Summary of Contents for Portech MT-360
- Page 1 MT-360 SMS Operation Manual PORTech Communications Inc.
-
Page 2: Table Of Contents
§ Index § Hardware Setup ................1 Software Setup ................1 Operation Guide ................2 How to send out a short message ............. 3 Report File ..................6 Q & A ....................6... -
Page 3: Hardware Setup
MT-350 SMS Manual 1 Hardware Setup Connect the RS232 cable between PC & MT360. Any serial port of the PC can be used(The software program uses COM1 as default). Make sure the SIM card has been inserted in position and the MT360 power is on. Software Setup The software program ‘MTSMS.exe’... -
Page 4: Operation Guide
MTSMS Manual 2 Operation Guide After executing the program, the following window shows up. There are 2 types of display mode in the program’s window : the “Short Message Item View” and the “Detail Information View”. The “Short Message Item View” shows all the short messages sent or received and the status of each short message item. -
Page 5: How To Send Out A Short Message
MT-350 SMS Manual 3 If the message “*** Initialization completes!! ***” shows up, then the communication between MT360 and the PC is OK, otherwise, you will see the message : “*** Timeout!! No response ***”. In that circumstance, the serial port might not be assigned correctly, or it is occupied by other application program. - Page 6 MTSMS Manual 4 You can have multiple destination mobile numbers to send common messages. First, type in the message content and mobile number to add into list, then click ‘<- Add’ button. Enter other mobile number then click ‘<-Add’ button to add into the mobile number list. You can also remove mobile number from the list, or import mobile numbers from external data file.
- Page 7 MT-350 SMS Manual 5 Choose a file to be imported. In the imported file, each line contains one mobile number. When all data is ready, click ‘Send’ button to send message out. A short message item is inserted in the short message item view. The sending procedure will show clearly in this view, and user may see the status of each sending message.
-
Page 8: Report File
MTSMS Manual 6 When a short message is received by MT360, a new item will be inserted in the view. The above figure reflects the situation. Report File There are 3 types of log file could be referenced for further use. In the working directory, e.g. - Page 9 MT-350 SMS Manual 7 In this case, switch the view to ‘Detail Information View’ to check whether the communication between PC COM port and MT360 works normally. Try to issue the initial commands to MT360 by clicking ‘Test/Issue Initial Commands’. If the “Timeout” message still appears, then check the RS232 cable.
- Page 10 PORTech Communications Inc. 150, Shiang-Shung N. Road Taichung, Taiwan 403, R.O.C. Tel: 886-4-2305-8000 http://www.portech.com.tw...
