Summary of Contents for G.M. International D1020S
- Page 1 D1020S - D1020D INSTRUCTION & SAFETY MANUAL SIL 2 Powered Isolating Driver Smart-Hart compatible DIN-Rail Models D1020S, D1020D D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible ISM0012-14...
-
Page 2: Technical Data
Characteristics General Description: The single and dual channel DIN Rail Isolating Driver, D1020S and D1020D, isolates and transfers a 4-20, 0-20 mA signal from a controller located in Safe Area to a load of up to 750 Ω in Hazardous Area. It has a high output capacity of 15 V at 20 mA combined with a low drop across its input terminals. The circuit allows bi-directional communication signals, for Smart I/P. -
Page 3: Ordering Information
- Input Ch 2 for Current Source mode - Output Ch 1 for I/P Converter + Ch2 Power Supply 24 Vdc Not used - Ch2 Power Supply 24 Vdc G.M. International ISM0012-14 D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible... - Page 4 For Division 1 and Zone 0 installations, the configuration of Intrinsically Safe Equipment must be FM approved under Entity Concept (or third party approved); for Division 2 installations, the configuration of Intrinsically Safe Equipment must be FM approved under non-incendive field wiring or Entity Concept (or third party approved). D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible G.M. International ISM0012-14...
-
Page 5: Function Diagram
Out 1 In 1 8 - Ch2 Supply 24 Vdc I/P Converter Source I Out 2 In 2 MODEL D1020S Supply 24 Vdc I/P Converter Source I Out 1 In 1 G.M. International ISM0012-14 D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible... - Page 6 The 2 channels of D1020D module could be used to increase the hardware fault tolerance, needed for a higher SIL of a certain Safety Function, as they are they are completely inde- pendent each other, not containing common components. In fact, the analysis results got for D1020S (single channel) are also valid for each channel of D1020D (double channel).
- Page 7 The unit cannot be repaired by the end user and must be returned to the manufacturer or his authorized representative. Any unauthorized modification must be avoided. G.M. International ISM0012-14 D1020 - SIL 2 Powered Isolating Driver Smart-Hart compatible...
-
Page 8: Operation
The wiring cables have to be proportionate in base to the current and the length of the cable. On the section “Function Diagram” and enclosure side a block diagram identifies all connections. Identify the number of channels of the specific card (e.g. D1020S is a single channel model and D1020D is a dual channel model), the function and location of each connection terminal using the wiring diagram on the corresponding section, as an example: Connect 24 Vdc power supply positive at terminal “3”... - Page 9 DC supply 30 V range at terminals 1 (+) and 2 (-), the multimeter (DMM) for the reading in DC supply 20 mA range at terminals 14 (+) and 15 (-). Execute the next test to verify D1020S unit channel or execute it twice to verified both D1020D unit channels. ...
