Teknim TSD-701 Mounting And User Manual

TSD-701 /
Ceiling Type Gas Detector
IMPORTANT WARNINGS
GENERAL
 Before using the device read this
manual carefully. Keep it just in case of
necessity.
 Abide all the rules and precautions stated in the
manual. Follow all the instructions one by one.
 Keep the devices away from water and moisture
CONDITIONS
Do not energize the device above or below the given
limits of extreme hot or cold conditions,
Temperature:
Relative Moisture: %0- 95 concentrated
SERVICE
In case of any malfunction or below conditions contact
with your authorized service,
 When Mains cable or the plug is harmed,
 Contact of device with a fluid,
 Exposure of rain and water,
 Fell down of device or harmed outer cover,
 Serious performance fall on the device,
 Depending on the instructions stated in manual, if
your device not working properly, further usage or
possible wrong usage may cause other
malfunctions. Contact with your authorized service
in such terms.
INFORMATION RELATING TO USAGE ERRORS
Do not allow to change the opening or setting up your
device by unauthorized persons. As a result of such a
situation, your device can start working differently
compared to the first case.
SECURITY CHECK
Please ask your dealer to check that the service is
working properly and safe conditions.
.
NO
NC
Mounting and User Manual
Issue Date: 29/09/2016
Between 0C and +55C
R:01
TO BE CONSIDERED AND CONSUMER CAN DO
TO MAINTAIN, REPAIR AND CLEANING
- Do not attempt to repair the device yourself,
because if you open the oven door or tampering
can be exposed to possible electric shock or cause
a malfunction of the device.
- If a fault occurs, please contact your dealer or
authorized service
intervention must be carried out by authorized
service personnel qualified.
- The device should be cleaned with a damp cloth.
Never spray, polish, do not use any chemicals such
as detergents.
- Alcohol, thinner, cologne, sprays, lighter too
intense, pungent cleaning agents do not mislead
the device to false alarms and may cause
deterioration of the detector. In addition, gas
detection holes must be clean and dry.
TRANSPORTATION
Device must be carefully transported avoiding all
physical bump, stroke and possible fluid entry.
Malfunctions that caused by improper transportation is
not under warranty.
Model
Supply Voltage
Type
IP Rating
Compatible Standard
Contact Output
Startup Time
Normal Condition Led Color
Error Condition Led Color
Alarm Condition Led Color
Alarm Level (Natural gas)
Output Relay
Alarm Output
Alarm Buzzer Sound Level
center. Device technical
TSD-701
12-24 VDC
A
IPX2D
TS EN 50194-1
1 pcs, NC or NO
3 minutes
Green
Yellow
Red
%10 LEL
30 V DC, 50mA
Solid State Relay +
Voice and flashing leds
85 dB
