Specifications, Installation and Operating

Woodsman Serene

Ultra Low Emission Burner

KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE

Proudly Manufactured By:

Instructions for the:

SERENE

Harris Home Fires

41 Braddon St

Addington

Christchurch 8024

New Zealand

Email sales@hhf.co.nz

Issued: May 2019 V1.2

P O Box 4043

Christchurch 8140

New Zealand

Phone 03 366 1796

Freephone 0800 3661796

Table of Contents

Need help?

Do you have a question about the Serene and is the answer not in the manual?

Questions and answers

Summary of Contents for Woodsman Serene

Page 1 Issued: May 2019 V1.2 Specifications, Installation and Operating Instructions for the: Woodsman Serene Ultra Low Emission Burner SERENE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Proudly Manufactured By: Harris Home Fires P O Box 4043 41 Braddon St Christchurch 8140 Addington...
Page 2: Testing And Certification
Cracked/broken door glass, makes the installation unsafe. Do not operate the fire with cracked glass. • Do not use the fire if there is a malfunction, a suspicion of breakage or unusual noises. Contact your nearest Woodsman dealer or Harris Home Fires.
Page 3: Before You Install
The installation of any solid fuel burner requires a Building Consent prior to installation commencing. We recommend the installation of a Woodsman solid fuel burner or flue system be undertaken by the holder of a current SFAIT (Solid Fuel Appliance Installa- tion Technician) qualification issued by the NZHHA (NZ Home Heating Association Inc.).
Page 4 Dimensions...
Page 5 Ceiling plate requirements The Serene has a minimum ceiling plate size of 400mm x 400mm Due to the Serene’s low rear clearance, the ceiling plate may be in close proximity to the wall. This may interfere with ceiling coving or mouldings where the wall and ceilings meet if.
Page 6: Ceiling Heights
Ceiling Heights All Woodsman free standing fires have been tested and approved to ASNZ 2918:2001 App B with a ceiling height of 2.4m and with the factory flue shield fitted in the below configurations. In some cases, the top of the flue shield terminates within 600mm of the ceiling height (refer to ASNZ 2918:2001 4.5.2) but all ceiling temperatures did not exceed the allowable limit in these cases and are therefore able to be installed.
Page 7: Minimum Flue Height
Your Woodsman appliance should be installed with a HeatSaver Flue System. A HeatSaver Flue System is available from all authorised Woodsman dealers throughout New Zealand. Use of a flue system other than a genuine HeatSaver Flue System may affect the safety of the installation, and may affect your warranty.
Page 8: Installation Instructions
HeatSaver Flue Kit Installation INSTALLATION INSTRUCTIONS • This HeatSaver flue system is tested and certified to AS/NZS 2918:2001 Appendix F, which means it is approved for use on all solid fuel appliances with a flue diameter of 150mm. • A copy of the Laboratory Test Certificate for this HeatSaver Flue System is included as part of these Installation Instructions, (refer to paperwork with flue kit).
Page 12 HeatSaver Flue Kit Certificate...
Page 13: Lighting Procedure
Lighting Procedure It is important to follow these steps to ensure the fire will operate as intended and to ensure a clean and efficient light up. What you will need: Approximately 16 pieces of kindling wood, about 1kg in weight (total) 4 x pieces of small sized wood (intermediate load 1), approximately 300mm in length, 1.2kg in weight (total) 4 x pieces of medium sized wood (intermediate load 2), approximately 300mm in length,...
Page 14 Lighting Procedure Continued Step 2. Light the fire lighter cubes Light the 3 fire lighter cubes. Once the fire lighters have caught well alight, the main door can be fully shut. 30 mins Step 3. Load intermediate load 2 (4 pieces) After approximately 30 minutes (or when the fire has burned down to red embers with minimal yellow flame), the fire is ready for the next load.
Page 15: Reloading Procedure
Appropriate Firewood Your Woodsman wood fire is designed to burn logs from trees which would typically be sourced from a reputable wood merchant as firewood. The most common species is radiata pine, which is a soft wood. Other common species of wood like macrocarpa are also appropriate to use and some hard woods like eucalyptus (bluegum) can also be used in conjunction with softwood.
Page 16: Creosote Formation
Creosote Formation A small intense fire is preferable to a large smouldering one, to reduce the amount of creosote. When wood is burned slowly it produces tar and other organic vapours, which combine with expelled vapour to form creosote. These creosote vapours condense in the relatively cool flue of a slow burning fire. As a result, creosote residue accumulates on the flue.
Page 17 Cleaning the Outside of the Fire Woodsman fires are finished in a high temperature paint. Only use a damp cloth (no • chemicals) when cleaning the outside of the fire. If any scratches occur, you can easily touch up the fire with an aerosol can of matching paint.
Page 18 Fire Safe Drawer (Not Available in Wood Box model) Your Serene comes with a Fire Safe Drawer located in the pedestal of the fire. Its purpose is to provide a convenient place to store kindling wood, matches, newspaper and natural fire lighters. Having a place to store these items can make it very quick and easy to light your fire and reduce clutter around the fire.
Page 19 (Not Available in Wood Box model) Your Serene comes with a No Mess Ash Scoop located on top of the Fire Safe Drawer, in the pedestal of the fire. Its purpose is to provide a clean and simple way to remove ashes from the fire.
Page 20 Consumables Some parts of your Woodsman fire are considered consumable. They are designed to be replaced as they will degrade over time. The life of the consumables will vary depending on; • Frequency of use. How often is the fire used? •...
Page 21 Fitting the Wetback To The Firebox Instructions for fitting a loose wetback to the firebox where the fire has been pre-punched with wetback holes. Remove knock-outs and cover plates in the rear panels • Remove top rear firebrick • Undo coach bolts on firebox plug to expose wetback holes •...
Page 22: Useful Tips
Useful Tips Get the most out of your fire Tips for lighting the fire Use finely cut, dry kindling wood. • Firelighter cubes or gel work best when ensuring ignition of the kindling. • Cross stack kindling over and around fire lighter like a small tower. •...
Page 23: Troubleshooting
• Identify where the water or moisture has come from and fix the problem. • Lightly sand the effected area and use matching Woodsman aerosol high temperature paint to touch up. My glass is dirty Your glass can get dirty easily if you use poor quality or wet wood or spend a lot of time with the fire on the low setting.
Page 24 Your Woodsman Serene is then covered by a further 5 year warranty on the fire box against defective materials and workmanship during normal domestic use. In the case of a claim after the first 10 years, It shall be the owner’s responsibility and...
