- Page 1 EZ TANKLESS EZ ULTRA HE OPERATION & INSTALLATION MANUAL...
-
Page 2: Tankless Water Heater Specifications
EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 01. EZ ULTRA HE GAS TANKLESS WATER HEATER SPECIFICATIONS Maximum Gas Consumption BTU/h 70,000 Minimum Gas Consumption BTU/h 12,500 Hot Water Supply at 45f Temperature Rise 3.4GPM LPG (Propane) Inlet Pressure 11”... -
Page 3: Table Of Contents
EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 02. TABLE OF CONTENTS 01. Tankless Water Heater Specifications 02. Table of Contents 03. Limited Warranty 04. What’s Included 05. Features & Benefits 06. Installation 07. Safety Precautions 09. Initial Set-up and Operation 10. -
Page 4: Limited Warranty
WHAT WILL EZ TANKLESS PROVIDE? EZ Tankless will repair or replace the product or any part or component that is considered defective in materials or workmanship, except as set forth below: EZ Tankless will provide parts with free shipping for most repairs. EZ Tankless will perform labor and pay shipping costs to repair the product if deemed necessary by EZ Tankless. -
Page 5: What's Included
EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 04. 2.0 WHAT’S INCLUDED? 1 x EZ Ultra HE Tankless Water Heater 1 x Expandable Screw 2 x Drywall Anchors 2 x Mounting Screws 2 x Self-tapping screw Flue pipe 3 x NPT connector 1/2’’... -
Page 6: Features & Benefits
• Low Water Pressure Start-Up – The EZ Ultra HE will fire at 0.6 GPM at a pressure as low as 3psi. • Temperature Memory – Upon startup, the unit will operate to the last set temperature used. If the unit is powered off or unplugged it will remember the last temperature used so when power returns it’s still... -
Page 7: Installation
Contact your local licensed plumber for a proper installation of the EZ Ultra HE tankless water heater. Do not install this unit by yourself if you are not a licensed plumber. The EZ Ultra HE uses a forced exhaust which must be installed according to the instructions in this manual and all local codes. -
Page 8: Safety Precautions
4.3 – INSTALLATION OF EXHAUST PIPE The EZ Ultra HE is a forced exhaust tankless water heater which must be vented to the outside using either the flue provided or 2” solid core PVC/CPVC schedule 40. The flue can be used horizontally through an exterior wall or vertically through the roof. - Page 9 EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 08. 5.2 SCALDS-FIRST AID GUIDANCE Remove clothing & jewelry - remove all wet clothing, quickly, as wet clothing retains the heat. Apply cold water for 30 minutes - immediately submerge the burnt area in cold water for 30 minutes to reduce the heat in the skin, preventing deeper burning.
-
Page 10: Initial Setup And Operation
EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 09. 6.0 INITIAL SETUP AND OPERATION CELSIUS FAHRENHEIT Note: These steps should be followed for every new location or water source 1. ON/OFF SWITCH Turn the systems power on. Display will light up with temp. -
Page 11: Special Notes & Installations
4. USE A SURGE PROTECTOR The EZ Ultra HE uses many sensors that are based on resistors. It is important to protect the electronics of the EZ Ultra HE system by plugging the units power cord into a surge protector. - Page 12 EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 11. DESCRIPTION 13-7/8” or 351mm Width 4-7/8” or 125mm Depth Height - Unit 22-7/8” or 566mm 24-5/16” or 618mm Height - Including Brackets 3/4” of 20mm Hot Water Outlet (from wall) 1-3/4”...
- Page 13 EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 12. EZ TANKLESS ULTRA-HE WATER HEATER 3/4" GAS CONNECTION 1/2” 3/4" HOT WATER SUPPLY LINE 1/2” FOR BUILDING FIXTURES 1/2” 3/4" COLD WATER SUPPLY LINE GAS SUPPLY This drawing is not an engineered drawing. It is intended for use only as a guide and does not act as replacement for professionally engineered installation drawings.
-
Page 14: Operation Of The Ez Ultra He
EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE13. 7.0 OPERATION OF THE EZ ULTRA HE 7.1 – INITIAL USE Before operating the unit make sure connections are sealed (water and gas) as well as proper installation of the flue. After confirming, proceed as follows: Open the cold and hot water valve at the unit. - Page 15 TIME-OUT PROTECTION The EZ Ultra HE will shut down after 50 minutes of continuous operation. If you need to use hot water longer than 50 continuous minutes, close the hot water tap and open it back up to re-fire the unit.
- Page 16 04. If you hear any abnormal noise, outside of normal operation, contact your local plumber or EZ Tankless to check the problem. Do not operate the unit until the problem is solved. 05. Do not open the cover of the unit unless instructed by EZ Tankless to avoid accidental damage.
-
Page 17: Recommended Ez Ultra He Maintenance
The cover of your water heater will become hot during use. It is not recommended to place any stickers, magnets, or other decorative material on the cover of the EZ Ultra HE. Be sure to wipe away any dirt or debris that may be... - Page 18 EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 17. NON-MALFUNCTIONING SYMPTOMS & SOLUTIONS SYMPTOMS SOLUTIONS White smoke can be caused from the hot air exiting the exhaust White smoke coming from flue into cooler temperatures outside. This is normal.
-
Page 19: Error Codes
EZ TANKLESS ULTRA HE OPERATION + INSTALLATION MANUAL PAGE 18. 9.0 ERROR CODES Error codes will be displayed in the temperature read-out if there is a malfunction. Call EZ Tankless if you have any questions (765)885-5125 ERROR CODE ERROR CODE DESCRIPTION CONFIRMATION &... - Page 20 CONTACT US EZ TANKLESS, INC. 120 N WASHINGTON AVE FOWLER, IN 47944 SALES DEPARTMENT: SALES@EZTANKLESS.COM 219-369-4781 SUPPORT DEPARTMENT: SUPPORT@EZTANKLESS.COM 765-885-5125...
