3. Operating principle

OTm Digi
GR
5Vdc
V
0 +
T001081-A
T001081-D
GR Green status LED
V Connection button
Green status LED
The status LED provides information
about the power supply and the
RF connection. Fault messages
about the power supply and the RF
connection are also provided via the
status LED; see Chapter 5.
Connection button
This button is used to make a
connection between the base station
and the controller.
