a line truck, its function is the same and all safety precautions that would apply to a line truck also apply to the EZ Hauler 4100. The EZ Hauler 4100 is a powerful machine that should be operated with respect &...
  • Page 4 Hard hats and protective gear must be worn by all personnel when using the EZ Hauler 4100.
  • Page 5 • The capacity of the EZ Hauler 4100 is rated at 4100 pounds which means that the most the boom will ever safely lift is 4101 4100 pounds. Refer to the load capacity chart or on the machine itself for more specific indications of the mini- derrick’s capacity.

  • Page 6: Safety Guidelines

    All of your existing in-house safety precautions must be followed as well as the precautions listed in this manual. • The EZ Hauler 4100 is not electrically insulated until final stage manual boom is extended and pinned into place. Be sure to follow your company’s safety procedures to protect against...
  • Page 7 • The EZ Hauler 4100’s controls react to input rapidly. Know the location and function of all controls before starting the machine. • The EZ Hauler 4100 can be shut down in an emergency by releasing all drive controls and turning the ignition switch to the “off” position.

  • Page 8: Pre-Trip Inspection

    Pre-trip Inspection • Before each day’s operation, the EZ Hauler 4100 must be inspected by the operator. • Do a visual inspection to check for lose, worn, missing or broken parts such as bolts, nuts, wires & retaining pins. a. Check hydraulic hoses for cuts, wear, loose connections.
  • Page 9 Pre-trip Inspection Check all tires on the EZ Hauler 4100 trailer for wear & proper inflation.
  • Page 10 Pre-trip Inspection Test all turn signal, parking and brake lights by turning them on. Be sure to test the braking action on the trailer before traveling to the work site.
  • Page 11 Pre-trip Inspection • Check to make sure that EZ Hauler 4100 is properly secured to the trailer. • Look inside the trailer toolbox & make sure it contains all tools & equipment necessary for operating the EZ Hauler 4100.
  • Page 12 Pre-trip Inspection Turn on the remote control & check the function of all controls.
  • Page 13 Pre-trip Inspection Inspect the lift line and hook for signs of wear or damage. Replace any worn or damages parts before using the EZ Hauler 4100.
  • Page 14 Familiarize yourself with these Control Panel Features engine speed Emergency Stop HI/LO switch coolant overheat pre-heat low oil pressure engine pre-heat on battery not charging WARNING LIGHTS ignition Switch hydraulic system engine RPM/hour meter voltage pressure oil pressure coolant temp The ignition switch has three stationary positions: engine off - pre heat –...
  • Page 15 Remote Control Basic Operation Turn E-stop counter- clockwise to turn on remote and press to shut off remote. Operation switch must be in crane position to operate digger derrick. Auger switch: A position to dig, B position to reverse (clean). NOTE: Auger will stop digging during overload, reverse auger to stop overload.
  • Page 16 Driving the EZ Hauler 4100 The EZ Hauler 4100 does not require its full engine power when moving. Set the engine speed relatively low when driving the unit, reserving the higher engine speeds for powering hydraulic accessories. WARNING: The EZ Hauler 4100 should only be driven with the...
  • Page 17 Driving the EZ Hauler 4100 Remote Drive Function (optional) When operating the EZ Hauler 4100 with the remote, pay close attention to the unit and the terrain that you are navigating.
  • Page 18 Driving The EZ Hauler 4100 • Pay close attention to the “side tip” angle indicator when navigating tough embankments. • Always stay within the safe operating zone.
  • Page 19 Going through gates with The EZ Hauler 4100 • When preparing to go through a gate with the EZ Hauler 4100, always make certain the boom is level as shown by the level indicator. NOTE: Boom must be level to allow outriggers to retract fully.
  • Page 20 Safety Track Interlock System • The track interlock system is an integral safety component that is designed to notify the operator of the tracks not being extended completely. • The red indicator light will be lit up when tracks are fully extended.
  • Page 21 4 inches from the ground. • Note: If the EZ Hauler 4100 engine is not started, start it and let it warm up for 5 minutes.
  • Page 22 (Pictures may not be a true representation of your machine.) NOTE: The EZ Hauler 4100 is secured for transport at the front and back of the trailer.
  • Page 23 Moving the EZ Hauler 4100 Through a small opening. • One of the advantages of the EZ Hauler 4100 is that it is small enough to operate in areas which are too confined to use a line truck. • A standard gate opening is 36 inches wide.
  • Page 24 Moving the EZ Hauler 4100 With a Load Moving a pole: Lifting and carrying a pole can be performed easily with the hydraulic outriggers. Attach the provided lifting chains to the pole and to the d-rings on the EZ Hauler 4100 outrigger arms as shown.
  • Page 25 Using the outrigger control levers lift both outriggers equally until pole is securely in place. NOTE: Pole must clear tracks when completely lifted (Picture may not be a true representation of your machine.) vReverse procedure when pole is ready to be lowered to the ground.
  • Page 26 It may be necessary to rotate the boom slightly in order to carry a transformer. Drive the EZ Hauler 4100 slowly. Make turns slowly and (Picture may not be a true representation of your machine.)
  • Page 27 Setting a Pole With the EZ Hauler 4100 • Remember the EZ Hauler 4100 is not totally electrically insulated. Use your company’s insulation procedure to avoid electrocution. Before setting a pole the load capacity chart must be thoroughly understood. Caution!! Weight of load must be known at all times .
  • Page 28 Setting the Outriggers Use the outrigger controls to lower outriggers to level and support the machine. Oversized outrigger pads might be required depending on soil conditions.
  • Page 29 Auger Operation Procedure...
  • Page 30 Make sure that boom sections are fully retracted and that auger pins are in correct position. Using the auger remote circuit wind up the auger slightly to release tension on latch pin. NOTE: Use the flow control on the remote control to control the speed of the auger.
  • Page 31 Release auger latch and slowly lower auger. IMPORTANT: You must raise boom to lower auger assembly.
  • Page 32 5. Carefully unwind (dig) auger and remove strap. You are now ready to use the remote control to auger as needed.
  • Page 33 5. Reverse this procedure to store the auger. Again making sure to have boom extensions fully retracted before stowing auger. DO NOT “OVER STORE” THE AUGER AS DAMAGE CAN OCCURE! NOTE: Make sure to place boom extension pins in proper CRANE location before extending boom sections.

  • Page 34: Digging The Hole

    Digging the Hole • Position the machine over the desired hole replacement area. Extending boom 12 or 14 inches and allowing enough slack in rope to drill a straight hole down. • Turn on the remote and toggle the Auger switch to the correct direction then lower the auger to begin digging.
  • Page 35 Take small bites and let the auger dig at its own pace until the hole is the proper depth. Different regions have many different soil compositions; familiarize yourself with your digging surface for your safety and those around you. (Pictures may not be a true representation of your machine.)
  • Page 36 If needed, the extension bar may adjusted for more digging depth. (Pictures may not be a true representation of your machine.)
  • Page 37 Setting the Pole 1. Unwind winch line. 2. Unpin 3rd stage fiberglass extension. 3. Pull extension out past first pin holes. Making sure stop latch handle is in a vertical position.
  • Page 38 4. Pull extension out until stop latch pin engages. WARNING! Fiberglass final stage must be fully extended and pinned for dielectric insulation! 5. Reinstall lock pin.
  • Page 39 • Install hydraulic pole guide. Refer to installation instructions on page 42. • Raise the boom into position so that the lift line will be lifting straight up. Follow load chart specifications on weight in relationship to boom angle. • Install the lifting strap, remember to position the lifting strap according to pole weight for balance in lifting.
  • Page 40 • Lift the pole straight up and set into the hole. • Always operate EZ Hauler 4100 from a safe distance using the remote control. • Never use manual lever overrides for normal operation, they are for emergency use only.
  • Page 41 Bucket Assembly Standard Operating Procedure...
  • Page 42 • CAUTION: Prior to using the bucket assembly, extend and secure all outriggers to the fullest settings. • CAUTION: The bucket assembly has the safe lifting capability • of 300 pounds. Besides the weight of the operator this includes all tools, parts or anything else in or on the bucket.
  • Page 43 Lower and extend the boom to accommodate installation of the bucket mount. After completing the tasks, return the hydraulic boom sections to the retracted “stowed” position before lowering the bucket to a flat surface. CAUTION! Stay clear of bucket while in operation.
  • Page 44 Winch rope Kill Switch Please retract winch rope back (optional feature) to the winch rope stowed if they are not in use.
  • Page 45 Shows the bucket mount installed and pinned it in place...
  • Page 46 The bucket can now be mounted to either side of the mount to best accommodate working from it.
  • Page 47 Make sure the locking mechanism on the bucket mount is unlocked by pulling it up and twisting counterclockwise into the position shown. This allows the bucket to swing freely and remain perpendicular while the boom is being raised or lowered.
  • Page 48 Once the boom is at working height lock the bucket in place by rotating the mechanism clockwise allowing the spring to engage the working parts of the lock. Remember to unlatch the lock each time before raising or lowering the boom!
  • Page 49 Hydraulic Pole Guide Procedure...
  • Page 50 1. Slide pole guide in to receiver of sheave head. 2. Install and secure pin.
  • Page 51 3. Make sure hydraulic couplers on pole guide and hose reel are clean. 4. Connect hydraulic couplers from hose reel to pole guide. Make sure connection is secure.
  • Page 52 5. Remember that the pole guide is conductive so it will not be insulated against cross fazing, but with the fiberglass stage boom properly pinned in place the EZ Hauler 4100 and its operator will be substantially protected.
  • Page 53 Pole Pulling Always use a suitable open center “pole pulling” tool for pole removal! The EZ Hauler can be used as a guide and steady the pole as the pole pulling tool is in use. WARNING: Never use the EZ Hauler to pole pulling or pull screw anchor, always use secondary pole No Pole Pulling...
  • Page 54 IMPORTANT! The EZ Hauler 3800 / 4100 series of machines are all dielectrically tested to 46kv category “C” guidelines. This qualification test is performed at the factory in accordance with ANSI A10.31 guidelines. It is important that periodic tests be performed to the EZ Hauler just as any other digger-derrick in a companies fleet.
