  • Page 1 StorSimple Safety Guide 5000-7000 Series Appliance September 2012...

  • Page 2: Table Of Contents

    Table of Contents Welcome ..........................3 Safety Notices ........................3 Safe Handling ..........................3 Safety ............................3 Rack System Precautions ......................4 Power Cooling Module Operation ...................5 ESD Precautions .........................6 Battery Disposal .........................6 Contacting Technical Support ..................7 775-0007-0200 Rev B © 2012 StorSimple, Inc.

  • Page 3: Welcome

    Welcome Thank you for purchasing a 5000/7000 series StorSimple appliance! This safety guide covers important information that will help ensure your safety while installing and using your appliance. Please carefully read and follow the instructions as detailed in the following sections.

  • Page 4: Rack System Precautions

    Rack System Precautions The following safety requirements must be considered when mounting in a rack cabinet. The following safety requirements must be considered when mounting in a rack  cabinet. 775-0007-0200 Rev B © 2012 StorSimple, Inc.

  • Page 5: Power Cooling Module Operation

    The appliance is designed to operate with two Power and Cooling Modules. Each of the PCM has a power supply and a dual-axis fan. During a critical condition, the system allows for a failure of one power supply while continuing normal operations. Two PCMs (and 775-0007-0200 Rev B © 2012 StorSimple, Inc.

  • Page 6: Esd Precautions

    Caution: The battery may present a risk of fire, explosion, or burns. Do not disassemble, crush, or heat above 60 degrees Celsius (140 degrees Fahrenheit) or incinerate. Replace the PCM battery with a battery provided by StorSimple only. Use of another battery may present a risk of fire or explosion.

  • Page 7: Contacting Technical Support

    StorSimple Data Recover Console (SDRC) for SharePoint and Exchange and the StorSimple Data Protection for managing Snapshots, Cloud Snapshots and Cloud Clones. Should you encounter any issues with your StorSimple appliance, please do not hesitate to contact StorSimple Technical Support at: Telephone: 1-855-2STORSIMPLE (1-855-278-6774) ...
  • Page 8 5000, 7000 Series StorSimple Appliance Rack Installation Guide September, 2012...
  • Page 9 Welcome ..........................3 Site Preparation ........................3 Installation Pre-requisites ....................3 Rack Mounting Rail Kit ......................3 Installation Procedure ......................3 Mounting the Appliance in the Rack ................5 Contacting Technical Support .................... 6 775-0005-0200 Rev D © 2012 StorSimple, Inc.

  • Page 10: Welcome

    Welcome Thank you for purchasing a 5000/7000 series StorSimple appliance! This rack mount installation guide will walk you through the steps necessary to install your appliance in a standard 19” rack with front and rear posts. The installation consists of multiple steps each of which is discussed in the following sections.
  • Page 11 Be sure the rail assembly is level. Secure the rail assembly to the rack vertical members using two of the (metric) screws  provided. There will be one screw used on the front and one on the rear. 775-0005-0200 Rev D © 2012 StorSimple, Inc.

  • Page 12: Mounting The Appliance In The Rack

    Secure the enclosure into the rack by installing one Philips screw (provided) through each  flange, left and right. Install the flange caps by pressing them into position. They snap into place.  775-0005-0200 Rev D © 2012 StorSimple, Inc.

  • Page 13: Contacting Technical Support

    SharePoint Database Optimizer (SSDO), the StorSimple Data Recover Console (SDRC) for SharePoint and Exchange and the StorSimple Data Protection for managing Snapshots, Cloud Snapshots, and Cloud Clones. Should you encounter any issues with your StorSimple appliance, please do not hesitate to contact StorSimple Technical Support at: Telephone: 1-855-2STORSIMPLE (1-855-278-6774) ...
  • Page 14 To complete the initial configuration, you’ll need to connect a serial console or a computer with terminal emulation to the StorSimple appliance. Use the serial cables and the accessories that came with your appliance. The serial connection must be set up as follows: 115.2Kbps, 8 data bits, 1 stop bit, no parity, flow control none or XON/XOFF.
  • Page 15 Pre-Requisites This guide describes the steps required to complete the power and cabling of your StorSimple 7520 appliance. You’ll need the following before you begin the power and cabling of your appliance: 4 power cables (2 each for the head unit and EBOD enclosure);...
