COMPACT POWDER COAT OVEN
91979
ASSEMBLY & OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web Site at www.harborfreight.com
©
Copyright
2004 by Harbor Freight Tools
®
. All rights reserved. No portion of this manual or
any artwork contained herein may be reproduced in any shape or form without the
express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
Advertisement
Table of Contents
Related Manuals for Chicago Electric 91979
Summary of Contents for Chicago Electric 91979
- Page 1 COMPACT POWDER COAT OVEN 91979 ASSEMBLY & OPERATING INSTRUCTIONS ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web Site at www.harborfreight.com © Copyright 2004 by Harbor Freight Tools ® . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.
-
Page 2: Work Area
Do not use any adapter plugs. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. If the Oven should electrically malfunction or break down, grounding provides a low resistance SKU 91979 For technical questions, please call 1-800-444-3353. Page... -
Page 3: Personal Safety
Use safety equipment. Always wear eye protection. Dust mask, nonskid safety shoes, hard hat, or hearing protection must be used for appropriate conditions. SKU 91979 For technical questions, please call 1-800-444-3353. Page... - Page 4 When servicing the Oven, use only identical replacement parts. Follow instructions in the “Inspection, Maintenance, And Cleaning” section of this manual. Use of unauthorized parts or failure to follow maintenance instructions may create a risk of electric shock or injury. SKU 91979 For technical questions, please call 1-800-444-3353. Page...
-
Page 5: Grounding Warning
Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code. (See Figure B.) Double insulated tools may be used in either of the 120 volt outlets shown in the following illustration. (See Figure B.) SKU 91979 For technical questions, please call 1-800-444-3353. Page... -
Page 6: Extension Cords
Protect your extension cords from sharp objects, excessive heat, and damp or wet areas. FIGURE C SKU 91979 For technical questions, please call 1-800-444-3353. Page... -
Page 7: Specific Safety Rules
Make certain that the table or stand is flat, level, sturdy and capable of supporting the weight of the Oven and objects being heated. Wear heavy work gloves when touching the Oven or hot materials and objects. SKU 91979 For technical questions, please call 1-800-444-3353. Page... - Page 8 Turn the Thermostat (1) to the desired temperature setting as recommended by the manufacturer of the powder coating material-see Figure 2-next page. The temperature can be set at a temperature between 0 and 480 degrees. SKU 91979 For technical questions, please call 1-800-444-3353. Page...
- Page 9 Depending on the temperature set on the Thermostat (1), it may take up to one hour for the Oven to reach and stabilize at the desired temperature. Once the Oven reaches the desired temperature the Heater ON Indicator Light (3) will go off. SKU 91979 For technical questions, please call 1-800-444-3353. Page...
- Page 10 Oven right side up. Replace the perforated tray at the bottom of the Oven and thread in all four screws. To test the Oven, see the Inspection, Maintenance and Cleaning section of this manual. SKU 91979 For technical questions, please call 1-800-444-3353. Page...
- Page 11 Thermostat and the thermometer that was placed inside the Oven. If the two thermometer readings are not the same, the Thermostat should be adjusted. Only a qualified service technician should perform adjustments or replace the Thermostat. SKU 91979 For technical questions, please call 1-800-444-3353. Page...
- Page 12 Wipe with a damp cloth, using a mild detergent or mild solvent. Do not use cleaners that are combustible or corrosive. Schematic Parts List See the next page for Parts list and description. SKU 91979 For technical questions, please call 1-800-444-3353. Page...
-
Page 13: Please Read The Following Carefully
AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 91979 For technical questions, please call 1-800-444-3353. Page...
