512 CHANNELS

•

1400 PROGRAMS (CUE, SUB, SEQ, CHAS)

•

1 GENERAL MASTER

•

1 SPEED FOLLOW

•

1 CROSS FADER / FLASH MASTER

•

1 SPEED STEP

•

24 CHANNEL POTENTIOMETERS

•

24 CHANNEL BUTTONS

•

28 OPERATING BUTTONS

•

38 OPERATING AND INDICATION LED

•

1 LCD (2 X 16 characters)

•

1 ON / OFF POWER SWITCHER

•

1 XLR 3 PINNS PLUG FOR DMX 512 OUTPUT

•

1 POWER PLUG

•

1 micro SD SLOT

•

Atel-Lights manufactures and presents COM-2 lighting console which is suitable for

theaters, concerts and places that require lighting control. It can create 1400 scenes at

512 channels. The console includes one LCD display with 2x16 characters that shows the

illumination quantum of the channels and the operating indications.

1-10 Buttons without LED: for arithmetic operations

1-24 Buttons with LED: operate like flash buttons on console channels or like group on

Console Operations.

BLACKOUT Button: for instantaneous interruption

CHASER Button: presents the chaser effects that have been created

FREEZE Button: cancels SPEED and FOLLOW potentiometers

REC Button: records scenes

EDIT Button: corrects the recordings

COPY Button: copies scenes

DEL. Button: eliminates operations

THRU Button: sets the time of channels or scenes

ATT Button: sets the illumination quantum of each channel

ENTER Button: completes every operation

PAGE/CHAN Button: selects the lighting page and channel

GO Button: increases the console operations

BACK Button: returns into previous state

QUE Button: creates or restores scenes

SUB Button: creates or restores SUB

COM-2 CONSOLE PRESENTATION

Table of Contents

Need help?

Do you have a question about the COM-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Atel-Lights COM-2

Page 1 • COM-2 CONSOLE PRESENTATION Atel-Lights manufactures and presents COM-2 lighting console which is suitable for theaters, concerts and places that require lighting control. It can create 1400 scenes at 512 channels. The console includes one LCD display with 2x16 characters that shows the illumination quantum of the channels and the operating indications.
Page 2 SEQ Button: creates or restores SEQ ESC Button: returns into previous state 1-24 Potentiometer: set the illumination quantum of channels and can operate like SUB MASTER as well CROSS/FLASH Potentiometer: goes over the next scene SPEED Potentiometer: changes the speed of fade in/ fade out steps FOLLOW SPEED Potentiometer: changes the duration that steps are constant G.
Page 3 double press ESC button. If you want to delete more than one scenes in sequence press DEL and then CUE, type the number of the first scene you want to delete, press THRU, type the number of the last scene you want to delete and complete the procedure by pressing ENTER.
Page 4 erase more than one SUB press DEL then SUB, type the number of the first SUB you want to remove, press THRU, type the number of the last SUB you want to remove and complete the delete by double pressing ENTER. e.g You wish to remove 5-8 SUB you press: DEL - SUB –...
Page 5 To edit the steps of a CHASER scene press EDIT then CHASER then type the number of the chaser you want to edit (e.g 1) and then POINT button. On the screen appears 1 STEP 1 the first 1 refers to chaser number and the second to step number. Type the step you want, do the editing using the potentiometers and complete pressing REC and then ENTER.
Page 6 then on the screen you can see the following indications: “Capacity: ..Files: ..”. Press ENTER again now on the screen you can see the following indications: “Select Action 1: READ, 2: WRITE”. Pressing 1 button you are able to read a file you have saved and by pressing 2 button you can write a new file and save it to the memory card.
