- Page 1 3007 5005 5007 6007 INSTRUCTIONS Français English Español Nederlands Italien Deutsch Portugeese Dansk...
-
Page 2: Table Of Contents
Thank you for choosing INVERTER ,and for your trust in our brand name. Please read this manual carefully before using the Unit. It is important that you handle and use the Unit according to the instructions, to prolong its life, and to avoid problems and accidents. -
Page 3: Specifications
INVERTER SPECIFICATIONS MODELS 3007 5005 5007 6007 Type Type of burner Fuel Injection fan heater TOZANE rolf (reduced Odour) Liquid Fuel Fuel RECOMMENDED TEST STANDARD C1 PARAFFIN TO BS2869-2 High voltage discharge ignition Ignition Fuel consumption (g/h) Average Fuel consumption... -
Page 4: Special Precautions
1. SPECIAL PRECAUTIONS Special precautions must be taken when you are using your electronic fan heater. Always use fuel recommended for your heater. Never use highly volatile fuel, such as, for example, petrol, due to the danger of causing a fire. Recommended fuels Petrol Avoid locations close to curtains, etc. - Page 5 Turn heater off and be sure the burner is out before going to bed or leaving the room. Turn off Unit to extinguish burner in emergency or in event of improper combustion. Keep calm. Ensure electrical socket is properly wired, and only use it for this Unit.
- Page 6 not touch blower grill while heater is on or immediately after use. (Children must be warned about this and kept under supervision). If the unit is for a child , elderly person, or handicapped person, somebody must supervise their use of the unit Service your heater regularly.
-
Page 7: Selection Of Location
2. SELECTION OF LOCATION Choose the location for your heater carefully, to get optimum performance from the Unit. SAFETY PRECAUTIONS TO BE TAKEN * Keep all obstructions and flammable materials away from the Unit, and observe the minimum distances shown on the following illustration. Keep curtains away from the Unit. -
Page 8: Names Of Parts
NAMES OF SPARTS FRONT Tank cover Removable tank Fuelx gauge (back) Fuel feeder cap Overheat prevention device Handle Front panel Control panel Inspection window Fuel filter Warm air outlet Magnetic pump Base plate Fixed tank BACK Warm air intake Room thermo-sensor Air filter Power cord... -
Page 12: Examples Of Display
5. EXAMPLES OF DISPLAY MUST USE FUEL ENGLISH SYMBOLSAM 5 SEC TIME TIMER TIMER SET (TIMER) TIME SET (HOURS) Temperature Display Left: Set temperature (12-30 deg. C.) Right: Room temperature (0-35 deg. C.) Clock/Time Setting Mode (set present time at 8 : 30 am) Timer Setting Mode (set timer at 6 : 30 am) —... -
Page 13: Before Using The Unit
6. BEFORE USING THE UNIT 1) Setting up the unit Remove the Heater unit from the carton box and remove packing materials. Remove fuel tank from the unit. 2) Fuel to be used Use only uncontaminated Paraffin to BS2869:C1, or ROLF (or TOSAINE) Fuel, as recommended the Distributor. - Page 14 WHAT IS POOR QUALITY OR IMPURE FUEL ? * Fuel which has been exposed to the * Last season‘s fuel. sun or high humidity Fuel which has been mixed with some Fuel stored in a container which has not water or dust or a different type of fuel been properly closed or which lets the other than C1 Paraffin light through...
-
Page 15: Fuel Filling
3) FUEL FILLING Procedure for filling with fuel PLEASE MAKE SURE THAT THE UNIT IS TURNED OFF, AND THERE ARE NO FLAMMABLES WITHIN THE VICINITY OF THE UNIT. 1. Remove fuel tank from the unit and open the cap. Do not drop the fuel tank. Remove cap by truning counterclockwise 2. -
Page 16: Checks Before Use
Note: * If filling fuel in a cold place and the tank is filled to less than half, open fuel feeder cap for a time, until the temperature of the fuel adjusts to room temperature before replacing the tank. * Be careful not to spill fuel on the Full Alarm sensor. If fuel is running short... -
Page 17: Ignition
2) Ignition Press ON/OFF button. ON lamp blinks. After a pause for pre- heating, the unit automatically turns on. ON lamp lights . * The sound of ignition on lighting is quite normal. * The pre-heat time until ignition is about 2 minutes, depending on the room temperature. -
Page 18: Temperature Control
4) Flame Condition When the unit is lit check the condition of the flame through the inspection window. If thecondition of the flame is abnormal, consult your dealer. Normal flame: Blue flame with a slight yellow. Abnormal flame 1: Flame shrinking. Produces noise or smell and eventually extinguishes. -
Page 19: Child Lock (Safety Lock For Children)
What is the ECO operation ? If the temperature gets three degree C higher than the selected temperature, the unit automatically shuts down When the temperature falls to the temperature selected , the unit automatically ignites again to maintain the temperature. Set ECO mode on warm days or in a comparatively warm room. -
Page 20: Count Down
HOW TO OPERATE TIMER? * Press the Timer button when the unit is on * The Timer lamp lights and the digital display changes to clock mode. * The unit automatically switches on at the selected time. * Press On/Off button to cancel Timer mode. * When the room temperature is relatively low, the unit switches on be- tween 5 and 15 minutes earlier than the selected time. - Page 21 DISPLAY DESCRIPTIONS 5 8H The heater just started. 5 7H The heater has been running for about 1 hour. The heater will switch OFF in 1-2 hour’s time. The heater will switch OFF in 1/2-1 hour’s time. O FF BLIKING The heater will switch OFF in 30 minutes.
-
Page 22: Safety Devices
IMPORTANT - Use your heater in a room which is properly ventilated, and free of inflammable vapours. - All rooms in which the heater is used must be adequately ventilated (the ventilator aperture must have a minimum surface area of 50 cm²). - Do not use your heater in too small a room : 3000 watts : min 46 M3 3200 watts : min 49 M3... -
Page 23: After Sales Service
PREVENTION OF INCOMPLETE COMBUSTION A shortage of oxygen, due, for example, to using the Unit for a long time without ventilating the room, or because of a dirty air filter, triggers this system, in order to switch off the burner , to prevent the unit from burning abnormally. Make sure that your room is ventilated at least once or twice per hour, and that the air filter is cleaned. -
Page 24: Problems And Trouble Shooting
10. PROBLEMS AND TROUBLE SHOOTING In exceptional circumstances, the following phenomena may arise. You should check the possible causes before seeing your local dealer. DESCRIPTION CAUSES Smoke and smell come from Heat-resistant paints and dust are burning off. unit when it is switched off. Ventilate the room for a while, until smoke and smell go. -
Page 26: Storing (When Not In Use For A Long Period)
SELF DIAGNOSIS If there is an “E” display, take following measures The unit shuts off at the time of ignition or during operation: Get rid of water or dust in fuel filter and fixed tank, and switch on again. If there is no improvement, refer to your dealer. Trouble with electrical parts: Needs repair. -
Page 27: Regular Maintenance
13. REGULAR MAINTENANCE All cleaning and maintenance must be done after switching off the heater, disconnecting the plug from the socket, and after waiting until the unit has cooled down. CLEANING OF AIR FILTER (MORE THAN ONCE A WEEK) Remove air filter from the unit, and clean it with vacuum cleaner or a brush. -
Page 28: Periodical Check
In all the above instances, clean the fuel filter as follows: 1. Remove the fuel filter from the fixed tank * Be careful not to allow water or dust into the fixed F U E L FILTER tank. 2. Clean the fuel filter with fuel * First get rid of water or dust from the fuel filter F U E L before cleaning. - Page 29 4. NAMES AND FUNCTIONS OF OPERATING BUTTONS INVERTER 3007 FUEL SIGN TEMP. ADJ. BUTTONS CLOCK/TIMER BUTTONS When flashing with alarm sound: Press when changing Set Press when setting Present Will automatically shut off (starts flashing 20- Temperature. Time and timer.
- Page 30 INVERTER 6007 AND 5005 FUEL SIGN CLOCK/TIMER TEMP. ADJ. BUTTONS When blinking and alarm sounds: BUTTONS Press when changing Will automatically shut off (starts blinking 20- Press when setting temperature. 40 minutes before shut off) Present time and timer..down When fast blinking and alarm sounds: .
- Page 31 INVERTER 5007 FUEL SIGN When blinking and alarm sounds: Will automatically shut off (starts blinking 20- TIMER “ON” SWITCH (TIMER 40 minutes before shut off) 5 SEC BUTTON LAMP) When fast blinking and alarm sounds: Press this button to set / cancel...
- Page 32 The following is a trouble-shooting table with problems and their probable causes. Take the necessary measures suggested as soon as possible. See your local distributor if necessary. 11. TROUBLE SHOOTING AND REFERENCE TABLE Phenomena Solutions Causes The plug is not properly in place. Make sure plug fits properly in power outlet.
