Essential Home KAF-1200B1 Operating And Safety Instructions Manual

2.4l air fryer for household use only

Hide thumbs

Table Of Contents

2.4L AIR FRYER

Operating and Safety Instructions

- FOR HOUSEHOLD USE ONLY -

Table of Contents

Need help?

Do you have a question about the KAF-1200B1 and is the answer not in the manual?

Questions and answers

Bruce Farrell

March 7, 2025

All the markings for temperature and other settings are completely worn off - was given to me used as a gift. How **** l supposed to operate this?

Summary of Contents for Essential Home KAF-1200B1

Page 1 2.4L AIR FRYER Operating and Safety Instructions - FOR HOUSEHOLD USE ONLY -...
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS Definitions Whenever used, the following identify safety and property damage messages and designate a level of hazard seriousness. - This is the safety alert symbol. It alerts you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. DANGER –...
Page 3 DANGER Read all instructions carefully   Never immerse the product, which contains electrical components and the heating elements, in water nor rinse it under the tap.  Do not let any water or other liquid enter the appliance to prevent electric shock. ...
Page 4 Keep the main cord away from hot surfaces. Do not plug in the appliance or operate the control panel with wet hands. Always make sure that the plug is inserted into the wall socket properly. This appliance is not intended to be operated by means of an external timer or a separate remote control system. Do not place the appliance on or near combustible materials such as a tablecloth or curtain.
Page 5: Automatic Switch-Off
Always return the appliance to a service center authorized by sellers for examination or repair. Do not attempt to repair the appliance yourself, otherwise the guarantee becomes invalid. Always unplug the appliance after use. Let the appliance cool down for approx. 30 minutes before you handle or clean it. Make sure the ingredients prepared in this appliance come out golden-yellow instead of dark or brown.
Page 6: Polarized Plug
SHORT CORD PURPOSE Note: A short power cord is provided to reduce the risk of personal injury resulting form becoming entangled in or tripping over a longer cord. Longer power-supply cords or extension cords are available and may be used if care is exercised in their use. If an extension cord is used: (1) the marked electrical rating of the extension cord should be at least as great as the electrical rating of the product;...
Page 7: Operating Instructions
OPERATING INSTRUCTIONS: Small silicone caps Timer (0-30 min.)/power-on knob Grill rack Power-on light Handle Heating-up light Air outlet openings Air inlet Temperature control knob (80- Mains cord 200°C/176-392°F) )
Page 8 (How to install or uninstall the grill rack :fix the 4 caps and grill rack, then put them into the pan and make the bottom of grill rack touch the bottom of the pan, make sure the small metal bar of the grill rack is upward ,then it turn right till the grill rack was locked into the pan stably, then you can use this system like a basket with pan, and if you want to remove the grill rack, just turn the grill rack left till it’s loose, then remove the grill rack.)
Page 9: Before First Use
BEFORE FIRST USE 1. Remove all packaging material. 2. Remove any stickers or labels from the appliance. 3. Thoroughly clean the grill rack and the pan with hot water, some washing-up liquid and a non-abrasive sponge. 4. Wipe the inside and outside of the appliance with a moist cloth. This is an air fryer that works on hot air.
Page 10 Never use the pan without the grill rack locked safely in it. Caution: Do not touch the pan during and sometime after use, as it gets very hot. Only hold the pan by the handle. Tip :To fix the grill rack to the pan correctly, fix 4 silicone caps to the grill rack properly, then put the grill rack into the pan, make sure small metal bar of the grill rack is upward, then turn the bar right till the grill rack with four silicone caps was locked in the pan stably, upside the pan, the grill rack was fixed and will not drop.
Page 11  Excess oil from the ingredients is collected on the bottom of the pan. 8. Some ingredients require shaking halfway through the preparation time (see section ‘Settings’). To shake the ingredients, pull the pan out of the appliance by the handle and shake it. Then slide the pan back into the air fryer. Tip: If you set the timer to half the preparation time, you hear the timer bell when you have to shake the ingredients.
Page 12 Because the rapid air technology instantly reheats the air inside the appliance, pulling the pan briefly out of the appliance during hot air frying barely disturbs the process. TIPS Smaller ingredients usually require a slightly shorter preparation time than larger ingredients. A larger amount of ingredients only requires a slightly longer preparation time, a smaller amount of ingredients only requires a slightly shorter preparation time.
Page 13 Min-max Time Temperature Shake Extra Amount (min) (°C) Information Potatoes & fries Thin frozen fries 300-700 12-16 Shake 200°C/392℉ Thick frozen fries 300-700 12-20 200°C/392℉ Shake Home-made fries 300-800 18-25 Shake add ½ tbsp. of 180°C/352℉ (8x8 mm) Home-made 300-800 18-22 180°C/352℉...
Page 14: Making Home Made Fries
Note: Add 3 minutes to the preparation time when you start frying while the air fryer is still cold. MAKING HOME MADE FRIES For the best results, we advise to use pre-baked (e.g. frozen) fries. If you want to make home-made fries, follow the steps below.
Page 15: Troubleshooting
Tip: If dirt is stuck to the grill rack or the bottom of the pan, fill the pan with hot water with some washing-up liquid. Put the grill rack in the pan and let the pan and the grill rack soak for approximately 10 minutes.   4.
Page 16 The set temperature is too Turn the temperature control low. knob to the required temperature setting (see section ‘Settings’ in chapter ‘Using the appliance’). The preparation time is Turn the timer knob to the too short. required preparation time (see section ‘Settings’).
Page 17 White smoke comes out of You are preparing greasy When you fry greasy the appliance ingredients. ingredients in the air fryer, a large amount of oil will leak into the pan. The oil produces white smoke and the pan may heat up more than usual.
Page 18: Limited Warranty
Cut the potato sticks smaller for a crispier result. Add slightly more oil for a crispier result. Electrical Specifications Voltage Frequency Wattage 120 VAC 60 Hz 1300 W LIMITED WARRANTY This item is warranted to be free from defects in materials or workmanship for a period of one year from the original date of purchase under normal conditions of intended use.
Page 19 purchase upon presentation of sales receipt or other proof of purchase. This warranty extends only to the original retail purchaser and excludes any damage to the product resulting from accident, misuse, abuse, damage caused by electrical power surge, or operation not recommended or authorized by these operating and safety instructions. This warranty is voided if the product is ever used in a commercial or business environment.
Page 20 KSN # 09801094-5 Model # KAF-1200B1 ETL is a registered trademark of Intertek Testing Services NA, Inc. and is used under license. Distributed by Kmart Corporation, Hoffman Estates, IL 60179 SHOP Kmart.com For product information, questions, or customer service, e-mail: Electrical@reginte.com or call toll free 1-866-450-4683.
