Using The Seat Harness - Redkite Lullaby Swing Instruction Leaflet

Storage and travel
Assembly instructions
1. Press the buttons on the inside of the hinges and open the legs.
2. Connect the base frame tubes to the bottom of the legs ensuring the push pins have come through
the holes.
3. Connect the rear and front seat frame supports to the swing section using the M4 screws provided.
4. Unthread the buckle straps on the back of the seat cover.
5. Slide the rear of the seat cover on to the rear seat support. Lift both seat frame supports upwards,
slide the front of the seat cover on to the front seat support and then push both seat supports back
down.
6. Ensure the shoulder harness is a snug fit around your child' s shoulders by selecting one of three
different height slots and rethread the buckle straps.
7. Using a Phillips screw driver, undo the battery compartment screw and pull the cover away.
8. Insert 4 x AA batteries observing the correct polarity.
9. Reattach battery cover.
10. Attach toy bar to the swing bars.

Using the seat harness

1. Flip the cover upwards and press the button in the centre of the harness clasp to release the straps.
2. Place your child in the seat, reattach the waist straps and pull the loose ends of the straps to take out
any slackness.
3. Fold the harness cover back down and check the shoulder straps at the back of the seat for correct
fitting. Adjust as necessary.
Storage and travel
1. Lift the seat supports upwards, push the release buttons on both side and slide the legs together.
