- Page 1 A I L O R E D P E C T R U M Commercial Grow Luminaire SQRT670CX1 NSTRUCTION ANUAL...
- Page 2 This state-of-the art fixture is supported by robust engineering, ISO 9001 manufacturing and backed by Sunmaster’s long- standing commitment to quality and service. For over 20 years Sunmaster has provided best-in-class lighting products throughout North America, Europe and Australia. Contact us at any time at sunmastergrowlamps.com/contact.
- Page 3 SAFETY RECOMMENDATIONS / WARNINGS Please read and understand all installation and safety guidelines before attempting to install or operate this fixture. • Always adhere to local and national building and • Do not clean the under side of the light bars (side with electrical codes LEDs) with heavy detergents, rags or sponge.
- Page 4 ASSEMBLY AND INSTALLATION 1. Place spine upside down (grey connectors facing up) on a clean, flat surface 2. Attach (8) light bars by sliding each set of (2) grey connectors on the light bar into the (2) grey slots on the spine. Ensure that the light bars are faced in the proper direction whereby the electrical connectors on the light bar face the electrical connectors on the spine.
- Page 5 ELECTRICAL Power cord Control cable • Fixture has a single power (blue) and single dimming (yellow) cord at each end. Electrical or control connection may be made at either end. Connectors on the opposite end of the fixture may be used to connect additional fixtures. •...
- Page 6 OPERATIONAL GUIDELINES • Mount light bars approximately 6” above the top of the plant canopy. This assures that the maximum amount of light energy reaches and penetrates the plant canopy. Light diminishes significantly as it is pulled away from the plant canopy. •...
- Page 7 WARRANTY This Sunmaster product is warranted for the period of 3 years, The warranty terms contained herein shall be the sole and as specified, from the date of purchase against defects in exclusive remedy of the purchaser of Sunmaster products and material and workmanship.
- Page 8 Robust design Connectivity Full Spectrum 0-10V Dimming Easy installation Communication No fan FOR TECHNICAL SUPPORT 855-562-1008 Email: info@SUNMASTERGrowLamps.com OLLOW IKE US ON ACEBOOK WITTER NSTAGRAM AND SUNMASTERGrowLamps.com © 2018 Venture Lighting International, Inc. SUNMASTER is a trademark of Venture Lighting International.
