- Page 1 Model 3810A Addressable Thermistor String Instruction Manual ©2019, GEOKON. All rights reserved. Document Revision: E | Release date: 3/18/19...
- Page 3 WARRANTY STATEMENT warrants its products to be free of defects in materials and workmanship, GEOKON under normal use and service for a period of 13 months from date of purchase. If the unit should malfunction, it must be returned to the factory for evaluation, freight prepaid.
-
Page 5: Table Of Contents
3. MODBUS RTU PROTOCOL ......................3.1 INTRODUCTION TO MODBUS ....................3.2 MODBUS RTU OVERVIEW ......................3.3 MODBUS TABLES ..........................3.4 READING 3810A SENSORS ....................... 4. MODBUS & CAMPBELL SCIENTIFIC DATALOGGERS ........4.1 DESCRIPTION ............................4.2 WIRING ................................. 4.3 SAMPLE CR6 PROGRAM ...................... - Page 6 FIGURES FIGURE 1: MODEL 3810A ADDRESSABLE THERMISTOR STRING ........1 FIGURE 2: MODEL 3810A ADDRESSABLE THERMISTOR ..........1 FIGURE 3: MODEL 3810A-3 END TERMINATOR ............2 FIGURE 4: MODEL 8020-38 ADDRESSABLE BUS CONVERTER ........2 FIGURE 5: PC TERMINAL PROGRAM SCREEN CAPTURE ..........4...
- Page 7 TABLE 4: EXAMPLE QUERY - FLOATING POINT RESISTANCE READING ..... 4 TABLE 5: EXAMPLE RESPONSE - FLOATING POINT RESISTANCE READING ....4 TABLE 6: DATALOGGERS WITH RS-485 CONVERSION ..........5 TABLE 7: DATALOGGERS WITHOUT RS-485 CONVERSION........... 5 TABLE 8: 3810A THERMISTOR STRING TO RS-485 TO TTL CONVERTER WIRING..5...
-
Page 9: Introduction
The beads are small in size and extremely robust, with a high degree of stability over a long life span. The accuracy and interchangeability of the thermistor bead used on the 3810A is ±0.07 °C, within the temperature range of 0 °C to 50 °C. -
Page 10: Installation
The maximum pulling force that can safely be applied to the string is 20 lb. FIGURE 3: Model 3810A-3 End Terminator Table 1 shows the function of each of the conductors of the instrument cable. -
Page 11: Modbus Rtu Protocol
The Modbus standard does not specify a physical layer (connection type), but it will work with any interface that can communicate asynchronously with multiple devices (e.g., RS-485, RS-422, optical, radio, etc.). Model 3810A strings use RS-485 as the electrical interface because of its prevalence, simplicity, and success as a robust, industrial physical layer. -
Page 12: Figure 5: Pc Terminal Program Screen Capture
Because of how this information is stored in memory, the two parts are received in reverse order; the complete floating-point number in HEX is 0x4628C87C (10,802.12 Ohms). 4 | MODBUS RTU PROTOCOL | GEOKON... -
Page 13: Modbus & Campbell Scientific Dataloggers
'Calculated Celsius for 5 sensors in string Public Celsius(5) 'Counter to increment through temperature sensors Public Count 'Define Data Tables DataTable (Test, 1,-1) Sample (5,Celsius(),IEEE4) 'Sample Celsius for 5 sensors in string EndTable MODEL 3810A ADDRESSABLE THERMISTOR STRING | MODBUS & CAMPBELL SCIENTIFIC DATALOGGERS | 5... -
Page 14: Sample Cr1000 Program With Required Model 8020-38
4.4 SAMPLE CR1000 PROGRAM WITH REQUIRED MODEL 8020-38 ADDRESSABLE BUS CONVERTER The following sample program reads one 3810A string with five addressable thermistor sensors. The string in this example is connected to a RS-485 to TTL converter and communicates with the CR1000 through the control ports C1 and... -
Page 15: Temperature Calculation
5.3 RAW ADC (ANALOG TO DIGITAL CONVERTER) READINGS Resistance can be found by: R = ADC reading (from register address 0x0100) And temperature is: Using an example ADC reading from address 0x0100 of 0x7984 (31,108): MODEL 3810A ADDRESSABLE THERMISTOR STRING | TEMPERATURE CALCULATION | 7... -
Page 16: Software
The three types of strings currently supported are the Addressable Thermistor (3810A) String, the Addressable VW (Vibrating Wire) (8020-30) Sensor String, and the Addressable MEMS (6150E and 6151E) String. -
Page 17: Appendix A. Specifications
±0.35 °C @ -20 to -10 °C ±0.15 °C @ -10 to 0 °C ±0.07 °C @ 0 to 50 °C ±0.12 °C @ 50 to 65 °C ±0.16 °C @ 65 to 80 °C MODEL 3810A ADDRESSABLE THERMISTOR STRING | SPECIFICATIONS | 9... - Page 20 GEOKON Phone: +1 (603) 448-1562 GEOKON 48 Spencer Street Email: info@geokon.com is an ISO 9001:2015 Lebanon, New Hampshire Website: www.geokon.com registered company 03766, USA...
