1. Introduction 1.1 Introduction This machine has been designed to set eyelets (grommets) and washers, in one step. EMBLEM EASY AIRPRESS Standard can set eyelets on materials such us PVC coated material and in general terms on plasticized fabrics with a strength of 0,3 - 1,2mm. 1.2 Machine Identification And “CE” Marking Each machine has a lable on the side, with the following specifications: - Manufacturer’s name and data. - "CE" Mark - Model and serial number. - Weight - Maximum air pressure (in bars). Gutenbergstr. 15 D-24558 Henstedt-Ulzburg Modell EMBLEM Easy-Airpress Standard item Seriennummer serialnumber Gewicht weight Max. Pressdruck 8 Bar max press Page - 3 -... -
Page 4: Installation
2 Installation 2.1 Installation Position Requirements The minimum space recommended must be sufficient to keep that safety space in all directions for the operator to work properly. 2.2 Pneumatic Installation The machine has an air inlet valve, type quick acting coupler (ISO 6150- B standard) 8 mm, located on the back of the machine. For an optimal operation, the supply of compressed air should be 6 kg/cm , adjusted with a pressure gauge that customer’s will have installed on its compressor. 2.3 Transport If it is necessary to transport the machine again after its installation and the customer does not have the original packaging, we advice to use a reinforced package (wood or cardboard). 2.4 And Holding The Box Firmly Before any operation with the equipment, the machine must be properly fixed to the bench (from the customer) with 4xM8 screws (8.8 quality), washers and self-locking nuts. 2.5 Learning Instructions The following set of instructions and warnings about EMBLEM Easy AIRPRESS Standard should always be taken in account: Before connecting the machine to the compressor or to customer’s pneumatic installation, it should be place on its permanent location. • The cleaning, handling or replacement of parts should always be made with the air inlet valve shut. • Do not remove from the machine the safety devices, stickers or warning signs that point out dangerous areas. -
Page 5: Technical Data
3 Technical Data 3.1 Machine Specifications And Operation The EMBLEM AIRPRESS Standard has been designed to bolt it to the customer’s work bench or the optional Table. Once the machine has been placed on its permanent location, without fitting the air hosepipe into the connection, verify that it has not suffered any blow or breakage while being transported and it has not any loose parts. The operation of the machine is very simple: Fig. 2 Fig 1 ). When pressing down manually the safety protection “P”, with the black plastic knob placed on the front and side of the machine, until it reaches completely its stroke (position “ON”, see Fig. 4), preventing the access of operator’s hands to the setting area “X”, the screw “Y” placed on the side makes contact and activates the micro end of race which sets the pneumatic cylinder in motion). Position "off" Position "on" Fig. 3 Fig. 4 ). The pneumatic cylinder “B” causes its vertical axle to descend. Attached to its lower part there is one puncher “C” and a setting die “D”. The aim of the downward movement of the axle is to cut a hole with the puncher and as an effect of the pressure that the top die “D” puts on the bottom one “E”, to set the eyelet (grommet) on the setting area “X”. Page - 5 -... -
Page 6: Main Technical Data
). After the eyelet is set and once the pressure on the black plastic knob of the safety protection “P” has been released, it will automatically come up by a return spring located in the guide that holds the safety protection to the machine, the pneumatic cylinder will return and the machine will be again on its starting position ready for a new cycle. 3.2 Main Technical Data The main technical data of this machine are: WxDxH 300 x 130 x 220 mm Weight 9 Kg Air pressure 6 Kg/cm² Page - 6 -... -
Page 7: Machine Operation
4. Machine Operation 4.1 Machine Description This machine has been designed to set eyelets (grommets) with washers, feeding the machine by hand, on PVC coated material and in general terms on plasticized fabrics with a strength of 0,3 - 1,2mm. The maximum cutting diameter is 11 mm. The machine cuts the material and sets the eyelet in just one operation. Dataplot GmbH disclaims any responsibility when using the machine for different uses than the ones covered on this operating manual. 4.2 Checking The Machine Before Starting Before starting the machine for the first time, or when the location of the machine is changed, or adjustments or part replacements are made, we advice customers to check that the machine has not suffered a blow or breakage. 4.3 Eyelet (Grommet) Setting a) Check that the air inlet valve “F” is on OPEN position (Fig. 14). b) Place the eyelet (grommet) “O” gently through the puncher “C” of the top die “D” checking that it stays firmly on the junction area puncher/top die. Fig. 7 c) Place the washer “A” on the bottom die “E” with the teethed surface upwards. Fig. 8 d) Place the banner on the stainless steel plate. e) Press down manually the safety protection “P”, with the black plastic knob placed on the front and side of the machine until it reaches completely its stroke to set the eyelet. Page - 7 -... -
Page 8: Other Machine Applications
Fig. 9 f) Release the safety protection “P” so it comes up by the return spring located on the guide that holds the protection with the machine. At the moment the machine will be ready to set an other eyelet. 4.4 Other Machine Applications To cut holes on the material, without setting eyelets, it will not be necessary to install specific tooling; it will be possible to make it with the same ones use to set the eyelets. See chapter 5 Adjustments, section 5.4. Only Cutting. WARNING: This machine should not be used for a different purpose than the one originally manufactured for and specified on this operating manual: To set eyelets (grommets) with washers, to cut holes on PVC coated material and in general terms on plasticized fabrics of the printing industry. -
Page 9: Adjustments
5. Adjustments 5.1 Warnings About The Adjustments Parts that should be replaced on a regular basis due to normal where are the cutting or bottom die “E” and setting on top die “D”. We will see that the parts need to be replaced when either the cutting or the setting is not accurate. We always recommend having a spare set of these parts on your stock. Puncher Fig. 10 When making adjustments if by any reason it is necessary to remove parts meant for operator safety (cover, stainless steel plate ...) remember to put them back where they belong and fasten them firmly. WARNING: Shut the general air inlet valve “F” (see Fig. 1) to change dies, make adjustments, install optional equipment or any other handling. 5.2 Dies Changing For Same Dimension Eyelet –... - Page 10 Puncher Fig. 11 To have an even cutting, the puncher (located on the setting die “D”, must be able to enter softly on the bottom die (see Fig. 11). We need to follow these steps: ) Machine should be as in Fig. 12. Fig. 12 ) Manually lower the safety protection “P” with the black plastic knob without releasing it when it has reached the end of the stroke. Fig. 13 ) Holding down the knob, shut the air inlet valve “F”. Fig. 14 ) Loosen the set screw “a” (see Fig. 13) of the bottom die “E” from the right hand side of the machine until the die can turn freely. Page - 10 -...
- Page 11 Fig. 15 ) Loosen the set screw “b” of the top die “D”. Fig. 16 ) Open the air inlet valve “F”, so the compressed air enters the cylinder and the main shaft comes up releasing the dies (Fig. 17 and 18). Take the dies out and shut the air inlet valve “F” for safety reasons. Fig. 17 Fig. 18 ) Out of the machine, take the new set of dies and gently enter the puncher of the top die “D” into the center hole of the cutting or bottom die “E” (see Fig. 16). Fig. 19 ) Place the new set of dies on the bottom shaft at the setting area with the set screws looking to the right hand side of the machine. ) Under the stainless steel plate tighten the set screw “a” (see Fig. Page - 11 -...
- Page 12 20) of the bottom die “E” from the right side of the machine. Fig. 20 ) Open the air inlet valve “F” and manually lower the safety protection “P” (Fig. 21) so the main shaft of the pneumatic cylinder comes down entering in the hole that the top die “D” has on its upper part. Please make sure that the set screw “b” does not point out on the inner part of the hole as it could damage the shaft. Fig. 21 ) Holding down the black plastic knob, close the air inlet valve “F”. Once the machine has been depressurized, release it checking that the main shaft does not move up. Fig. 22 ) Tighten the set screw “b” (see Fig. 23) of the top the die “D”. Page - 12 -...
-
Page 13: Cutting And Setting Adjustments
Fig. 23 ) Open again the air inlet valve “F” (see Fig. 17). Once these steps have been accomplished, the machine is properly adjusted, both for cutting of the material and setting of the eyelet while having a constant air pressure of 6 kg/cm 5.3 Cutting And Setting Adjustments It is not necessary to make any adjustments, just follow the steps on chapter 5.1. 5.4 “Only Cutting” Operation If you just need to cut the material, you can use the same dies without placing the eyelet/washer. Page - 13 -... -
Page 14: Maintenance
6. Maintenance 6.1 Mechanical Parts Of The Machine For an optimum operation of the machine we recommend to keep clean certain parts of the machine. The cleaning should be done with the machine disconnected from the air supply and with a rag that will leave no threads. It is very important for the correct holding of the eyelet on the top die that the area where the puncher touches the top die (see Fig. 23) is completely free of threads or dust, as otherwise the eyelet will come off easily. This area must be keep clean of threads Fig. 24 How often you will need to clean this area will depend of the number of eyelets set and the type of material being cut. When the machine is going to be a long period with no use we recommend to disconnect it from the compressor, clean it and cover it to avoid humidity and dust. 6.2 Pneumatic Parts Of The Machine The pneumatic parts of the machine do not need a specific maintenance. The machine must be connected to an air compressor or pneumatic circuit with air filter and pressure gauge to have a constant pressure of 6 kg/cm Page - 14 -... -
Page 15: Failures
7. Failures 7.1 Troubleshooting PROBLEM CAUSE SOLUTION The machine does not work. 1. Check that the air Connect the air hosepipe. hosepipe is connected to the compressor. 2. Check that the air inlet Open the inlet valve. valve is on position "ON" 3. Check that the Adjust the pressure gauge air pressure on the until the manometer has circuit is 6 Kg/cm² the correct pressure 4. Check that the Lower the protection all safety protection is on the way until it reaches its lower position the end of its stroke. The machine does not cut. 1. The edge of the Change the dies. bottom die is either worn our damaged. The eyelet crushed 1. Check that the pressure Adjust the pressure with the when setting. of the circuit is no more manometer to 6 Kg/cm². than 6 Kg/cm². The eyselet does not 1. Check that there are Clean the threads with a hold on the puncher... -
Page 16: Safety
8. Safety 8.1 Safety Devices The machine has a range of protection devices to prevent operator (except on maintenance or repairs) from accessing dangerous areas where he can be injured. The dangerous part of the machine is the setting area “X”, where operator has the risk of crushing his fingers or hands. Fig. 26 Fig. 25 The dangerous area “X” is protected with the following devices: Safety protection “P”: Before a cutting and setting cycle is made, this protectimust come down manually all its stroke and hold it on position “ON”, preventing the access of operator’s hands or fingers to the risk area “X”. Fig. 27 Pneumatic valve or security end of race “2”: This valve prevents the action of the pneumatic cylinder if the safety protection “P” is not on its lower position. Page - 16 -... - Page 17 Position "off" Position "on" Fig. 29 Fig. 28 General air inlet valve “3”: This valve allows manually opening or shutting the pneumatic air supply from the compressor or general air installation. As safety device, it has a decomb pressing system, when the valve changes its position from open to close; the compressed air on the internal circuit of the machine is expelled, preventing any unexpected action from the pneumatic cylinder when making assembling or adjustments on the machine. Open position Close position Fig. 31 Fig. 30 Page - 17 -...
-
Page 18: Annex
9. Annex 9.1 Spare Parts Listing Protection Damper Article nr. PMS060-006 Screw Article nr. PMS060-008 Cutting Tool Article nr. PMS060-009 Base Article nr. PMS060-010 Switcher Article nr. PMS060-007 Handle Article nr. PMS060-011 Page - 18 -... - Page 19 Pneumatic Article nr. PMS060-001 Valve Article nr. PMS060-002 Alignment Article nr. PMS060-003 Steel plate Article nr. PMS060-004 Track Article nr. PMS060-005 Dataplot Gmbh Gutenbergstrasse 15 D- 24558 Henstedt-Ulzburg Tel: +49 (0)4193-995-0 Fax: +49 (0)4193-995-220 www.dataplot.de email: info@dataplot.de Page - 19 -...
