RESCUE PHONE
ease of operation during stressful negotiations.
Easy-to-follow operating instructions are also printed directly on the control panel for quick reference.
This instruction manual provides a more detailed explanation of functions and theory of operation.
POWER: Master on/off power control for the Rescue Phone.
PHONE LINE: Hook switch for outside calls. When the light is
off the phone line is hung up and you may receive incoming
calls. Push PHONE LINE on to answer a call or get dial
tone to place an outside call.
HOLD: Places an outside phone call on hold. May also be
used to separate parties on a conference call.
OFF HOOK/CALL: When lit this shows the throw phone is off
the hook. When the call button is pushed the throw phone
will begin the automatic ringing cycle, (2 SECONDS RING
- 4 SECONDS IDLE) and will continue until the perpetrator
answers or the CANCEL button is pushed.
®
CRT MODEL
The Rescue Phone has been designed for
R
P
ESCUE
HONE
INSTRUCTION MANUAL
C
ONTROL
CONFERENCE: Used to patch the perpetrator from the throw
phone to an outside phone line. The perpetrator must
negotiate this privilege from you. He must give you the
phone number, and you must dial it for him.
RINGING/CANCEL: When lit, it indicates the console is ringing
the throw phone. It will stay lit until the throw phone is
answered or the cancel button is pushed. When CANCEL
is pushed the automatic ringing is stopped.
MONITOR/ON: This button controls the on-hook monitoring
ability of the throw phone. When the throw phone is
provided into the barricaded area and the monitor light is
on, monitoring of room noises will occur. Leave this button
off in all other applications. A special circuit mutes the
negotiator's earpiece when the call button is pushed.
P
ANEL
Advertisement
Table of Contents
Related Manuals for Rescue Phone CRT
Summary of Contents for Rescue Phone CRT
- Page 1 HONE ONTROL ANEL POWER: Master on/off power control for the Rescue Phone. CONFERENCE: Used to patch the perpetrator from the throw phone to an outside phone line. The perpetrator must negotiate this privilege from you. He must give you the PHONE LINE: Hook switch for outside calls.
- Page 2 TO CALL THE PERPETRATOR ON THE THROW PHONE Once the THROW PHONE has been given to the perpetrator or the phone line into the barricaded area has been cut and the wires attached to the RESCUE PHONE, you may call the perpetrator by pushing the CALL button one time.
- Page 3 (digital) phones are used, (Merlin, Rolm, Nortel, etc.) use a fax outlet (analog) for dial tone. To attach the RESCUE PHONE to an existing phone line which has been cut, attach the target phone line pair to the red and green terminals marked L1 and L2 on the control panel.
- Page 4 SCENARIO 3 The Rescue Phone can be used with the throw phone and the 1000 foot wire spool to supply a telephone to an area that does not normally have a telephone or where the existing phone has been damaged. The throw phone would also be useful in cases where the barricaded area is a motor vehicle.
- Page 5 CIRCUI OFF HOOK LINE ON BREAKER BREAKER 2 CONFERENCE ON PHONE LINE ON 4 DIAL PHONE NUMBER Rescue Phone OFF HOOK TONE ALERT (CAUTION: 105 db) Push Tone Alert And Cancel At The Same Time OFF HOOK RINGING MONITOR RISIS...
- Page 6 ESCUE HONE CCESSORY ASSETTE APE HITE HITE ECORDER OMMAND PEAKERS ASSETTE APE ASSETTE NFRARE EADPHONES IRED EADPHONES NFRARED RANSMITTER (Infrared Transmitter) WO NFRARED EADPHONES IRED EADPHONES...
