HYDRIVE 2010A - 2020A
Z.I. La Plaine des Isles - F 89000 AUXERRE - FRANCE
Tel. : +33 (0)3.86.49.86.30 - Fax : +33 (0)3.86.49.87.17
contact@mouvex.com - www.mouvex.com
INSTRUCTIONS 206-A00 e
Section
206
Effective
October 2011
Replaces
March 2011
Original instructions
INSTALLATION
OPERATION
MAINTENANCE
SAFETY
STORAGE
Your distributor :

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYDRIVE 2010A and is the answer not in the manual?

Questions and answers

Summary of Contents for Mouvex HYDRIVE 2010A

  • Page 1 INSTRUCTIONS 206-A00 e Section Effective October 2011 Replaces March 2011 Original instructions HYDRIVE 2010A - 2020A INSTALLATION OPERATION MAINTENANCE SAFETY STORAGE Your distributor : Z.I. La Plaine des Isles - F 89000 AUXERRE - FRANCE Tel. : +33 (0)3.86.49.86.30 - Fax : +33 (0)3.86.49.87.17...

  • Page 2: Table Of Contents

    HYDRAULICS COOLERS SAFETY, STORAGE, INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS MODELS : HYDRIVE 2010A & 2020A Page TABLE OF CONTENTS 1. OVERALL DIMENSIONS ......3 2.

  • Page 3: Overall Dimensions

    1. OVERALL DIMENSIONS REVOLVING T 1”1/16 JIC M/F/M DISCHARGE HYDRIVE 2010 SUCTION REVOLVING T 1”5/16 JIC M/F/M HYDRIVE 2020 DISCHARGE SUCTION NT 206-A00 10.11 Hydrive e 3/16...

  • Page 4: Technical Data

    2. TECHNICAL DATA HYDRIVE 2010A Oil Flow Rate 15 - 32 US GPM 55 - 120 l / min Circuit pressure 2 possible versions : RV set @ : RV set @ : 170 bar 2465 PSI 170 bar 270 bar...
  • Page 5 3. INSTALLATION (continued) 3.1.1 STANDARD HYDRIVE 2010A & 2020A There are 2 versions of the HYDRIVE 2010, standard version and selector valve version. (NOTE : Use a remote on / off HYDRAULIC CIRCUIT valve on hydraulic systems using the hydrive 2010 without...

  • Page 6: Mounting The Hydrive

    3. INSTALLATION (continued) 3.1.2 HYDRIVE 2010A HYDRAULIC CIRCUIT - SELECTOR Hydraulic motor 1 Hydraulic motor 2 The HYDRIVE must be mounted as high above the hydraulic pump as possible to avoid hydraulic pump cavitation. Suction line HYDRIVE 2010/2020 Oil tank...
  • Page 7 Various options for position 3. All seals must be made using bonded washers, O-ring or coned fittings. MOUVEX does not recommend the use of PTFE tape or liquid sealant, as these may contaminate the hydraulic oil or plug the system.
  • Page 8 1. Suction Hazardous pressure can cause 6. Motor 2 7. T-junction* (High Pressure) personal injury or property damage. Figure 5 HYDRIVE 2010A selector connections 4. Drain 3. Return (Low Pressure) 2. Pump (High Pressure) 1. Suction 7. T-junction Figure 4...

  • Page 9: Hydraulic Oil

    3. INSTALLATION (continued) 3.3 Hydraulic oil 4. Have a container of suitable hydraulic oil available to refill the HYDRIVE reservoir as necessary. DO NOT The System must be filled with one of the following anti- OVERFILL. foaming hydraulic oils, or an equivalent oil : NOTE Do not fill the HYDRIVE reservoir while the hydraulic system is running.

  • Page 10: Engaging Hydraulic Motor

    3. INSTALLATION (continued) 3.5 Engaging hydraulic motor 1. Install test equipment in the high pressure line per the manufacturers recommendations. 1. Move the system on/off control valve or HYDRIVE NOTE selector valve (if equipped) and any directional valves The use of quick connect fittings in the hydraulic motor to the correct position for running the hydraulic motor.

  • Page 11: Setting Hydrive Fan Speed

    NOTE A minimum 725 PSI (50 bar) is required to operate the HYDRIVE fan. MOUVEX recommends the fan speed remain at the factory setting of 2,800 rpm. 1. Operate hydraulic system at full load to properly set HYDRIVE fan speed.

  • Page 12: Operation

    3. Set the tractor RPM to the required speed to obtain desired system operation. DO NOT overspeed the QUICK RELEASE COUPLINGS MUST BE MOUVEX pump or compressor. FULLY CONNECTED. FAILURE TO DO 4. Inspect system for hydraulic oil leaks and for HYDRIVE SO CAN CAUSE PERSONAL INJURY OR fan operation.

  • Page 13: Maintenance

    5. MAINTENANCE 5.2 Return filter replacement NOTICE HYDRIVE SERVICE SHALL BE PERFORMED BY Check the return filter (19) at least every 3 months and QUALIFIED TECHNICIANS ONLY. SERVICE SHALL replaced at least every 12 months (see Figure 10). CONFORM TO ALL APPLICABLE LOCAL AND 1.

  • Page 14: Troubleshooting

    6. TROUBLESHOOTING PROBLEM CAUSE CORRECTIVE ACTION Insufficient oil getting to the pump. See “Cavitation”. Aeration of the oil Air entering the system. See “Air Entering the System”. (Oil goes milky) Water entering the system. Tighten up all hose connections. Inspect suction pipe for splits. Replace as required.

  • Page 15: Storage Conditions

    7. STORAGE CONDITIONS The equipment must be systematically stored in an area shel- If installation is interrupted, put back in place the original pro- tered from bad weather. tective components or equivalent components. The equipment must bear its original protective components until it is installed in its final application.

  • Page 16: Certificate Of Conformity

    Quality Manager MOUVEX sas : Z.I La Plaine des Isles – 2, rue des Caillottes - 89000 AUXERRE – France – SAS au capital de 8 496 855 € Tél : (33) 3.86.49.86.30 – Fax : (33) 3.86.46.42.10 – RCS AUXERRE 389 236 548 – APE 291 B – FR 85 389 236 548 www.mouvex.com...
