Page 1 User Manual Wireless Touch Control Unit...
Page 2 Thank you for purchasing the RF TOUCH wireless control device RF Touch allows you to: • Control numerous devices via the touch screen • Control and dim lighting • Switching of electrical loads and equipment • Blinds / shutters / curtains etc. •...
Page 3: Table Of Contents
Contents Home Screen ..............4 Normal & Holiday Modes ........... 5 Main Menu ................6 Programmed Devices ............7 Switching Control ............... 8 Dimming Control ..............9 Blind / Shutter Control ............10 Detectors ................11 Quick Control ..............12 Setting Weekly/Daily Program ..........
Page 4: Home Screen
Home Screen When you come to use your RF Touch for the first time you will find this screen, which is referred to as the Home Screen. It displays the time, date, favourite commands and gives access to the control menus. The date and time are set up within the settings menu explained in the installation manual.
Page 5: Normal & Holiday Modes
Normal & Holiday Modes Also available on the Home Screen, if enabled within the settings menu is the facility to add two timings elements for switching, dimming and blind/shutter devices. One for 7 day normal mode and one for holiday mode. 7 Day Normal Mode Timings can be setup for the required devices for when the property is occupied.
Page 6: Main Menu
Main Menu This menu is where you can access and control the various wireless devices installed. The menu is divided up by the functionality of the devices as listed below. Temperature Regulation - (Manual available via training course) Switching - (This will bring you to the switching menu where you can see and control the status of switching devices and add timing elements) Page 8 Dimming...
Page 7: Programmed Devices
Programmed Devices After selecting the function of the device to be controlled from the Main Menu, you are then offered a list of named devices programmed during the installation. Select the device and then depending on its functionality will depend on the control options available. The following pages will help explain these options.
Page 8: Switching Control
Switching Control This menu will display and give control of the on/off status of the selected switching device. The 7 day and holiday mode time elements can be set for each dimming device for when the property is occupied or unoccupied.
Page 9: Dimming Control
Dimming Control This menu will display and give control of the on/off and dimming status of the selected dimming device. The 7 day and holiday mode time elements can be set for each dimming device for when the property is occupied or unoccupied.
Page 10: Blind / Shutter Control
Blind / Shutter Control Gives the facility to manually control or via the weekly programming facilities to automatically control shutters/blinds. A short press on UP or DOWN will manoeuvre the shutter/blind in small increments, whilst a 3 second press will run the set time to fully open or fully close.
Page 11: Detectors
Detectors This menu will display the contact status for each detector programmed. The screen is for observation only and offers no control facility. Press to return to the home screen or to step back one screen to the main menu. Status (This will indicate green for OPEN contact &...
Page 12: Quick Control
Quick Control With the ‘quick control’ (scene) settings set up via the installation manual with the various receivers assigned. Each ‘quick control’ can then be instigated by pressing the button ‘Activate’. The ‘Deactivate’ button will produce the opposite effect, e.g. If activate turns a light on, deactivate will turn it off etc. Press to return to the home screen or to step back one screen to select a different device.
Page 13: Setting Weekly/Daily Program
Setting Weekly/Daily Program Two sets of times can be programmed, the 7 day normal mode program can be set up for when the property is occupied and the holiday mode program can be set up for when the property is unoccupied. Each day can be allocated up to 5 timed programs (5 x ON, 5 x OFF) which can be used for switching, dimming and shutters/blinds.
Page 14 Setting Weekly/Daily Program Up to 5 timed programs can be set for each day for shutters/blinds in both 7 day normal mode and holiday mode. Shown below is an example of how to set up the weekly program. Make sure that your timings have been set up correctly to open and close your blinds as desired Setting time Accessing different Daily Overview...
Page 15: Notes
Notes...
