normal operation and expected malfunction.
b. Electro static charges
The only non-conductive
equipment is the plastic handle grip. The
surface resistance of the material does not
exceed 1GΩ at (23
relative humidity.
designed and constructed with an electrical
continuity design between ball, stem and
body. Any occurrence of efficient electro
static charge will be earthed through the pipe
line earthing.
c. Containing light metals
Materials used in the construction of external
parts do not contain light metals more than
7.5% of magnesium.
d. Equipment was tested in factory according to
high pressure leakage test before delivery. It
will not release flammable gases to explosive
atmosphere outside the equipment.
e. The internal parts, such as seals and packing
can be adversely affected by some solvents.
List of solvents which are known to be
compatible with the seal and packing
material are provided in the corrosion data
information.
f. The equipment also conforms to Pressure
Equipment Directive
mechanical strength of the structure can
withstand the hazard cause by internal
pressure.
11. Marking
Mfg logo: MD
Mfg location: TAICHUNG, Taiwan
Mfg year: 2009
CE mark: CE for DN 25 and smaller
CE for DN 32 and larger
0035
Max. working pressure:
For PN16: 14.7bar at -20°C,
10.3bar at 200°C
ATEX mark
Group II, category 2 equipment,
II2DGc:
Dust & Gas application,
Constructional safety according to
part of the
2) C and (50 5)%
The equipment also
(97/23/EC), The
EN 13463-5:2003.
T.F ref. No. ATEX-TF-0701: Technical file
reference number provided by ATEX
certification body.
Other identification such as
Shell Material
1.0619), PN (bar),
marked on the shell respectively.
DN (size in mm),
(1.4408 or 1.4308 or
Heat number are
