Declaration Of Conformity (Doc) - Nexo Digital TDcontroller Series User Manual

Drawings and dimensions
DTD-T model
MADE IN FRANCE
90-240V~ 50/60 Hz 20W
DTD-I model
90-240V~ 50/60 Hz 20W MADE IN FRANCE

Declaration of conformity (DoC)

We,
NEXO S.A.
ZA du Pre de la Dame Jeanne
60128 Plailly
France
Declare under our sole responsibility that the products
Professional Audio Equipment
Model:
Manufacturer name:
Manufacturer address:
CE Mark first affixed in:
to which this declaration relates is in conformity with the following standard(s) or other normative document(s)
EN 55103-1:2009 / EN 55103-2:2009 / J55013 (H22)
EN61000-3-2:2006 + A1:2009 + A2:2009 / EN61000-3-3:2008
FCC Part 15 :2013
IEC 60065:2001 (Seventh Edition) + A1:2005 + A2:2010
CSA 60065-03 + Am 1(2006) / UL 60065 / K06065 / J60065 (H23)
Plailly, France
Date: September 18, 2015
DRAWINGS AND DIMENSIONS
480 mm
SUB AMP MAIN AMP
IN IN
Always connect to amplifiers outputs
1+/1- LEFT channel / 2+/2- RIGHT channel
SPEED LINK / ACT
480 mm
Always connect to amplifiers outputs
SUB AMP MAIN AMP
+ R - + L - + R - + L -
SPEED LINK / ACT
DTD-T-U, DTD-T-N, DTD-I-U, DTD-I-N
NEXO S.A.
ZA du Pre de la Dame Jeanne, 60128 Plailly, France
2015
PAGE 8 OF 16
AES/EBU SUB MONO MAIN RIGHT
IN OUT
44.1 TO 96 KHZ BALANCED ANALOG OUTPUTS
BALANCED
ANALOG OUT
AES/EBU IN
SUB MONO MAIN RIGHT
44.1 TO 96 KHZ
OUT
G + - G + -
MAIN LEFT
OUT OUT
BALANCED
ANALOG IN
IN IN
RIGHT LEFT
MAIN LEFT
OUT OUT
G + - G + - G + - G + -
Joseph CARCOPINO
R&D Director, NEXO
44
mm
480
44
mm
