- Page 1 USER MANUAL READ CAREFULLY BEFORE SERIAL NUMBER: PWM100777 AND UP © 2015 Portable Winch Co. – All Rights Reserved www.600mh.com English Version – Printed in Canada...
-
Page 2: Table Of Contents
SUMMARY INTRODUCTION – p. 3 1.0 SAFETY GUIDELINES – p. 3 1.1 Safety messages – p. 3 1.2 Labels – p. 4 1.2.1 Serial number label – p. 4 1.2.2 Sound pressure level label – p. 4 1.2.3 Read the user manual label – p. 4 1.2.4 Safety equipment label –... -
Page 3: Introduction
INTRODUCTION Portable Winch Co. wishes to thank you for purchasing a PWM600MH Perimeter Wire Machine. This manual was written to help you make the best use of your new machine and to use it in the most secure way. For any problems or questions please refer to an EAD IT CAREFULLY BEFORE USING THE MACHINE. -
Page 4: Labels
5. The CE mark. 1.2.2 Sound pressure level label The sound pressure level label indicates that the guaranteed measured sound pressure level is 105 dB. We recommend wearing hearing protection when using the PWM600MH Perimeter Wire Machine. 1.2.3 Read the user manual label The read the user manual label indicates that it is necessary to read the entirety of this manual as well as the Honda engine user manual before using the machine. -
Page 5: Warning Label For Potential Dangers Of The Blade
1.2.5 Warning label for potential dangers of the blade This warning label informs you of the following potential dangers: Debris could be launched and cause injuries to the eyes; The blade can crush feet; The blade can crush hands; ... - Page 6 Clean and/or replace all security labels that are dirty, deteriorated, unreadable or torn. Always wear safety glasses with deflectors when using the machine. Always wear anti-vibration gloves when using the machine. Always wear hearing protectors when using the machine. Always wear steel-toe work boots when using the machine. Do not back up the machine unless absolutely necessary.
-
Page 7: Pre-Operation Checks
Inspect the box to detect any obvious damage. If a part is missing or damaged, notify the carrier immediately. Here is what you should find in the box: 1x PWM600MH - PERIMETER WIRE MACHINE - 600MH 1x 10-0303 - REVERSIBLE BLADE TYPE 7 1x 70-0056 - WIRE GUIDE ASSEMBLY ... -
Page 8: Assembly And Start-Up
2.2 Assembly and start-up The PWM600MH Perimeter Wire Machine was completely assembled at the factory except for the following parts: blade, wire guide, sliding foot, blade pulley cover, wheels and handle. To assure a safe and appropriate usage, these parts must be attached securely. Use the 4 mm key to ensure they are tightened sufficiently. -
Page 9: Installing The Wheels
2.2.2 Installing the wheels 1) Remove the adhesive tape and take the small key on the wheel hub; 2) Use your 4 mm hex key to remove the screw and the washer from the hub; 3) Insert the wheel with its valve side exterior;... -
Page 10: Preparing And Starting Engine
2.2.5 Preparing and starting engine The PWM600MH Perimeter Wire Machine is equipped with a Honda 4-stroke GXH-50cc engine. 2.2.5.1 Engine Oil Fill the Honda engine with a maximum of 0.25 liters of SAE 10W-30 API SJ oil. For special uses and in extreme temperature conditions, consult the Honda engine manual. -
Page 11: First Use
2.2.5.3 First use IMPORTANT: Before installing the blade and wire guide, start the engine and let it run at idle speed for five (5) minutes. Consult the Honda engine manual for starting instructions. The on/off switch is located on the engine. Take care to pull the starter grip in the output axis of the rope. -
Page 12: Installing The Wire Guide
2.2.6 Installing the wire guide Remove the bolt from the blade transmission housing. Position the wire guide in the cavity and tighten the bolt (Figures below). 2.2.7 Installing the blade IMPORTANT: Type 7 blade included has two sides: one for hard, compacted soil, and one for normal grass. -
Page 13: Usage
3.0 USAGE IMPORTANT: Its compact size and low weight allow the PWM600MH Perimeter Wire Machine to be easily carried in a small vehicle. It is strongly recommended that you turn the fuel valve to the off position (OFF). Before each use: ... -
Page 14: Wire Coils Without Drums
Some manufacturers provide a coil designed to be emptied through the center. Two (2) Perimeter Wire Boxes (18 CM X 18 CM – Part number PWMA-0002 and 22.5 CM X 22.5 CM – Part number PWMA- 0003), that are available as optional accessories for the PWM600MH Perimeter Wire Machine, accept this type of coil (up to 17.5 cm or 21 cm diameter, depending of the wire box used):... -
Page 15: Wire Coils Without A Drum
3.1.2.2 Wire coils without a drum Some manufacturers provide wire designed to be manually wound on a drum. As an optional accessory for The PWM600MH Perimeter Wire Machine, a PERIMETER WIRE DRUM (part number: PWMA-0001) is available for this type of wire to be wound upon: 1) Upon receiving the machine, the hardware is already installed on the shaft;... - Page 16 3) Remove the two (2) screws and their small washers to take out the adjustable spool support. Once removed, put the screws and washers back in place to avoid losing them (Figure 2); 4) Remove the nylon nut from the shaft using locking pliers (at middle of the shaft to prevent damaging the essential threads) and a 19 mm socket wrench.
-
Page 17: Moving The Machine To The Working Zone
3) Lift the support foot in front the machine; 4) Pull or push the machine to the work area. 3.3 Using the distance guide The PWM600MH Perimeter Wire Machine is equipped with an adjustable distance guide. It allows the machine to align itself with the edge of the course and bury the wire at a distance ranging from 15 cm to 45 cm. -
Page 18: Inserting The Perimeter Wire In The Wire Guide
3.5 Inserting the perimeter wire in the wire guide Proceed as follows : 1) Pull the end of wire from the coil (Figure 1); 2) Insert the wire into the plastic tube (Figure 2); 3) Push the wire until it exits the wire guide (Figure 3). 3.6 Burying the perimeter wire in the ground Refer to the manufacturer's instructions of the robot mower for the technical specifications for installation of perimeter wire. -
Page 19: Adjusting The Handle Height
3.7 Adjusting the handle height It is important to adjust the handle to a comfortable height before working with the PWM600MH Perimeter Wire Machine. The recommended handle position is at the waist level, but adjust it to your preferred height using the handle clamping lever (see Figures). -
Page 20: Insertion Of Perimeter Wire In A Tight Corner
3.9 Insertion of perimeter wire in a tight corner When designing the PWM600MH Perimeter Wire Machine, every feature has been implemented to allow burying of the wire as close as possible to the perimeter of the field and to avoid manual burying of wire. - Page 21 5) Lower the handle until horizontal (Figure 6); 6) With your left hand on the chassis and your right hand on the traction handle, move the machine far enough to clear the corner and resume the normal working position (press the traction handle to move the machine) (Figure 7); 7) Once out of the corner, move the handle to the desired position to continue burying the wire (Figure 8).
-
Page 22: Maintenance
Check the engine as specified by the Honda manual 4.1 Belt adjustment The PWM600MH Perimeter Wire Machine is equipped with three (3) belts. These should be inspected and/or adjusted every ten (10) hours of use. In some cases, they should be replaced. The main reasons for replacing a worn belt are: cracking, loss of material, fraying, uneven wear or shiny spots resulting from heat or skating. -
Page 23: Adjusting The Engine Belt
4.1.1 Adjusting the engine belt 1) Loosen the 4 bolts (Figure 1 and 2); 2) Apply pressure by hand to the engine mount until the belt is tight (Figure 3); 3) Tighten the 4 bolts. 4.1.2 Adjusting the blade transmission belt 1) Loosen the 6 bolts (see Figure);... -
Page 24: Lubricating The Blade Transmission
10) Tighten all six (6) bolts. IMPORTANT: Use only GS-1000 Prolab 100% synthetic grease or equivalent. (Refer to Schedule II) 4.3 Storage Always store the PWM600MH Perimeter Wire Machine on its tires. Please consult the Honda engine user manual for storage instructions. -
Page 25: Additional Information
1 year warranty (serviced by Portable Winch Co. or retailers). Portable Winch Co. will repair or replace defective parts without charge for parts or labor if the part fails due to a defect in materials or workmanship during the warranty period. -
Page 26: Declaration Of Conformity
5.4 CE Declaration of conformity DECLARATION OF CONFORMITY PORTABLE WINCH CO. 1170 Thomas-Tremblay St. Sherbrooke, QC J1G 5G5 CANADA Tel: +1 819 563-2193 www.portablewinch.com Declare that this products Perimeter wire machine Model PWM600MH Serial number PWM100013 and up For intended purpose... -
Page 27: Technical Data
Full throttle engine speed: LpA value of 91 dB(A) with included uncertainty KWA = 2,5 dB 5.7 Vibration level The measured vibration level at the operator position is 25.39 m/s 5.8 Manufacturer The PWM600MH Perimeter Wire Machine is manufactured by: Portable Winch Co. 1170, Thomas-Tremblay St. -
Page 28: Schedule I: Exploded Views And Parts Lists
Schedule I: Exploded views and parts lists PWM600MH - PERIMETER WIRE MACHINE - 600MH VIEW PART # DESCRIPTION 43-0035 BELT 220-J 8 GROOVES 43-0044 BELT 190-J 8 GROOVES 70-0039 HANDLE ASS'Y 35-0001 INTERNAL TOOTH LOCK WASHER TYPE-A 1/4 - ZN 32-0027 BHCS M6-1.0 X 45mm - ZN... -
Page 29: Schedule Ii: Characteristics Of Gs-1000 Prolab Synthetic Grease
10-0258 LONG PLASTIC SPACER 10-0231 SPOOL CENTER HUB 10-0220 RUBBER DAMPER 10-0265 WING NUT 32-0039 SHCS M6-1 X 16mm - BLACK 10-0214 DISTANCE ROD 70-0056 WIRE GUIDE ASS'Y 10-0303 BLADE TYPE 7 32-0014 REAMER BOLT M6-1.0 X 23 - BLACK 43-0034 KEY 1/4 X 1/4 X 1 44-0038...
