3D PRO Scanning Camera
Item List
3D PRO
Mobile
Power Cable
Camera
Power Bank
Part Name
Front Side
Back Side
Camera Installation
1. Affix the camera on
2. Stabilize the camera by
the tripod by aligning
holding the camera plate
the tripod mount
and turning clockwise.
(small holes located
Tighten so that the
on the bottom of the
camera) on the bolts
camera plate is fixed to
of the tripod.
the tripod.
Product Manual
Power
Scanning
Adapter
Software
* Pictures are for reference only
❶ Infrared Receiver Camera
❷ RGB Color Camera
❸ Infrared Transmitter
❹ Camera WIFI Amplifier
❺ Camera Power Switch
❻ Power Cable Interface
3. Adjust the tripod to the
required height. Connect to
the mobile power bank via
the power cable. The mobile
power bank can hang down
from the tripod.
Operation Guide
1. Install Scan Application "3DNest" on your iPad
2. Switch on the camera, and the camera's WIFI network will turn on automatically
3. Open the iPad's WIFI connection and connect to the camera's WIFI network (the
network will begin with the letter "N")
4. Control scanning via 3DNest application on the iPad
* Refer to "3D Reality Capture User Manual" for detailed instructions
3D PRO Camera Specifications
Camera Model
Weight
Size
Color
Lens
Camera WIFI
Input Voltage
Operating Temperature
Storage Temperature
Scanning Range
Mobile Power Bank Specifications
Power Bank Capacity
Charging Time
Battery Life
Input Voltage
Input Frequency
Output Voltage
Output Current
Password: 3dnestnest3d
N300 series
3.5kg
210 x 203 x 125 mm
Black
9 Lens in 3 groups
802.11 b/g/n 2.4GHz
14.8V
10℃ ‐ 32℃
0℃ ‐ 40℃
3.5m ‐ 5.0m
10,000mAh
2 ‐ 3 hours
4 ‐ 5 hours
220V
50/60Hz
14.8V
2A
Advertisement
Summary of Contents for SilvrCraft 3D PRO N300 series
- Page 1 3D PRO Scanning Camera Product Manual Item List Operation Guide 1. Install Scan Application “3DNest” on your iPad 2. Switch on the camera, and the camera’s WIFI network will turn on automatically 3. Open the iPad's WIFI connection and connect to the camera's WIFI network (the network will begin with the letter “N”) 3D PRO Mobile Power Scanning Power Cable Camera Power Bank Adapter Software Password: 3dnestnest3d * Pictures are for reference only Part Name ❶ Infrared Receiver Camera 4. Control scanning via 3DNest application on the iPad ❷ RGB Color Camera * Refer to "3D Reality Capture User Manual" for detailed instructions ❸ Infrared Transmitter 3D PRO Camera Specifications ❹ Camera WIFI Amplifier ❺ Camera Power Switch Camera Model N300 series ❻ Power Cable Interface Weight 3.5kg Front Side...
- Page 2 45 seconds to reduce back to normal temperature Disclaimer to connect to the 2. Wait for the camera to cool down before turning the Camera camera back on 3. Too long distance between the camera and laptop This manual has been prepared with substantial effort to make the content correct and computer may result in slower connection speeds complete, but there is no guarantee that there are no errors or omissions 1. Make sure the battery voltage is above 14.7V. If lower than 14.7V, please recharge the battery SilVRcraft reserves the right to make changes to the hardware and/or software Inadvertent loss of 2. Check the laptop’s WIFI signal strength. If the WIFI connection between specifications mentioned in this manual at any time without prior notice signal is weak, please shorten the distance between the the laptop and the laptop and the camera No part of this manual may be reproduced, transmitted, transcribed, stored in a camera 3. Make sure the laptop is still connected to the camera searchable system, or translated into any language in any form without the prior WIFI. Sometimes when the written permission of SilVRcraft When uploading the ...
