- Page 1 IO-F-SLD100-1064 Fiber Isolator for Broadband SLDs User Guide...
-
Page 2: Table Of Contents
4.1. Forward Mode .............. 6 4.2. Reverse Mode ............... 6 Chapter 5 Warranty ................6 Chapter 6 Specifications ..............7 Chapter 7 Drawing ................8 Chapter 8 Regulatory ................. 9 Chapter 9 Thorlabs Worldwide Contacts........10 TTN046826-D02, Rev B Sept. 14, 2018... -
Page 3: Chapter 1 Safety
1064 nm Fiber Isolator for Broadband SLD’s Chapter 1: Safety Chapter 1 Safety WARNING This isolator contains a powerful permanent magnet. Keep all steel objects and anything affected by a magnetic field at a minimum distance of 2" (50 mm) from the isolator. WARNING Do NOT attempt to disassemble this isolator. -
Page 4: Chapter 2 Setup
1064 nm Fiber Isolator for Broadband SLD’s Chapter 2 Setup 2.1. Unpacking Note: Thorlabs aligns the isolator with unpolarized light. This unit is fusion spliced with the laser source fiber and individually tested. See the included test report for details. -
Page 5: Chapter 3 Description
SLD1XX (indicates broadband wavelength range in nm) Center Wavelength (nm) Example: The IO-F-SLD100-1064 isolator is a polarization independent fiber isolator with a max power level of 2 W (CW), wavelength range of 100nm (1064 ± 50nm) and a center wavelength of 1064 nm. -
Page 6: Polarization Independent Optical Path Schematic
1064 nm Fiber Isolator for Broadband SLD’s 3.1. Polarization Independent Optical Path Schematic TTN046826-D02, Rev B Sept. 14, 2018... -
Page 7: Chapter 4 Operation
The laser is now isolated from downstream reflections. Chapter 5 Warranty All Thorlabs fiber isolators are covered by Thorlabs’ six-month warranty against defects in materials and workmanship. WARNING Do not attempt to disassemble the isolator. -
Page 8: Chapter 6 Specifications
1064 nm Fiber Isolator for Broadband SLD’s Chapter 6 Specifications IO-F-SLD100-1064 Item # Polarization Independent Fiber Type Single Mode (SM), HI1060 Center Wavelength 1064 nm Operating Range 1014 - 1114 nm Weight 0.20 kg Optical Specifications ≥ 25 dB @ 1064 nm... -
Page 9: Chapter 7 Drawing
1064 nm Fiber Isolator for Broadband SLD’s Chapter 7: Drawing Chapter 7 Drawing Page 8 Sept. 14, 2018... -
Page 10: Chapter 8 Regulatory
Waste Treatment is Your Own Responsibility If you do not return an “end of life” unit to Thorlabs, you must hand it to a company specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site. -
Page 11: Chapter 9 Thorlabs Worldwide Contacts
1064 nm Fiber Isolator for Broadband SLD’s Chapter 9: Thorlabs Worldwide Contacts Chapter 9 Thorlabs Worldwide Contacts USA, Canada, and South America UK and Ireland Thorlabs, Inc. Thorlabs Ltd. 56 Sparta Avenue 1 Saint Thomas Place Newton, NJ 07860 Ely CB7 4EX... - Page 12 www.thorlabs.com...
