Summary of Contents for Owasys 22C

  • Page 1 Advanced Wireless Devices...
  • Page 2 Owasys Advanced Wireless Devices SL (hereafter called as Owasys), publishes this manual without warranty of its content. Owasys reserves the right to make changes at any time and without prior notice to improve and change this manual as necessitated by typographical errors, inaccurate information as printed, or improvements to the product.
  • Page 3 owasys22C User’s guide Advanced Wireless Devices...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS 1 General Information ....6 4 The Telephone ....25 1.1 User Warnings .
  • Page 5 6.6.1 My Numbers ....41 8.2.2 Changing the Hour Format . .50 6.6.2 Emergency Number ..42 8.2.3 Changing the Date ..50 6.6.3 Service Number .
  • Page 6 11 Extras ......58 11.1 Turning off the telephone ..58 12 Accesories .

  • Page 7: General Information

    1 GENERAL INFORMATION The information contained in this user’s guide is written for the Owasys mobile phone model owasys22C in 2 different versions: GSM 900/1800 and GSM 850/1900. 1.1 User Warnings Export controls This product is subject to export laws and regulations from the U.S. and other countries. Diversion contrary to law is prohibited.
  • Page 8 the use of a phone unless the automobile is equipped with a hands-free device and an external antenna. Consult with the dealer you purchased your car from to see if your mobile phone will interfere with the electronic systems on your car. Do not place any objects or devices over the air bag or in the deployment area.
  • Page 9 To minimize the potential for interference persons with pacemakers • Should always keep the phone more than 6 inches (15 cm.) from their pacemaker when the phone is switched on • Should not carry the phone in a breast pocket •...
  • Page 10 Vehicles with an Air Bag Do not place a portable phone in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a portable phone is placed in the air bag deployment area and the air bag inflates, the phone may be propelled with great force and cause serious injury.
  • Page 11 Only use batteries, chargers, and accessories that are compatible with the model of your phone and are recommended by Owasys. Using inappropriate equipment can generate health risks or can damage the equipment because of incompatible devices. Do not expose your battery to extreme temperatures above 60 ºC. To maximise the battery capa- city, use it at room temperature.
  • Page 12 FCC Statements Modification statement: Any changes or modifications made to this device that are not expressly approved by Owasys SL may void the user´s authority to operate the equipment. Interfence statement: This device complies with Part 15 of the FCC Rules.

  • Page 13: Exposure To Electromagnetic Radio Waves And Sar

    used in accordance with the instructions, may cause harmful interference to radio communi- cations. However, there is no guarantee that interference will not occur in a particular installa- tion. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encourage to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna.
  • Page 14 All Owasys mobile phone models are designed to function inside these levels and include an ample margin of safety in order to guarantee safety to all persons, regardless of their age or health, and to avoid any measurement variations.
  • Page 15 be well below the maximum value. This is because the phone is designed to operate at multi- ple power levels so as to use only the power required to reach the network. In general, the clo- ser you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public in the US, it must be tested and certi- fied to the FCC that it does not exceed the limit established by the government for safe exposu- re.

  • Page 16: Applicable Standards And

    1.3 Applicable Standards and Regulations Declaration of Conformity (European Union) Owasys, the manufacturer of the product owasys22C GSM 900/1800 version described in this manual, certifies that said product complies with all Radio and Telecommunications terminal equipment regulations described in the directive 1999/5/EC (R&TTE), the requirements inclu- ded in the EMC directive 89/336/EEC and the Low Voltage directive 73/23/EEC.

  • Page 17: Practical Advice For The Care And Maintenance Of The Product

    • Do not try to disassemble the product. The phone does not contain components that the con- sumer can replace. Only personnel authorised by Owasys may make repairs. • If the phone is not going to be used for a prolonged period of time, it is good to remove the...

  • Page 18: Effective Use Of The Product

    1.6 Effective Use of the Product Use only original accessories recommended by Owasys. Using other accessories could adver- sely affect your telephone, damaging it, causing fires, electrical discharges, or personal bodily harm. The warranty does not cover problems to your telephone caused by using accessories not recommended or provided by Owasys.

  • Page 19: Getting Started

    2 GETTING STARTED 2.1 Insertion and Removal of the SIM Card Before using your phone, it is necessary to insert the SIM card and charge the battery. The SIM card contains all the main data necessary to connect (your phone number and phone book), and uses an associated security code and PIN To insert the card: 1.

  • Page 20: Insertion Of The Sim Card

    3. Slip the card into place. Be sure that it is placed below the lateral supports situated on either side of the compartment. To remove the card: Insertion of the SIM Card 1. Turn the phone off. 2. Remove the back covering by simultaneously pressing down on the ribbed indentation and pushing the covering towards the bottom of the phone.

  • Page 21: Installing The Battery

    2.2 Installing the Battery To install the battery, once the cover is removed: 1. First place the upper part in, making sure that the catches situated on the upper part of the battery fit into the corresponding slots in the telephone. 2.

  • Page 22: Removing The Battery

    To remove the battery: 4. The phone should be turned off. This is done by pressing and holding the On/Off button 5. Once off, press on the clip at the base of the battery to free it and then lift up on it to remove. 6.

  • Page 23: Charging The Battery

    Before using the phone for the first time, you should charge the battery for at least 3 hours. Use only compatible chargers and accesories (those recommended by Owasys) for your phone model. Owasys disclaims any responsibility for damage caused by the use of accesories not compatible with your phone.

  • Page 24: Turning The Phone On And Off

    3 TURNING THE PHONE ON AND OFF 3.1 Turning the Phone On To turn your mobile phone on, press and hold the Power key on the right bottom of the keypad The phone will vibrate and emit a start up melody to let you know it has been turned on correctly.

  • Page 25: Turning The Phone Off

    The registration of the phone in the network will take a few seconds and during this time the start-up melody will sound. Once a network has been located, your phone will be in STANDBY mode, ready to send and receive calls. During this time the telephone will work in private mode (speaker low, hands-free deactivated).

  • Page 26: The Telephone

    4 THE TELEPHONE 4.1 Physical Description of the Telephone The front part of your owasys22C telephone includes: 1. Two grooves situated on the upper part of the phone, which covers the speaker. Try not to obstruct these grooves when the telephone is being used in hands-free mode, as it can affect the quality of the sound.

  • Page 27: Front View Of The Owasys22C

    Below is a general diagram of the front of the telephone, detailing the functions of each key as was explained earlier. Speaker Volume Handsfree Phone book Status key Call/Accept Hang up/Cancel/Delete Navegation keys Voicemail Silent mode Lighting Indicator Front view of the owasys22C Turn ON/OFF Keypad Lock/Unlock...
  • Page 28 Phone book Allows direct access to the list of stored names in the phone list, listed in alphabetical order. Hands-Free This is used to go from handset mode (with the speaker turned down, or before connecting the portable hands-free device) to hands-free mode in which the speaker has the volume turned up, and vice-versa.
  • Page 29 • Operator which provides the service. In the case that there is no coverage, this will be indica- ted with “No Network”. If it is only possible to make emergency calls, the phone will indicate this with “Only emergency calls”. •...
  • Page 30 Hang Up / Cancel / Delete key Press this for a normal length of time to hang up or reject a call and to return to a previous menu level. While navigating the menu, pressing & holding this key for a prolonged period of time will take you back to the standby mode.

  • Page 31: The Owasys22C

    For more detailed information regarding the numerical shortcuts associated with each subme- nu, consult the MENU STRUCTURE section of this chapter. Call your voicemail (press and hold for 2 seconds). Activating and de-activating the silent mode (press and hold for 2 seconds). Activating the silent mode will silence the tones for all incoming calls, and the phone will automatically revert to a vibrating mode.

  • Page 32: Side Connectors On The Owasys22C

    On the left side of the phone (oriented with the front faced up) there are two volume keys to adjust the volume of the speaker to its maximum and minimum established levels. When pres- sing any of these keys you will hear the menu option you are currently in with the volume set at that moment.

  • Page 33: Menu Structure

    4.2 Menu Structure What follows is a general description of the menu structure of your owasys22C mobile phone. Pressing the navigation keys will take you directly to the Phone book, which is the first menu option available. From here you can use the menu keys or the shortcut keys which are detailed in the following table.
  • Page 34 The complete information about available menu options is in the following table: PHONE BOOK (1) MESSAGES (2) CONFIGURATION (3) (1) Find and Call (1) Send new message (1) Sounds and alarms (2) New contact (2) Unread messages (1) Ring volume (3) Edit contact (3) Read messages (2) Vibrating alert...
  • Page 35 CALL INFORMATION (4) MANAGE CALLS (5) EXTRAS (6) (1) My number (1) Missed calls (1) Switch off (2) Accepted calls (1) Show number (2) Hide number (3) Dialled calls (4) Clear call list (2) Call divert (1) Divert always (2) On busy (3) No answer (4) No reachable (5) Cancel all diverts...

  • Page 36: Making And Receiving Calls

    5 MAKING AND RECEIVING CALLS 5.1 How to Make a Call Once the phone is turned on and in standby mode, dial the number you wish to call. Every time you enter a digit, the telephone will say the number entered. If you misdial, press the Cancel button to erase the last digit.

  • Page 37: How To Answer An Incoming Call

    5.3 How to Answer an Incoming Call When you receive a call while your phone is in wait mode, press the Accept key to answer it. 5.4 Rejecting a Call If you want to know who is calling you, press the Status key while the ringing tone is playing.You will be informed of the number or contact name, if stored in the phone book.

  • Page 38: Phone Book

    6 PHONE BOOK Use this option to create a personal phone book by recording phone numbers and the names associated with them. Your contacts information can be stored in the phone’s internal memory and/or on the SIM card. By default, your phone stores your contact information within the internal memory. The phone book in your owasys22C mobile phone allows you to store for a single contact seve- ral phone numbers, as well as their postal and e-mail addresses.

  • Page 39: Alphabetic Search

    6.1.1 Alphabetic Search If you access the phone book through the navigation menu, the search will be performed alpha- betically, starting with the first contact that matches with the characters entered. Your phone will ask you to “Write name”. Use the alphanumeric keypad to enter in a search string and press Accept to begin the search.

  • Page 40: Edit Contact

    The phone will ask you to introduce the information you wish to edit in every case. For example, if you wish to edit the contact name , select Name and press Accept . You will hear a mes- sage asking you to “Write name”. Use the alphanumeric keypad to edit the name and press Accept Repeat this operation until you have completed all the contact information.

  • Page 41: Delete Contact

    level you can also Store the changes. Press the Accept key to select which field you would like to edit. The phone will ask you to key in the information for the field in question. Use the alphanumeric keypad to edit the new information for the existing contact and press Accept 6.4 Delete Contact •...

  • Page 42: Phone Book Status

    6.5 Phone Book Status Select Phone book status (5) in the Phone book (1) menu to check the status of the phone’s 6.6 Special Numbers internal memory. A message will tell you the number of positions used and the number still available (250). Through the Special Numbers (6) option in the Phone book (1) , you will be able to store and check certain numbers with a special character.

  • Page 43: Emergency Number

    6.6.2 Emergency Number Your number allows you to make emergency calls even if your SIM card is unavailable, as long as you have GSM coverage. This option let you save an emergency number. Enter in the appropriate emergency number and press Accept .

  • Page 44: Messages

    7 MESSAGES 7.1 Send New Message The SMS service allows you to send and receive text messages up to 160 characters in length. To write a new message, select Messages (2)/Send New Message (1) and press Accept .Use the Navigation keys to get into the following options: •...

  • Page 45: Unread Messages

    7.2 Unread Messages To read your unread messages, go to the Messages (2)/Unread Messages (2) menu and press Accept . The set of messages will be listed off, and if the message is from a contact stored in your phone book, the contact’s name will be read along with the time and date the message was received.

  • Page 46: Read Messages

    7.3 Read Messages When you receive a text message, your phone will emit a tone and a short vibration indicating that a new message has been received. Once read, messages are stored in the list of "Read Messages". To read the received message, go to the Messages (2)/Read Messages (3) menu. If the messa- ge is from a contact stored in your phone book, this contact’s name will be read, along with the time and date the SMS was received.

  • Page 47: Unsent Messages

    7.5 Unsent Messages Once you have read the messages, push Accept to achieve one of the following: Delete (1), Forward (2), Answer (3), Call (4), Delete all messages (5), Add number to phone book (6). Consult the section 7.2 UNREAD MESSAGES to obtain information on erasing and forwarding messages.

  • Page 48: Message Options

    • Read mailbox (1). This option makes a call to the number of the voicemail previously defined. • Set mailbox phone number (2). Choose this option to store the number of your voice mailbox and press Accept . Enter the number and press Accept to store it.

  • Page 49: Configuration

    8 CONFIGURATION 8.1 Sounds and Alarms Your phone allows you to make some adjustments. You can do this by accessing the Configuration (3) menu. Through this option you can choose between different tones and melodies to identify your incoming calls, adjusting the volume to the desired level.

  • Page 50: Ringing Tones

    8.1.3 Ringing Tones Select one of the melodies available on your phone for your incoming calls. Once in the Sounds and alarms (1) menu, choose the option Ringing tones (3). Your phone will at first play the default melody at the call tone fixed volume. Listen to the various tones and melodies available using the navigate by menu keys and press Accept to choose the desired option.

  • Page 51: Changing The Hour Format

    Enter the hours and press Accept . Then enter the minutes and minutes. Press Accept to validate or Cancel to leave the menu. 8.2.2 Changing the Hour Format Time can be showed in a 12 hour format (AM/PM) or in a 24 hour format. To change the format of the time, select Time format (2) from the menu Time and Date (2) .

  • Page 52: Lock The Telephone

    • Change PIN Code (2): Through this option the PIN code can be modified. The phone will ask you to enter the old PIN 4 digit code. Enter the new one and press Accept . Re-enter the PIN code and press Accept .

  • Page 53: Selecting The Speed

    8.4.1 Selecting the Speed of the Spoken Text To change the speed at wich you hear your telephone’s spoken text, from the main menu go to Configuration (3) and select Speech configuration (4) /Speed (1) . With the navigation keys cho- ose the desired speech and press Accept From this moment you will hear the text-to-speech at the speed that you just selected.

  • Page 54: Call Information

    9 CALL INFORMATION 9.1 Call Information Your phone will provide the following information about the numbers and the times of the following calls: 9.2 Call Log Memory • Last calls received • Last calls received that were missed (including rejected calls) •...

  • Page 55: Manage Calls

    10 MANAGE CALLS 10.1 My Number 10.2 Call Divert This option allows you to configure your phone to show or hide your phone number from the person you are calling. Go to Manage Calls (5)/My number (1) and press the Accept key select either one of the following options: Show number (1) or Hide number (2) .

  • Page 56: Call Barring

    • Deactivate the diversion of the group of selected numbers. Press the Accept key to can- cel forwarding of the select group of numbers. You will hear a message indicating that call rejection has been deactivated. • Get status: Provides information about active and inactive call forwarding. Press Accept and you will be given information regarding the status of all your rejected numbers as well as if call forwarding has been activated or not.
  • Page 57 Use the navigate by menu keys to select one of the available options and press the Accept to select the desired option. For each of the call restriction options described, you can Activate (1) , Deactivate (2) , or Get sta- tus (3) of the associated restrictions.

  • Page 58: Call Waiting

    10.4 Call Waiting This service allows you to keep one call on the line while you accept and/or make a second call. Select Call waiting (3) from the Call information (4)/Manage calls (5) menu and press Accept . You can activate, deactivate it, or check the call waiting status. With the menu keys you can access the following options: •...

  • Page 59: Extras

    11 EXTRAS 11.1 Turning off the telephone To switch off, go to Extras (5)/Switch off (1) . Press Accept to switch the telephone off. You will be asked for confirmation in turning off the telephone, and will hear a farewell message before the phone is completely turned off.

  • Page 60: Accesories

    12 ACCESSORIES Your telephone owasys22C has the following accessories available: • Battery charger • Spare batteries • Portable handsfree device • Protective case • Data cable Ask your service provider about the availability of these accessories.

  • Page 61: Fda Statement

    13 FDA STATEMET The U.S. Food and Drug Administration's Center for Devices and Radiological Health Consumer Update on Mobile Phones FDA has been receiving inquiries about the safety of mobile phones, including cellular phones and PCS phones. The following summarizes what is known—and what remains unknown— about whether these products can pose a hazard to health, and what can be done to minimize any potential risk.
  • Page 62 antenna —the primary source of the RF— and the person's head. The exposure to RF from mobile phones in which the antenna is located at greater distances from the user (on the out- side of a car, for example) is drastically lower than that from hand-held phones, because a per- son's RF exposure decreases rapidly with distance from the source.
  • Page 63 of the nerve sheath). No statistically significant association was found between mobile phone use and acoustic neuroma. There was also no association between mobile phone use and gliomas when all types of types of gliomas were considered together. It should be noted that the average length of mobile phone exposure in this study was less than three years.
  • Page 64 ding research recommendations and scientific oversight of new CTIA funded research based on such recommendations. Two other studies of interest have been reported recently in the literature: 1 Two groups of 18 people were exposed to simulated mobile phone signals under laboratory conditions while they performed cognitive function tests.
  • Page 65 In summary, we do not have enough information at this point to assure the public that there are, or are not, any low incident health problems associated with use of mobile phones. FDA conti- nues to work with all parties, including other federal agencies and industry, to assure that rese- arch is undertaken to provide the necessary answers to the outstanding questions about the safety of mobile phones.
  • Page 66 What is FDA's role concerning the safety of mobile phones? Under the law, FDA does not review the safety of radiation emitting consumer products such as mobile phones before marketing, as it does with new drugs or medical devices. However, the agency has authority to take action if mobile phones are shown to emit radiation at a level that is hazardous to the user.
  • Page 67 In the absence of conclusive information about any possible risk, what can concerned indivi- duals do? If there is a risk from these products—and at this point we do not know that there is—it is pro- bably very small. But if people are concerned about avoiding even potential risks, there are sim- ple steps they can take to do so.
  • Page 68 Where can I find additional information? For additional information, see the following Web sites: Federal Communications Commission (FCC) RF Safety Program (select “Information on Human Exposure to RF Fields from Cellular and PCS Radio Transmitters”): http://www.fcc.gov/oet/rfsafety World Health Organization (WHO) International Commission on Non-Ionizing Radiation Protection (select Qs &...

  • Page 69: Manufacturer´s Limited Warranty

    If that is unavailable, the sales receipt will suffice. Owasys reserves the rights to oppose or refuse this warranty service if the required information is not on the certificate or has been modified since the time of the items purchase.
  • Page 70 Owasys and designed specifically for this product will void the warranty. This warranty does not apply in case of accident, theft, acts of vandalism or natural disasters. Owasys will not be held responsible for connection problems attributed to a lack of coverage, availability,and services from the network service provider.
  • Page 71 WARRANTY CERTIFICATE TELEPHONE INFORMATION Model: Serial Number of the Telephone: Serial Number of the Battery: IMEI Number: SALES INFORMATION (Please read the label below the battery to find the following information) Name of the Store: Address of the Store: Date of Purchase: Seller’s Stamp and Signature...
  • Page 72 Address: To thank you for purchasing from us, and sending this to us, you will be enrolled in the “Owasys Club”. We will keep you informed of the latest news and sales, as well as all the new features and releases on the...
