INSTALLATION & INSTRUCTIONS
The
Water Filtration & Purification System
technologies of filtration and purification using methods of reverse osmosis and re-
mineralization.
Once installed, the
or office.
is connected directly to your existing water line. The water goes through the
following stages of filtration:
Stage 1
– The 5-micron sediment filter removes suspended matter from tap water by
passing it through a cartridge filter preparing the water for the reverse osmosis
membrane.
Stage 2
– Pre-Carbon filter contains granular activated carbon to remove chlorine and
other chemical contaminants, protecting the Reverse Osmosis Membrane.
Stage 3
– The Reverse Osmosis Membrane (RO) is a semi-permeable membrane and
considered the heart of the system. Here the remaining suspended solids and most of
the dissolved impurities are separated from the water molecule and flushed down the
drain.
Stage 4
– Re-mineralization Filter enhances and clarifies your water prior to delivery,
adding those minerals essential to the human body. In addition, this filter re-
established and elevates ph levels supplying you with crystal clear, great tasting water.
Stage 5
– Post Carbon Filter contains block activated carbon to remove any residual
taste and odor.
system produces the highest quality water for your home
-1-
www.pur2o.com
973-794-3175
1 - 888-393-1828
MANUAL
is unique and based on the newest

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Alkaline Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PUR2o Alkaline Plus

  • Page 1 973-794-3175 1 - 888-393-1828 MANUAL INSTALLATION & INSTRUCTIONS Water Filtration & Purification System is unique and based on the newest technologies of filtration and purification using methods of reverse osmosis and re- mineralization. Once installed, the system produces the highest quality water for your home or office.
  • Page 2 Options system comes with a selection of options: · Faucet finish - chrome or brushed-nickel · Pressure tank - 2 gallon, 3G, 10G, 14G and 20G Pressure Tank Service of the system The filters in the Reverse Osmosis Box Assembly - sediment, pre-carbon and post- carbon or 3-Pack must be replaced once a year.

  • Page 3: Tubing Connections

    Tubing Connections Tubing connections below designate tubing color and the label on the Reverse Osmosis Box Assembly associated with the fitting connection point. 1 – Connect ¼” tubing from the DRAIN PORT on the box unit to the DRAIN SADDLE VALVE.

  • Page 4: Installation Requirements

    INSTALLATION REQUIREMENTS The requirements below are necessary for correct installation, proper operation and to validate the warranty: •A pressure of 40 psi* (276 Kpa**) minimum and 100 psi (689 Kpa) maximum. •A temperature of 40-100 °F (5-35 °C). •Maximum total dissolved solids (TDS) 500 ppm. *** •Installation must comply with existing state and local plumbing codes.

  • Page 5: Faucet Installation

    For installation, you will need •Drill and drill bits •Teflon tape •Straight & Phillips screwdriver •Adjustable wrench •Work gloves •Pliers •Safety glasses •Knife or scissors Additional tools will be required for installation on sinks without a predrilled alternate faucet location. NOTE: DRILLING OF HOLES MAY BE NEEDED FOR THE FAUCET AND COLD WATER SADDLE VALVE.

  • Page 6: Mounting Faucet

    Mounting Faucet 1 - Locate Faucet kit. 2 - Insert faucet onto your sink/counter top hole. Place OPEN END HARD PLASTIC WASHER, LOCK NUT WAHER and HEX NUT onto the stem of the faucet. Tighten, securing the faucet to the sink/counter top. 3 - In the PARTS bag, take GRAY plastic ⅜”...

  • Page 7: Storage Tank Preparation

    Storage Tank Preparation 1 - Remove storage tank from its box, discard packing material. 2 - From parts bag locate: tank shut-off valve. 3 - Using Teflon tape (not included), wrap ¼” male treads on storage tank using clockwise motion. 4 - Install tank shut-off valve on storage tank as seen in figure “B”.
  • Page 8 Inlet Water Supply CAUTION: ONLY USE COLD WATER LINE. IF YOU CANNOT TELL WHICH LINE IS THE COLD, TURN ON WARM WATER AND FEEL FOR WARMTH. 1 - Locate the cold water line and shut-off valve for faucet. Shut off water supply. Turn cold water on at sink to release pressure.

  • Page 9: Troubleshooting

    Troubleshooting NOTE: TURN OFF THE SYSTEM BEFORE SERVICING. PROBLEM CAUSE SOLUTIONS Milky colored water Air in system Air in system is a normal occurrence with initial start-up of the RO system. This milky look will disappear during normal use within 1 to 2 weeks. Noise from faucet Location of drain saddle Relocate the drain to above water...
