Summary of Contents for AUSTRALIAN MONITOR DPRM
- Page 1 SERVICE INFORMATION DIGIPAGE DPRM REMOTE CONTROL PANEL CONTENTS: OPERATION MANUAL SCHEMATIC DIAGRAM TEST PROCEDURE SERVICE BULLETIN Australian Monitor 1 Clyde Street, Silverwater NSW 2128 Australia +61 2 9647 1411 www.australianmonitor.com.au...
- Page 2 DPRM REMOTE CONTROL PANEL INSTALLATION AND OPERATION MANUAL...
- Page 3 Precautions should be taken so that the Australian Monitor Inc is not responsible for damage to means of grounding of a piece of equipment is not defeated. loudspeakers for any reason.
-
Page 4: Introduction And Contents
DigiPage Zone Paging and Source Selection System. CONTROLS The DPRM allows control over program source selection, local input INSTALLATION selection and volume control from a remote location. PROGRAMMING LED illumination provides the user with visual feed back if the system is busy. - Page 5 A jumper is provided for the data transmission to be terminated if that Remote Control Panel is at the end of a CAT5 RUN. Shipped as terminated. Data (shown as terminated) Reset Button PAGE 4 DPRM INSTALLATION & OPERATION MANUAL...
-
Page 6: Installation
DigiPage unit. There are two holes available adjacent to the terminal block for securing the CAT5 cable with a cable tie. PAGE 5 DPRM INSTALLATION & OPERATION MANUAL... - Page 7 The BUSY LED will go out. The remote control panel is now programmed. Confirm that the panel is controlling the correct zone. NOTE: You have approx. 2 secs to begin the programming and between button presses else it will exit programming mode. PAGE 6 DPRM INSTALLATION & OPERATION MANUAL...
-
Page 8: Australia And New Zealand
AUSTRALIA AND NEW ZEALAND www.australianmonitor.com.au SYDNEY MELBOURNE BRISBANE ADELAIDE PERTH AUCKLAND (NSW & ACT SALES) (VIC & TAS SALES) (QLD SALES) (SA & NT SALES) (WA SALES) (NZ SALES) 149 Beaconsfield 22/277 42 Commercial Road 31 Walsh Street 299 Fitzgerald Street Unit B, 11 Piermark Street Silverwater Middleborough Road... - Page 9 PCB6298 PCB6297 LM2594 VOLUME PROG SOURCE LOCAL DOWN PROG OFF 250uH 100u 220u 1N5818 RESET BUSY 100R DS3695 74LS165 16F84 BC556 100K BC556 BC546 BUZZER PN2K WALL CONTROL Title CD6297-1 Size Number Revision Date: 19-Nov-2003 Sheet of File: C:\ATC\DigiPage\DigiPage.ddb Drawn By:...
- Page 10 DIGIPAGE DPRM (WALL UNIT) FINAL TESTING PROCEDURE MECHANICAL CHECK: 1. Check for any solder blob on the PCB or in the set. 2. Check for LED height. All should be ( 1.4mm + 0.1mm outside ) 3. Check for any dent marks / scratch marks on the molded chassis.
- Page 11 6. Also check that the “program off” and “Local on/off” selections reflect in the zone for which the wall unit has been programmed. (note that with every selection there should be a beep indicating the selection).
- Page 12 Please be aware that DPRM panels ship from the factory with the DATA bus terminated. If there is more than 1 DPRM (or Paging Station) on the CAT5 RUN you MUST remove the termination from all but the last unit.
-
Page 13: Remote Control Panel
10. REMOTE CONTROL PANEL Introduction The Australian Monitor Installation Series DPRM Remote Control Panel is a control surface that is designed to be used with the DigiPage Zone Paging and Source Selection System. The DPRM allows control over program source selection, local input selection and volume control from a remote location. - Page 14 5. Press the Up button X times (the unit will beep each time). Eg. for ZONE 4, press 4 times 6. Press the Down button. 7. The BUSY LED will go out. The remote control panel is now programmed. 8. Confirm that the panel is controlling the correct zone. Australian Monitor INSTALLATION SERIES...
