D R Burton iPEP Quick Start Instructions

D R Burton
•
INSPIRE FOR L I FE
The complete instructions are packaged with the iPEP®.

Assembly of the iPEP

1
A. The OPEP module comes pre-assembled in the iPEP.
B. Put the iPEP mouth-piece tube into the tube port.
C. To use the handle:
• Swing the handle down.
• P ush the handle up to gently lock into place.

Using the iPEP

2
A. Take the dust cap off the iPEP mouth-piece tube and insert in mouth.
B. T ake a very slow breath in. The cylinder will move up as you breathe in. Your
healthcare practitioner may place the target marker to tell you how big of a breath
you should take. Clinical judgment should be used.
C. T o select the right volume target, see Chart B from complete instructions that are
packaged with the iPEP.
D. A s you breathe in, make sure that the disk stays in the middle of the the green zone.
Hold your breath for 2-3 seconds.
E. Breathe out through the mouth-piece with more force than normal.
F. Keep taking slow breaths in and forceful breaths out — 10 to 20 times.
G. A fter at least 10 breaths in and out, do 2 or 3 'huff coughs' to clear your lungs.

Repeat Step 2

3
REPEAT step 2 four times, or as directed by your healthcare practitioner.
Below, please find abbreviated instructions for use.
QUICK START INSTRUCTIONS
®
®
A B
C
Cylinder
D
B
Disk
A
4 seconds
over, please
3L
C
2L
Target
marker
1L
D
E
