Aptos Design Lab Gtrackr ADSG001-0 User Manual

Gps & wireless locating system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Gtrackr
User Guide
GPS & Wireless Locating System
ADSG001-0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gtrackr ADSG001-0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aptos Design Lab Gtrackr ADSG001-0

  • Page 1 Gtrackr User Guide GPS & Wireless Locating System ADSG001-0...

  • Page 2: Table Of Contents

    Index Description & Feature ..........02 Specification ..............03 Product Overview ............04 Getting Started ........... 05 Driver Install .............. 07 Application Install ......09 Bluetooth GPS Receiver for Navigation ............... 12 Security Tracker ............15 Phone Number Setup ............16 Time Interval Setup ..............

  • Page 3: Description & Feature

    Description & Feature Gtrackr is a data logger device that can store more than 120 hours travelling routes. Through USB port, user can use our application to merge the inside data with his photos for map application. It also can be treated as a small Bluetooth-GPS receiver and combine with handheld devices for easily navigating.

  • Page 4: Specification

    Specification Frequency L1, 1575.42MHz Accuracy Position 2.5m CEP, Velocity 0.1m/sec, Timing 300ns Acquisition Cold start 35 seconds average Open Sky Warm start 30 seconds average Hot start 1 second average Sensitivity -161dBm Green – GPS status, Blue – BT status, Red –...

  • Page 5: Product Overview

    Product Overview GPS indicator (Green) Low power indicator (Orange) Charge indicator (Red) Bluetooth indicator (Blue) Power Slide Switch Tracking Function Navigation Function Data Log Function Mini USB (Power Charge & Connect with PC)

  • Page 6: Getting Started Driver Install

    Getting Started Driver Install 1. Insert the CD-ROM in your PC 2. The system will pop out the application for install 3. Select Install USB Driver...
  • Page 7 Getting Started Please follow the steps to complete the setup.

  • Page 8: Application Install

    Getting Started Application Install 1. Insert the CD-ROM in your PC 2. The system will pop out the application for install 3. Select Install Application...
  • Page 9 Getting Started Please follow the steps to complete the setup.

  • Page 10: Bluetooth Gps Receiver For Navigation

    Getting Started Bluetooth GPS Receiver for Navigation 1. Slide up the switch to power on the device 2. Slide the function switch to the middle 3. Check GPS status GPS indicator is blinking (When Gtrackr 3D fix) 4. Check Bluetooth status Bluetooth indicator is blinking (When Gtrackr link with mobile phone) Slide to the Middle...
  • Page 11 Getting Started Connect with mobile phone 1. When Bluetooth of Smart Phone is on, use Smart Phone to search Gtrackr 2. When you press accept the device, you need to input the pin number. Pin code : 8888 Bluetooth...
  • Page 12 Getting Started Connect with Smartphone Check GPS and Bluetooth status: 1. The GPS & Bluetooth indicator is blinking 2. Gtrackr sends GPS Message for Smart Phone (with Map) to Navigation. Bluetooth...

  • Page 13: Security Tracker

    Getting Started Security Tracker STEP 1 STEP 2 Open the power and slide the Connect with PC by using USB cable function switch to the middle.
  • Page 14 Getting Started 1. Please go to Device Manager to check the COM number of CP210x USB TO UART Bridge Controller 2. Go to Start All Programs Aptos datalog to open the application...
  • Page 15 Getting Started 1. Select the same COM number privious step. 2. Before press Connect button, please is 9600 make sure the Baudrate...

  • Page 16: Phone Number Setup

    Getting Started Phone Number Setup Choose and press the “Set phone numbers” button to setup two cell phone number and then press the “Accept” button. Note: These two phone numbers are for people, parents, who want to track the location of Gtrackr device.

  • Page 17: Time Interval Setup

    Getting Started Time Interval Setup Choose and press the “Configure Time interval” button to setup time interval and then press the “Accept” button. Time Unit: Second...
  • Page 18 Getting Started 1. Slide up the switch to power on the device 2. Slide the function switch to the top 3. Check GPS status GPS indicator is blinking (When Gtrackr 3D fix) Slide to the Top...
  • Page 19 Getting Started Connect Gtrackr with Smart Phone: After previous setting and bluetooth Link with mobile phone/smart phone, mobile phone/smart phone sends message every time interval to Web Server and mobile Bluetooth phones of Parents or Friends as the two phone numbers you enter. Smartphone...
  • Page 20 Getting Started 4. When the child go outside and bring Gtrackr with his mobile phone, parents can login our web service to check his/her route and location.

  • Page 21: Travel Logger

    Getting Started Travel Logger 1. Slide up the switch to power on the device 2. Slide the function switch to the bottom 3. Check GPS status GPS indicator is blinking (When Gtrackr 3D fix) 4. Gtrackr start recording the travel logger itself Slide to the Bottom...
  • Page 22 Getting Started STEP 1 STEP 2 When user finish the trip, open the power Connect with PC by using USB cable and slide the function switch to the middle.
  • Page 23 Getting Started 1. Please go to Device Manager to check the COM number of CP210x USB TO UART Bridge Controller 2. Go to Start All Programs Aptos datalog to open the application...
  • Page 24 Getting Started 1. Select the same COM number as privious step. 2. Before press Connect button, please make sure the Baudrate is 9600...
  • Page 25 Getting Started Device Setup Choose and press the “Log Configure” button to setup log interval mintime is for time setup min distance is for distance setup min speed is for maximum speed limit setup and then select the Data log “Enable” and press the “Setting”...
  • Page 26 Getting Started Download files 1. Click Log Read Batch and select a folder that you want to save the Gtrackr’s logger data. 2. Click Log Decompress and select the file from previous step. 3. The application will convert the file to KML format.
  • Page 27 Getting Started 4. Use the KML file to show the travel path on Google Earth or Google Map...

  • Page 28: Package List

    Package List Gtrackr Stand CD-ROM USB Cable User Manual...

  • Page 29: Safety Precautions

    Safety Precaution Please follow the safety precautions carefully before you use the product. Make sure that you use the product correctly according to the procedures described in the guide. 1. Never place the product close to equipment generating strong electromagnetic fields. * Exposure to strong magnetic fields may cause malfunctions.
  • Page 30 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 31 Registered tradmarks of Aptos Design Lab Inc. 2009 Aptos Design Lab Inc. All rights reserved.
