Summary of Contents for Aztech Kyla Smart Smoke Sensor
- Page 1 User Guide...
- Page 2 Smart Smoke Sensor Thanks for using Aztech Kyla product If you need support or help, please visit www.kyla.aztech.com...
-
Page 3: Product Description
Product Description Base Networking Hole LED Indicator Sensor The Smart Smoke Sensor alarms when there is excess smoke detected indoors. It adopts high-performance electrochemical sensor, supports sound and flash alarm, has ultra-low power consumption for longer battery lifespan, and many other features. -
Page 4: Installation Tips
Installation Tips Bedroom Bedroom Bedroom Garage Aisle Living Room Kitchen Minimum Required Installation Basement Additional Required Installation To increase safety factors in single-layer house, at least a Smart Smoke Sensor in each bedroom and at 6m from chimney and gas fixture is suggested. To increase safety factors in multi-layer house, at least a Smart Smoke Sensor in each bedroom, in basement, and at 6m from chimney and gas fixture, is suggested. -
Page 5: Ceiling Mounting
Ceiling Mounting The preferred location to install smoke alarm is in the centre of the ceiling because smoke, heat, and combustion products rise to the ceiling and will lateral spread. Keep at least 30cm distance from lights or decorations, and at least 15cm away from walls and corner. - Page 6 Operation Guide Step 1: Download Aztech Kyla App from Google Play/App Store Aztech Kyla App Step 2: Login to Aztech Kyla App, then add “Smart Smoke Sensor” to device list to enable the device.
- Page 7 Step 3: Rotate the bracket counter-clockwise from the installation base, then remove the battery insulating film to turn on power.
- Page 8 Step 4: Follow the App prompt and press the networking hole for 2 seconds until a green LED flashes quickly. App will be prompted once succesfully connected. (Press the networking hole for 5 seconds to disconnect from the network. Wait until the green LED flashes slowly for 3 seconds which indicates that the device has disconnected successfully.)
- Page 9 Step 5: Remove the double-sided adhesive membrane on the mounting bracket, and rotate the smoke alarm into the bracket.
- Page 10 Status and Troubleshooting Alarm Status Light Sound Red LED flashes Normal every 53 seconds Red LED flashes Rapid Testing 4 times in 10 seconds Beeps LED flashes alternately Warm Up Beeps Once in 3 colors then go out Red LED flashes every Mute Mode 10 seconds Red LED flashes every...
- Page 11 Please refer to the following if the sensor doesn’t work normally: 1. Fault is caused by dirt with dust or oil, etc.,. Please clean the alarm properly. 2. Check whether the alarm is properly rotated into the mounting bracket. 3. Replace the battery and follow the battery positive and negative electrode.
- Page 12 Notes 1. This product can not be used for detecting natural gas (methane), propane, butane, and other combustible gas. 2. Clean once a month. Users may use household vacuum cleaner and soft brush when cleaning. 3. Do not use cleanser or solvent wipes on sensor. Avoid spraying air freshener, hair spray, oil paint or other aerosol near sensor.
-
Page 13: Technical Speci Cations
Technical Speci cations Product Dimensions: 60 x 60 x 49.2mm Alarm Volume: 85 dB/3m Alarm Current: ≤ 60mA Networking: Zigbee ZHA / Z-WAVE Operating Temperature: -10~50°C Working Humidity: Max 95% RH Wireless Networking Distance ≤ 100m (Open Area) - Page 14 ©2018 Aztech Technologies Pte Ltd. All rights reserved.
